TRENDnet TU-400 User manual

TRENDnet introduces TU-400 4-port USB Hub that includes

highly integrated four USB ports. The TU-400 is convenient

for a wide variety of legacies and other peripherals, such as

speakers, cameras, and joysticks, to be connected that are

controlled by USB enabled systems. Our TU-400 USB Hub

equips with power control and over-current detection on each

of four downstream ports. This feature allows to detect both

modes automatically. With TRENDnet TU-400’s data access

rate up to 12Mbps, it provides for devices requiring more

bandwidth. Compact, efficient, and easy-to-install

TRENDnet’s TU-400 is the choice for USB solution.

TU-400

4-Port USB Hub

Compatible with Universal Serial Bus Rev. 1.0

Specification

Plug and Play (PnP) with USB devices

Easy to expand USB Hub allows the use up to 127

devices

6 status LEDs per USB port indication

Supports 1 upstream and 4 downstream USB ports

Supports Self-Powered mode and Bus-Powered mode

indicated by power LED

All downstream ports support high-speed (12Mbps ) and

low-speed (1.5Mbps) operations mode

Power control/overload detection on each individual USB

port

2.1 Amp switching power supply - Ensures each port has

500mA current output

5 Year Warranty

BENEFITSFEATURES

Compatibility:

Flexibility:

Expandability:

Speed:

4-port USB Hub is compatible with

Windows 95/98/NT 5.0, Windows

2000, iMac, Mac G3, so it is ready to

work as soon as the users plug it into

PC.

TU-400 provides the most convenient

way to connect USB to any Desktop

or Laptop.

Able to daisy-chain to additional USB

Hub that allows the use up to 127

USB devices at the same time.

Provides 12Mbps high-speed and

1.5Mbps low-speed operations mode.

TU-400 (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TU-ET10: USB to Ethernet Adapter

TU-ET100: USB to 10/100Mbps Fast Ethernet

Adapter

TU-400: 4-port USB Hub

TU-700: 7-port USB Hub

NETWORKING SOLUTIONS

SPECIFICATIONS

TU-400

4-Port USB Hub

TU-400

4-Port USB Hub

Standard:

Universal Serial Bus Standard v1.0

USB Ports:

1 x upstream port, 4 x downstream ports

Access Speed:

12Mbps for high-speed,

1.5Mbps for low-speed

Power:

External power supply DC6V, 2.1A

Max Devices Supported:

127 (daisy-chaining hubs)

Power Consumption:

DC 5V/500mA per each USB

downstream ports

LED Indicators:

1 Bus-Power LED (green),

1 Self-Power LED (orange),

4 Port-Status LEDs (green)

•

Dimensions:

102 x 85 x 30 mm

(4.01 x 3.35 x 1.18 inches)

Weight:

113 g (0.25 lbs.)

Temperature:

Operating: 0° to 70° C

Storage: -20° to 80° C

Operating Humidity:

10% to 95% (non-condensing)

Certifications:

FCC, CE, VCCI-II

•

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
