TRENDnet TK-205K - PS/2 KVM Switch User manual

The 2-Port PS/2 KVM Switch lets you manage two PC's with just one

set of keyboard, monitor, and mouse. Switch between two PC's with

a simple press of a button! Separate sets of KVM cables are

included with the KVM Switch, so users can start controlling 2 PC's

instantly. The KVM cables also provide power to the KVM Switch,

eliminating the need for a power adapter. Hot Key operations

provide immediate access to features such as computer switching,

and auto-scanning. With its Hot-Plug and Audible Feedback, the 2-

Port PS/2 KVM Switch is the perfect choice for managing multiple

PC's.

TK-205K

2-Port PS/2 KVM Switch

TEW-503PI (07-28-2005) TK-205K

rev:10.08.2005

• Use one keyboard, monitor, and mouse to control two computers

• PS/2 Keyboard/Mouse emulation

• 2-Port KVM switch in compact size design with 2 sets of 3 to 1 KVM Cables

• Support Microsoft Intellimouse, Optical Mouse, Logitech Net Mouse and more

• Support very High Video Quality, up to 300MHz 2048 x 1536 VGA resolution

• No software required, easy PC selection via Push Button and Hot-Key Commands

• Support High Video Quality, up to 300MHz 2048 x 1536 VGA, or up to 800 x 600 SVGA resolution

• Hot-Plug feature, add PC or remove the connected PC for maintenance without powering down the KVM Switch or other PC's.

• Auto-Scan Mode for monitoring PC's.

• Keyboard status restored when switching between PC's.

• LED display for easy status monitoring

• Beeping sound for port switching confirmation

• 2-Year Warranty

FEATURESFEATURES

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

2-Port PS/2 KVM Switch

TK-205K

SPECIFICATIONSSPECIFICATIONS

RELATED PRODUCTSRELATED PRODUCTS

PACKAGE CONTENTSPACKAGE CONTENTS

• 2 sets of KVM Cables

• TK-205K

• Multi-Language User's Guide

TK-207K

TK-210K

TK-205K 2-Port PS/2 KVM Switch

2-Port USB KVM Switch

2-Port USB Hub and PS/2 KVM Switch with Audio

KVM Cable

Auto-Scan Interval

Cable Interface (all male)

Console (all female)

Keyboard State

Power Type

Weight

Humidity

Certifications

Dimensions

Temperature

• 2

• Push Buttons and Hot-Key Commands

• 2 Sets of 1.2M (4ft) KVM Cables

• 10 seconds

• 95 x 65 x 30 mm (3.7 x 2.6 x 1.2 in.)

• Operating: 0°C ~ 40°C (32°F ~104°F)

• To Console: 1 x VGA/SVGA HDB 15-pin

• To PC: - 1 x PS/2 Mouse 6-pin Mini Din

• Saved and Restored

• 1 x PS/2 Mouse 6-pin Mini Din

• 1 x PS/2 Keyboard 6-pin Mini Din

• 85 g (3 oz)

• PS/2 Interface Power

• 0%~80%, Non-Condensing

• CE, FCC

• Storage: -20°C ~ 60°C (-4°F ~140°F)

Port Selection

Computer Connections

Hardware

• 1 x VGA/SVGA HDB 15-pin

- 1 x PS/2 Keyboard 6-pin Mini Din

- 1 x VGA/SVGA HDB 15-pin

ORDERING INFORMATIONORDERING INFORMATION

To Order Please Call:

1-888-326-6061

3135 Kashiwa Street,Torrance, CA 90505 USA

Tel: 1-888-777-1550

Fax: 310-891-1111

Web:

Email: [email protected]

www.trendnet.com

NETWORKING SOLUTIONSNETWORKING SOLUTIONS

2-Port

KVM Switch

PS/2

(TK-205K)

PC 1

Keyboard Mouse

VGA Cable

PS/2 Cable

PC 2

LCD Monitor

VGAVGA

PS/2 PS/2
