Tranberg TEF 2502 User manual
R. Stahl Tranberg AS
E[email protected] | stahl-tranberg.com
Main office: Strandsvingen 6 | N-4032 Stavanger | Norway | T+47 51 57 89 00 | F+47 51 57 89 50
Office Oslo: Luhrtoppen 2 | N-1470 Lørenskog |Norway | T+47 24 08 44 10
IMPORTANT
Read this instruction carefully before installing the
product
LIGHTING
TEF 2502 FLOODLIGHT
HALOGEN 1000W
SAFE AREA
USER MANUAL
Subject to change without prior notice TUM4139 REV. B 14.07.2017
TEF 2502 HALOGEN FLOODLIGHT 1000W USER MANUAL
INTRODUCTION
Thank you for purchasing this product!
For installation, maintenance and assurance of a long life
of this product, please follow this manual.
CONTENT IN BOX
The product is fully assembled, and ready for installation.
SAFETY PRECAUTIONS
Note that changes made to the product and/or installation
of components which do not conform to the approval,
may be a safety violation. The manufacturer will in no
circumstance be held responsible for such activity.
For your health and safety, always use safety gear suited
for the task. Be certain to follow codes, regulations and/or
specific procedures that are related to the installation.
TOOLS REQUIRED
Regular tools required for installation:
• Flat small screwdriver
• PH 1 screwdriver
• Wrench or similar for fastening the lamp
MAINTENANCE INSTRUCTIONS
The light should be inspected according to Company
routines. The manufacturer suggests regular check for
water intrusion/condensation which should be removed
immediately. When cleaning, use only mild detergents.
Alcohol or petroleum based products may damage lens or
paint.
APPLICATIONS
• Ships
• Yachts
• Fishing vessels
• Offshore and industrial installations
• Public areas
APPROVALS
NA
TEF 2502 HALOGEN FLOODLIGHT 1000W USER MANUAL
INSTALLATION INSTRUCTIONS
LAMP 230 VAC
Cable glands
The installated cable gland is suited for cables with diameters ranging from 9,1 to 14,3mm.
Be sure to install the cable in a way wich prevents water to penetrate into the enclosure
through the cable gland
R. Stahl Tranberg AS
E[email protected] | stahl-tranberg.com
Main office: Strandsvingen 6 | N-4032 Stavanger | Norway | T+47 51 57 89 00 | F+47 51 57 89 50
Office Oslo: Luhrtoppen 2 | N-1470 Lørenskog |Norway | T+47 24 08 44 10
TEF 2502 HALOGEN FLOODLIGHT 1000W USER MANUAL
TECHNICAL DATA
Housing: Glass-holding frame, latches and bracket made out of stainless steel,
Powercoated (RAL 9018) casing. Hard glass pane, resistant against
temperature changes
Input voltage: 230V AC
Lamp: Halogen 1000W
Option: Narrow beam
Burning position: +/- 15° horizontal
Lamp holder: R7s
Mounting: Four mounting hole, Ø10,5mm
IP-rating: IP67 ( According to EN60529)
Standard cable entries: Brass M25 cable glands
Cable: 9,1- 14,3mm
Weight: 7,9 kg.
