TRENDnet TEW-410APBplus User manual
Copyright ©2004. All Rights Reserved. TRENDware International, Inc.
TRENDnet
TRENDware, USA
What's Next in Networking
TEW-410APBplus
Version 05.26.04
54Mbps 802.11g Wireless Access Point + Bridge
Quick Installation Guide
Guide d'installation rapide pour le
Point d'Accès Sans Fil 54Mbps 802.11g + fonction "bridge"
Schnell Anleitung
54Mbit/s 802.11g Wireless Access Point + Bridge
Guía de Instalación Rápida del
Base Transmisora Wireless + Bridge 802.11g de 54Mbps
Table of Contents
English ......................................................................................................
Troubleshooting...........................................................................................
1
1
2
3
8
13
1. Prepare for Installation ......................................................................
2. Install Hardware ................................................................................
3. Configure the computer’s TCP/IP Settings .......................................
4.Configure the Access Point ................................................................
Thank you for purchasing the TEW-410APBplus. With this Access Point, you
will be able to share your files and resources between wired and wireless PCs.
This guide will help you set-up and configure your Access Point. Following the
installation instructions should be quick and easy. If you run into problems,
please refer to the Troubleshooting section or more detailed information from
the User’s Guide on the CD-ROM. If you need further technical support, please
visit www.TRENDNET.com or contact us by phone.
Verify Package Contents
Please make sure you have everything in the box:
5 Ft. RJ-45
Network Cable
User’s Guide CD-ROM
1
Quick Installation Guide
TEW-410APBplus
English
1. Prepare for Installation
English QIG
Before installing the Access Point, you should have:
1. A Hub or Switch connecting your existing network.
2. A working Wired PC connected to the Hub/Switch or a working Wireless
PC.
3. A web browser such as Internet Explorer (5.0 or higher) or Netscape
Navigator (4.7 or higher).
4. TCP/IP protocol installed on each computer.
AC Power Adapter
Verify Equipment
TRENDnet
TRENDware, USA
What's Next in Networking
TEW-410APBplus
Version 05.26.04
54Mbps 802.11g Wireless Access Point + Bridge
Quick Installation Guide
Guide d'installation rapide pour le
Point d'Accès Sans Fil 54Mbps 802.11g + fonction "bridge"
Schnell Anleitung
54Mbit/s 802.11g Wireless Access Point + Bridge
Guía de Instalación Rápida del
Base Transmisora Wireless + Bridge 802.11g de 54Mbps
2English
1. Connect the RJ-45 network cable from the Access Point to any port on
the Hub or Switch.
2. For Wired PC setup, please connect another RJ-45 network cable
from the PC to the same Hub or Switch.
3. Connect the AC Power Adapter to the Access Point and to an available
power outlet. Turn on the Access Point.
Verify Hardware Installation
Verify that the following Access Point LEDs are on.
2. Install Hardware
3
1
2
POWER
TEW-410APBplus
3
3. Configure the computer’s TCP/IP Settings
English
The Access Point has a default IP address 192.168.1.250, therefore to be able
to access and configure the Access Point, the computer's TCP/IP settings need
to be changed.
Windows 95/98/98SE/ME
1. Find the Start button located on Desktop.
2. Click Start; click Settings and then click on Control Panel.
3. Double-Click the Network Icon and the Network Properties box will
appear.
4. Under the Configuration tab, locate and select TCP/IP with the
corresponding network card. Then click on the Properties button and
the TCP/IP Properties window will appear.
4English
5. Under the IP Address tab, select Specify an IP address and enter
“192.168.1.50” for the IP address and “255.255.255.0” for the Subnet Mask.
Then, click OK.
6. Click OK.
7. At this point, the installation may require files from your Windows
CD-ROM. If this happens insert Windows CD-ROM into your
CD-ROM drive and select the CD-ROM drive to load the necessary files.
8. After the files load, the System Settings Change prompt will appear; click
Yes to restart your computer.
9. Your computer is now ready to access and configure the Access Point.
Point.
NOTE: If this prompt does not appear, you must manually restart your
computer.
5English
Windows 2000/XP
1. Find Start button located on Desktop.
2. Click Start; click Settings and then click on Control Panel.
3. Double-Click the Network Connection Icon.
4. Right-Click on the Local Area Connection icon and then click on
Properties. The Local Area Connection Properties box will appear.
6English
6. Click on Use the following IP address; then enter 192.168.1.50 for
IP Address and 255.255.255.0 for Subnet, then click OK.
7. Click OK on the Local Area Connection Properties box to close it.
8. Your computer is now ready to access and configure the Access Point.
5. Under the General tab, locate and select Internet Protocol TCP/IP and
then click Properties. The Internet Protocol (TCP/IP) Properties box
will appear.
7English
Mac OS X
1. Go to the Apple Menu, click Network and select System Preferences.
2. Select Built in Ethernet in the Show pull-down menu and select Manually
in the configuration pull-down menu.
3. Input a valid IP address and subnet mask. (The IP address must be within
the same range as the TEW-410APBplus. The IP Address of the TEW-
410APBplus is 192.168.1.250 so you can assign 192.168.1.50 and
255.255.255.0 as subnet mask)
4. Click Apply Now and continue to the Configuration section.
8English
The following set-up information is designed to help you to configure the
Access Point to work with your existing Wired or Wireless network.
From a Wired PC
1. Open your Web browser and type http://192.168.1.250 into the Address box
and press the Enter key.
2. The logon pop-up screen will appear, type admin for the username and
admin for the password then click OK to access the configuration page.
4. Configure the Access Point
