TRENDnet TE100-DX8Eplus User manual

TRENDnet's TE100-DX8Eplus is an 8-port palm-size dual

speed hub that presents a quickest way to build or expand a

Fast Ethernet network. Each port automatically detects and

negotiates 10Mbps and 100Mbps connections. With built-in

switch, it allows communica-tion between network end nodes

operating at different speeds. These hubs support one switch

port that allows your hub to be uplinked together without

considering the uplink rule of 10Mbps and 100Mbps hubs. An

uplink port extends the distance to 100 meters with 10Mbps or

100Mbps hub stacks. TRENDnet's TE100-DX8Eplus is

perfect for small workgroups to expand as their networking

needs grow.

TE100-DX8Eplus

8-Port 10/100Mbps Dual Speed Hub with Switched Uplink Port

Compatible with IEEE 802.3 10Base-T Ethernet

IEEE 802.3µ Fast Ethernet standards

8 10/100Mbps auto-negotiation ports

Fast Ethernet supports both shielded twisted pair

and CAT 5 unshielded twisted pair cables

MID-II uplink port for easy expansion

Built-in switch function intercommunicates between

10Mbps and 100Mbps segments

Plug and Play with auto-configuration

One switch port supports 100Mbps uplink distance

up to 100 meters

External power adapter included

Uplink jack for easy linking of two hubs to further

expands the network

5 Year Warranty

FEATURES BENEFITS

Performance:

Expandability:

Flexible:

Cost-Effectiveness:

Easy Upgrade:

Full 100Mbps connectivity significantly

boosts network performance.

Uplink to another 100Mbps hubs up to

100 meters away by using the switched

uplink port and UTP/STP CAT 5 cable.

Seamless integration of 10Base-T and

100Base-TX networks.

Provides 10Mbps, 100Mbps hub and

10/100 switching functionality in one

unit.

Ethernet workgroups can be upgraded

to Fast Ethernet without changing hubs.

TE100-DX8Eplus (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TE100-DX5Eplus

5-port 10/100Mbps Dual Speed Hub with

Switched Uplink Port

TE100-DX8Eplus

8-port 10/100Mbps Dual Speed Hub with

Switched Uplink Port

NETWORKING SOLUTIONS

SPECIFICATIONS

Standards:

• IEEE 802.3 10Base-T Ethernet,

IEEE 802.3µ 100Base-TX Fast Ethernet standards

Protocols:

• CSMA/CD

Data Transfer Rate:

• 10/100Mbps

Topology:

• Star

Network Media:

• UTP CAT 5 (100 m), EIA/TIA-568 100-ohm

screened twisted pair (STP) (100 m)

Power Consumption:

• 12 Watts max. AC external power adapter

Diagnostic LEDs:

• System: Power, 10M Collision, 100M Collision,

EXP-FDX

• Port: 10M Link/Act, 100M Link/Act

Dimensions:

• 171 x 98 x 29 mm

(6.73 x 3.86 x 1.14 inches)

Weight:

• 453 g (1.0 lb.)

Temperature:

• Operating: -10° to 40° C (14° to 104° F)

• Storage: -20 to 70° C (-4° to 158° F)

Humidity:

• Operating: 10 % to 90 % non-condensing

• Storage: 5 % to 90 % non-condensing

Certifications:

• FCC, CE, VCCI

TE100-DX8Eplus

8-Port 10/100Mbps Dual Speed Hub with Switched Uplink Port

TE100-DX8Eplus

8-Port 10/100Mbps Dual Speed Hub with Switched Uplink Port

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.trendnet.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
