TRENDnet TK-205i User manual

TRENDnet TK-205i 2-Port KVM Switch Kit lets you

manage two PC’s with just one set of keyboard, monitor,

and mouse. Switch between the PC’s with a simple press

of a button! The KVM cables are built into the TK-205i so

users can start controlling 2 PC’s instantly. The TK-205i is

a self-powered KVM Switch loaded with friendly features.

With its Hot-Plug, Auto-Scan, Audible Feedback, and

Hot-Key operations, the TK-205i is the perfect choice for

managing multiple PC’s.

TK-205i

2-Port KVM Switch with Integrated Cables

Use one keyboard, monitor, and mouse to control two computers

PS/2 Keyboard/Mouse emulation

2-Port KVM switch in compact size design

2 sets of KVM Cables are integrated into the unit

Support Microsoft Intellimouse, Optical Mouse, Logitech Net

Mouse…etc.

Support very High Video Quality, up to 1920 x 1440 with 200Mhz

bandwidth

No software required, easy PC selection via Push Button and Hot-

Key Commands

Support DOS, Windows 3.x/95/98/ME/NT/2000/XP, Netware, Unix,

Linux, and more

Hot-Plug feature, add PC or remove the connected PC for

maintenance without powering down the KVM Switch or other

PC’s.

Auto-Scan Mode for monitoring PC’s.

Keyboard status restored when switching between PC’s.

LED display for easy status monitoring

Beeping sound for port switching confirmation

1-Year Warranty

BENEFITSFEATURES

Integration Friendly

Flexible

Cost Effective

Performance

Does not require driver/software for

the installation and operation.

Switching between PCs with the push

button or Hot-Key commands.

Hot-Plug feature, add PC’s or remove

connected PC’s without powering off

the KVM switch or the other PC’s.

Manage two PC’s with single

keyboard, monitor, and mouse. Save

on equipment cost, utility, and space.

Support very High Video Quality up to

1920 x 1440 with 200Mhz bandwidth.

Keyboard status is saved for each PC.

TK-205i (07-08-2004)

TRENDnet

TRENDware, USA

What's Next in Networking

RELATED PRODUCT

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

SPECIFICATIONS

Computer Connections:

Port Connectors:

Keyboard & Mouse: PS/2 type

6-pin mini Din. Monitor: 15-pin

HDDB type

KVM Cable:

Length:

1.4 meters (4.6 feet)

Console Port:

Port Selection:

Push Button

Auto-Scan Intervals:

4 seconds

• 2

•

• 2 sets of high-grade KVM cables

(UL2919 for VGA monitor).

•

Switching Confirmation:

Beeping sound

Keyboard State:

Saved and restored

Power Supply:

Draw power from computer’s

keyboard port.

Dimensions:

102 x 63 x 30 mm

(4.02 x 2.48 x 1.18 inches)

Weight:

Appro. 315 g. (11.1 Oz.)

Temperature:

Operating: 0° ~ 40°C (32° ~104°F)

Storage: -20° ~ 60°C (-4° ~ 140°F)

Humidity:

0%~80%, Non-Condensing

•

Certifications:

FCC, CE•

TK-200K: 2-Port KVM Switch Kit

TK-205i: 2-Port KVM Switch with Integrated

Cables

TK-400K: 4-Port KVM Switch

TK-401R: 4-Port Rack-Mountable KVM Switch

TK-800R: 8-Port KVM Stackable Rack-Mountable

Switch (with OSD)

TK-801R: 8-Port Rack-Mountable KVM Switch

TK-205i

2-Port KVM Switch with Integrated Cables

TK-205i

2-Port KVM Switch with Integrated Cables

TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
