TRENDnet TFC-110S100 User manual

TRENDnet's TFC-110 series Fiber Media Converter transforms

10/100Base-TX UTP/STP media to 100Base-FX media and vice

versa. The 10/100Base-TX port auto-sense 10 or 100Mbps

connection speed, auto-negotiates half-/full-duplex mode, and auto-

selects MDI-X / MDI-II media type. The fiber connection can be

multi-mode SC, MT-RJ, or single-mode SC Connector and it has a

slide-switch for selecting half- or full-duplex mode. This converter

will give your Switch/Hub the ability to interface with fiber connection

over a distance up to 100 km. With the optional 16-slot EIA-19" rack-

mount chassis; the TFC series converters are the perfect solutions

for various fiber media conversions for your network.

TFC-110S100

10/100Base-TX to 100Base-FX Single-Mode

Fiber Converter (100Km) with SC-Type

Connector

TFC-110S100

rev:05.02.2007

• Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX / 100Base-FX standards

• One 10/100Base-TX auto-negotiation RJ-45 port

• Auto-negotiation 10/100Mbps connection speed and Half/Full-duplex mode on TX port

• Auto MDIX for 10/100Base-TX port

• One 100Mbps fiber port with Single-mode SC-Type Connector

• Half / Full-Duplex mode selector on Fiber port

• Status LED indicators for Power, Link/Activity, Full-Duplex, and Speed

• Wall-Mountable

• Optional 19” system chassis with redundant power supply (TFC-1600), holds up to 16 TFC series Media Converters

• 5-year Warranty

FEATURES

Supported Frame Size

Network Media

Wavelength

Protocol

Ports

Data Transfer Rate

Humidity

Temperature

• IEEE802.3 10Base-T, IEEE 802.3u 100Base-TX and 100Base-FX

• Standard Ethernet up to 1522-Byte

• Power, Link/Activity, Full-Duplex, and Speed

• 100Base-TX: Cat. 5, EIA/TIA-568 100-ohm UTP/STP, up to 100 meters.

• 100Base-FX: Single-Mode fiber optic cable 9/125 or 10/125 µm, up to 100 Km.

• 1300nm

• 100Mbps (Half-Duplex), 200Mbps (Full-Duplex)

• Operating: 0° ~ 40° C (32° ~ 104° F) ; Storage: -25° ~ 70° C (-13° ~ 158° F)

• Operating: 10% ~ 90% ; Storage: 5% ~ 90% (non-condensing)

• CSMA/CD

• 1 x 10/100Base-TX and 1 x 100Base-FX

• 7.5VDC, 1.5A (7.2 watts max.)

Diagnostic LEDs

Power Adapter

Standards

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

10/100Base-TX to 100Base-FX Single-Mode Fiber Converter

(100Km) with SC-Type Connector

TFC-110S100

RELATED PRODUCTS

TFC-110MSC

TFC-110MM

TFC-1600 16-Slot Chassis System for TFC series Fiber Converter

10/100Base-TX to 100Base-FX Multi-Mode Fiber

Converter with SC-Type Connector

10/100Base-TX to 100Base-FX Multi-Mode Fiber

Converter with MT-RJ Connector

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

SPECIFICATIONS

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

TFC-110MST

TFC-110S15

10/100Base-TX to 100Base-FX Multi-Mode Fiber

Converter with ST-Type Connector

10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (15Km) with SC-Type Connector

TFC-110S30 10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (30Km) with SC-Type Connector

TFC-110S60 10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (60Km) with SC-Type Connector

Other manuals for TFC-110S100
