Overview
The Trend Micro™ TippingPoint™ Threat Protection System (TPS) is a high-
performance, enterprise-class solution that protects your network by
scanning, detecting, and responding to network trac according to the
lters, action sets, and global settings maintained on each device by a client.
The TPS oers improved technology that is optimized for higher throughput,
high resiliency, high availability, and network segment protection from both
external and internal attacks. In addition, the TXE model oers improved
hardware acceleration that enables characterizing and network visibility
capabilities.
You can install as many TPS security devices as you need to strategically
protect your network enterprise zones. You can manage a device by using its
command line interface (CLI) or by using the Security Management System
(SMS) console.
Learn more about each TPS product in the following sections:
•TPS 9200TXE device on page 1
•TPS TX Series devices on page 2
•TPS 2200T device on page 5
•TPS 440T device on page 6
For information about the Virtual Threat Protection System (vTPS) virtual
appliance, refer to that product documentation.
TPS 9200TXE device
Figure 1. 9200TXE device
This TPS TXE security device provides the following hardware features.
1
Feature Description
Ports 1GbE Copper + 25GbE SFP28 management port
Dual QSFP28-DD (400Gbps Full-Duplex Total) special
purpose ports
RJ-45 serial console port
Slots Two I/O slots
AC Power supply Two hot-swappable, replaceable (1500W/110V and
2000W/220V) PSUs
1+1 redundant
External storage One 240 GB SSD
Fans Seven hot-swappable dual-rotor 40 mm modules
TPS TX Series devices
TPS Hardware Specification and Installation
2
The TPS TX Series security devices provide the following hardware features.
Feature Model Description
Ports 1100TX • One RJ-45 console port
• One 1 GbE copper management
port
TPS Hardware Specification and Installation
3
Feature Model Description
5500TX • Two fixed SFP+ special purpose
(SP) ports (not used in this TOS
release)
• One RJ-45 console port
• One 1 GbE copper management
port
8200TX and 8400TX • Two fixed QSFP+ special
purpose (SP)
• One RJ-45 console port
• One 1 GbE copper management
port
Slots 1100TX One I/O slot
5500TX Two I/O slots
8200TX and 8400TX Four I/O slots
Power supply 1100TX One replaceable 250W AC power
supply
5500TX Two hot-swappable, redundant 250W
AC power supplies
8200TX and 8400TX Two hot-swappable, redundant 750W
AC power supplies
External storage 1100TX One 8 GB SSD
5500TX, 8200TX, and
8400TX
One 32 GB SSD
Fans 1100TX Two (nonreplaceable)
5500TX Three (nonreplaceable)
8200TX and 8400TX Seven (replaceable and hot-
swappable)
TPS Hardware Specification and Installation
4
TPS 2200T device
The TPS 2200T device provides the following hardware features.
Feature 2200T device
Ports One RJ-45 console port
One 1 GbE copper management port
1 GbE copper ports 8
1 GbE SFP ports 8
10 GbE* SFP+ ports 4
Power supply 2 hot-swappable 750W AC power supplies
External storage One 8 GB CFast
System fans 3 fans (not replaceable)
Dedicated High Availability (HA) port Yes
Zero Power High Availability (ZPHA)** Built-in ZPHA for copper segments
External ZPHA port for SFP and SFP+
segments
*Rate does not include autonegotiation. Dual-rate SFP+ transceivers are not supported.
TPS Hardware Specification and Installation
5
**To learn more about installing and operating a ZPHA module, refer to TippingPoint ZPHA
Installation Guide – Modular and Non-Modular.
TPS 440T device
The TPS 440T device provides the following hardware features.
Feature 440T device
Ports One RJ-45 console port
One 1 GbE copper management port
1 GbE copper ports 8
Power supply One 350W (built-in) power supply
External storage One 8 GB CFast
System fans 3 internal fans (not replaceable)
Dedicated High Availability (HA) port Yes
Zero Power High Availability (ZPHA) Built-in ZPHA for copper segments
TPS 9200TXE device overview
The following topics describe the components, chassis, requirements, and
installation specics of the 9200TXE device:
•Chassis – front panel on page 7
•Chassis – rear panel on page 7
TPS Hardware Specification and Installation
6
•Chassis – features on page 7
•Model requirements on page 11
•I/O modules on page 12
•Technical specications on page 16
Learn more on page 51 about installing the device. Prior to installation, have
the TPS CLI Reference available for conguration information.
Chassis – front panel
The following illustration shows the front panel view of the 9200TXE device:
Figure 2. 9200TXE front panel
Chassis – rear panel
The following illustration shows the rear panel view of the 9200TXE device:
Figure 3. 9200TXE rear panel
Chassis – features
Refer to the following topics for information about the 9200TXE chassis
features:
•Fans and power supplies on page 8
TPS Hardware Specification and Installation
7
•External SSD on page 8
•Ports on page 8
•Chassis LEDs on page 10
Fans and power supplies
The 9200TXE device includes:
• Two hot-swappable power supplies
• Seven hot-swappable fans
Learn more about Power supplies on page 62 and Fans on page 69.
External SSD
The TXE device includes an external SSD module that ships pre-installed
with your product. The SSD is used to store trac logs, snapshots, and other
system data. You can remove and install the card while the device is running;
however, to do so, you must issue the appropriate unmounting, mounting,
and preparation commands from the device CLI.
Learn more on page 77 about these external user disk commands.
Ports
The TXE device comes equipped with network slots for standard or bypass
I/O modules.
TPS Hardware Specification and Installation
8
