TRENDnet TEG-240WS User manual

The 24-Port Gigabit Web Smart Switch with 2 Shared Mini-GBIC Slots

(model TEG-240WS) delivers a 48Gbps switching capacity with

managed layer 2 features at a reduced cost. Support for SNMP v1,

802.1X, STP, 802.1Q VLAN, QoS, IGMP snooping, Broadcast Storm

Control and port Trunking provides a cost effective, scalable and secure

backbone switch solution for SMB networks.

SNMP support enables the switch to provide valuable status and event

information, saving system administrators time and resources. Connect

a fiber network to the shared Mini-GBIC slots. Access the Web-browser

management interface and segment up to 256 Virtual Local Area

Networks, manage network priority with 802.1p support and dedicate

bandwidth with port-based Trunking.

TEG-240WS [C1.0R]

24-port Gigabit Web Smart Switch with 2 Shared

Mini-GBIC slots

TEG-240WS

rev: 06.04.2009

• 24 x 10/100/1000Mbps Auto-MDIX RJ-45 ports

• 2 x 1000Base-SX/LX Mini-GBIC slots (shared with Gigabit ports 23-24)

• 48Gbps switching capacity

• IEEE 802.3x Full Duplex Flow Control and Back Pressure

• IEEE 802.3ad Port Trunk

• IEEE 802.1D Spanning Tree Protocol

• IEEE 802.1p QoS

• IEEE 802.1X Authentication and SNMP v1 support

• Supports port based IEEE 802.1Q VLAN Tag and Asymmetric VLAN

• Full Wire-Speed non-blocking reception and transmission

• Store and Forward switching method

• Front panel diagnostic LEDs

• Supports Jumbo Frame packet transfer (max size up to 10Kytes)

• Integrated address look-up engine supports up to 8K absolute MAC addresses

• Supports 512Kbytes RAM for data buffering

• Easy configuration via Web browser

• Standard 19” (1U) rackmount size (rackmount kit included)

• 5-Year Limited Warranty

FEATURES

Protocol

Power Supply

Interface

Network Media

Data Transfer Rate

Filtering Address Table

Power Consumption

Dimension

Temperature

Weight

Certifications

• IEEE 802.3ad Port Trunk • IEEE 802.1D Spanning Tree Protocol

• Per Unit: Power, System

• CSMA/CD

• 100 ~ 240VAC 50/60Hz, internal universal switching power

• Operating: 0°C ~ 40°C (32°F ~ 104°F); storage: -10°C to 70°C (14°F to 158°F)

• Store-and-Forward

• 24 x 10/100/1000Mbps Auto-MDIX RJ-45 ports

• 10Mbps: 10/20Mbps (Half/Full-Duplex)

• 440 x 210 x 44mm (17.3 x 8.3 x 1.73in.)

• 512KBytes per device

• 8K entries per device

• 48Gbps forwarding capacity

• 3kg (6.6lb)

• Operating: 10 % ~ 90 % (non-condensing); storage: 5 % ~ 90 %(non-condensing)

Switch Fabric

Diagnostic LEDs

Standard

Hardware

SPECIFICATIONS

• Ethernet: UTP/STP Cat. 3, 4, 5 up to 100m

• Per Copper Gigabit Port: Link/ACT, 1000M, 100M

• IEEE 802.3 10Base-T • IEEE 802.3u 100Base-TX • IEEE 802.3ab 1000Base-T

• Per Mini-GBIC Port: Link/ACT, 1000M

• 35 watts (max)

Humidity

• CE, FCC

TEG-240WS

rev: 06.04.2009

TEG-240WS [C1.0R]

24-port Gigabit Web Smart Switch with 2 Shared Mini-GBIC slots

• IEEE 802.3x Flow Control and Back Pressure

• IEEE 802.3z 1000Base-SX/LX (Mini-GBIC)

• IEEE 802.1Q VLAN Tag • IEEE 802.1X Authentication

• IEEE 802.1p QoS • SNMP v1

Transmission Method

• 2 x 1000Base-SX/LX Mini-GBIC slots (shared with Gigabit ports 23-24)

• Fast Ethernet: UTP/STP Cat. 5, 5e up to 100m

• Gigabit: UTP/STP Cat. 5, 5e, 6 up to 100m

• 100Mbps: 100/200Mbps (Half/Full-Duplex) • 1000Mbps: 2000Mbps (Full-Duplex)

Data RAM Buffers

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

RELATED PRODUCTS

PACKAGE CONTENTS

TEG-160WS

TEG-PCITXR Gigabit PCI Adapter

• Rackmount Kit

• CD-ROM (Utility & User's Guide)

16-port Gigabit Web Smart Switch w/ 2 Shared

Mini-GBIC Slots

• TEG-240WS

• Multi-Language Quick Installation Guide

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

• Power Cord

NETWORKING SOLUTIONS

Optional Mini-GBIC Modules

TEG-MGBS10

TEG-MGBSX Mini-GBIC Multi-Mode SX Module

Mini-GBIC Single-Mode LC Module

TEG-MGBS80

TEG-MGBS40

TEG-MGBS40D35

TEG-MGBS10D35

Mini-GBIC Single-Mode LC Module

Power over Ethernet (PoE) Splitter

Mini-GBIC Dual Wavelength Single-Mode LC Module

1310/1550 Pair

Mini-GBIC Dual Wavelength Single-Mode LC Module

1310/1550 Pair

TEG-PCBUSR Gigabit PC Card

TEG-240WS [C1.0R]

24-port Gigabit Web Smart Switch with 2 Shared Mini-GBIC slots

Servers with 10/100/1000Mbps

Copper Gigabit PCI Adapter

(TEG-PCITXR)

24-Port Gigabit Web Smart Switch

with 2 Shared Mini-GBIC slots

(TEG-240WS)

Single Mode Fiber

Mini-GBIC Modules

(TEG-MGBS10)

Laptops with 32-bit

Gigabit CardBus PC Card

(TEG-PCBUSR)

Single Mode Fiber

Mini-GBIC Modules

(TEG-MGBS10)

16-Port Gigabit Web Smart Switch

with Mini-GBIC Slots

(TEG-160WS)
