Traeger RANGER TFT18KLD User manual

ASSEMBLY

GUIDE

A MAJOR CAUSE OF FIRES IS FAILURE

TO MAINTAIN REQUIRED CLEARANCES

(AIR SPACES) BETWEEN COMBUSTIBLE

MATERIALS. IT IS OF UTMOST

IMPORTANCE THAT THIS PRODUCT

BE INSTALLED ONLY IN ACCORDANCE

WITH THESE INSTRUCTIONS.

Wood Fired Grills – Ranger

Please read this entire manual before installation and use of this pellet fuel-burning appliance.

Failure to follow these instructions could result in property damage, bodily injury, or even death.

Contact your local building or ﬁre ocials about restrictions and installation inspection requirements

in your area.

For English-only assistance

with assembly, installation, parts,

and customer service, contact

Traeger's VIP-365 Customer Service.

Phone: 1-800-TRAEGER

Email: [email protected]

Mail: Traeger Pellet Grills LLC

1215 E. Wilmington Ave.

Salt Lake City, UT 84106

traegergrills.com

WARNING!

Many parts of the grill will become very hot during operation. Care

must be taken to avoid burns, both during operation and afterwards,

while the grill is still hot.

• Never leave the grill unattended when young children are present.

• Never move the grill when it is operating.

• Let the grill cool completely before moving or attempting to

transport.

• Grill is very heavy. Always lift grill with TWO people.

IMPORTANT, RETAIN FOR FUTURE

REFERENCE: READ CAREFULLY

TFT18KLD

08/2018

Traeger Pellet Grills LLC

1215 E. Wilmington Ave

Salt Lake City, UT 84106

traegergrills.com

4928 Ranger Assemblyv05.indd 1 8/22/18 3:36 PM

READ ALL INSTRUCTIONS BEFORE INSTALLING

AND USING THE APPLIANCE

PARTS LIST

BLISTER PACK PARTS

NEEDED

PART DESCRIPTION

1Grill Lid

2Grill Body

3Feet with Caps

4Lid Handle

5Cast-Iron Griddle

6Grill Grate

7Grease Drip Tray

8Grease Bucket

PART DESCRIPTION

ABolts: 1/4-20 x 3⁄8" (2 pcs.)

BWashers: 1/4" (2 pcs.)

CLock Washers: 1/4" (2 pcs.)

DWrench

EPhillips Head Screws (4 pcs.)

FFeet (4 pcs.)

GCaps (4 pcs.)

In this step: 4

Ax 2 Bx 2 Cx 2 D

ATTACH LID HANDLE

In this step: 3

Ex 4 Fx 4 Gx 4

INSTALL FEET

In this step: 7

In this step: 6

PLACE GREASE DRIP TRAY AND BUCKET

INSTALL GRILL GRATE

NOTE: Be sure the grease drain spout on the grease drip

tray extends through the opening in the back of the grill.

IMPORTANT: Always be sure to position the grease drain

bucket under the spout during use!

Traeger’ing is more fun with friends! (No, really, you will need two people to lif the grill.)

NOTE: You should assemble grill on a clean, ﬂat

surface, as you will need to lay it on its back during

assembly.

You are ready to season your grill and get Traeger’ing!

Refer to your Owner’s Manual for operation instructions.

4928 Ranger Assemblyv05.indd 2 8/22/18 3:36 PM
