Tracer BP2607-II User manual
1
OVERVIEW
Congratulations on purchasing the latest in high
performance battery pack technology from Tracer.
Lithium Iron Phosphate (LiFePO4) battery packs are
the safest battery technology available. The output
voltage is identical to Sealed Lead Acid batteries, but
they are approximately 1/3 of the weight. LiFePO4
battery packs will provide over 1400 cycles and are
capableof fast charging.
Please take a moment to read carefully the following
instructions to get the best performance from your
LiFePO4battery pack.
FEATURES
• Lightweight and compact – 1/3 weight of SLA battery.
• Long cycle life – over 1400 cycles.
• Built-in LED fuel gauge displays remaining power.
• Flat discharge curve – high power for longer.
•Fast charging capability – no memory eect.
• BMS protects against: overcharge, short circuit, over
current, over temperature and deep discharge.
• Robust ABS case – IP64 rated.
•CE approved | UN38.3 certi ied | 12 month warranty.
2
SPECIFICATION
BP2607 - II BP2616 - II BP2624 - II
Voltage 12V 12V 12V
Amp-hour 7Ah 16Ah 24Ah
Watt-hour 84Wh 192Wh 288Wh
Charge Time 4-6 hrs
(4A Charger)
8-9 hrs
(4A Charger)
12-13 hrs
(4A Charger)
Max. Cont. Dis-
charge Current 10A 10A 10A
Max Peak Cur-
rent (for 10mS) 30A 40A 40A
Weight 0.99 kg 2.22 kg 2.9 kg
Dimensions 90 x 145
x 65 mm
125 x 175
x 80 mm
138 x 187
x 94 mm
3
CHARGING
AC MAINS CHARGING:
Warning: Only use the Tracer LiFePO4charger
supplied with this battery pack.
1.Plug the charger into the AC mains – the LED light
will glow green.
2. Plug the charger lead rmly into the battery pack –
the LED light will change to red to indicate charging.
3.When the LED light changes back to green the
battery pack is fully charged.
4.Disconnect the charger from the battery pack and
from the AC mains.
5.Do not leave the charger connected to the battery
for long periods after the battery is charged.
DC VEHICLE CHARGING:
A DC (buck booster) vehicle charger (TR8180) is
available at www.tracerpower.com
4
FUEL GAUGE
The battery fuel gauge must be operated at least
2 minutes after the load has been switched o.
The battery will recover slightly and only then will the
fuel gauge provide an accurate charge state indication.
After 2 minutes of no load, press and hold the fuel
gauge button.
The battery fuel gauge indicates the approximate
battery charge state, as the battery varies slightly with
temperature and cycles of use.
3 green & 2 red: Battery fully charged
2 green & 2 red: Over 50% capacity
1 green & 2 red: Over 20% capacity
2 red: * Less than 20% capacity
1 red: ** Less than 10% capacity
No lights: *** Battery empty
* Recharge as soon as possible.
** Battery is about to electronically switch o to
prevent over discharge.
*** Recharge within 12 hours.
5
WARNING
•Do not dispose of in normal household refuse.
•Do not attempt to dismantle the battery pack in
any way.
•Do not short circuit the battery pack – it could overheat
and cause re or explosion.
•If using a 12V light, use a normal length coiled or
straight lead. If the lead is shortened the battery pack
may shut down, as the light will be detected as a
short circuit.
•Charge the battery pack fully before use. If storing the
battery pack, store in a charged state. Recharge every 6
months.
•Recharge the battery pack within 12 hours if fully
discharged.
•Excess heat will degrade the battery pack rapidly.
Always store the battery pack in a cool dry place.
Do not leave for long periods in direct sunlight or a
hot vehicle.
•The battery pack is waterproof to IP64 – do not
immerse in water.
•Transportation – Only battery packs below 100Wh may
be taken on passenger planes. Consult the material
safety data information www.Tacerpower.com prior to
travel or transportation of batteries.
•Further safety data is available to download at
www.tracerpower.com
6
WARRANTY
Your new battery has a 12-month warranty (from the
date of purchase) against premature failure due to
defects in materials and/or workmanship, subject to
the following conditions:
• The warranty does not cover failure due to damage
caused by abuse.*
• The warranty does not cover failure from excessive
wear and tear even within the warranty period.
• A till or computer-generated proof of purchase must
accompany your claim.
• The warrant is limited to the original owner and is
not transferable.
• Should any defect appear, please log your claim with
your retailer or at www.tracerpower.com
The warranty is void if:
• The serial number is removed from the product.
•The battery connection system is modied in any
way.
• The battery has been left in a discharged state.
This warranty is limited to the original purchaser and
is in addition to your statutory rights.
* Charge your battery directly after each use. Leaving
the battery in a discharged state will seriously and
permanently damage its performance. Please note we
cannot uphold warranty claims in these circumstances.
7
ACCESSORIES
Various connectors, spares and accessories are
available for LiFePO4battery packs at
www.tracerpower.com
Bespoke connectors are available on request.
DOWNLOADS
PDF’s can be downloaded at www.tracerpower.com
• Battery pack brochure.
• Battery pack price list.
• Transportation data sheets.
• Safety data sheets.
• Instruction manuals.
WWW.TRACERPOWER.COM
8
Félicitations pour votre achat du bloc batterie haute
performance de Tracer, celui-ci fait appel à la technologie la
plus récente.
Les blocs-batteries au Lithium Fer Phosphate (LiFePO4) sont
conçus à l’aide de la technologie de batterie la plus sûre qui
soit. La tension de sortie est identique à celle des batteries
au plomb scellées (SLA) mais ne pèse que le tiers de leur
poids environ. Les blocs-batteries LiFePO4assurent plus de
1400 cycles et peuvent être rechargés rapidement.
Veuillez lire attentivement les consignes suivantes an
d’obtenir les meilleures performances de votre bloc-batterie
LiFePO4.
• Léger et compact : 1/3 du poids d’une batterie SLA.
• Cycle de vie prolongé : plus de 1400 cycles.
• Une jauge carburant à LED intégrée affiche la charge
restante.
•Courbe horizontale de décharge : puissance élevée plus
longtemps.
•Capacité de recharge rapide : pas d’effet mémoire.
•Le BMS (système de gestion de batterie) protège des
surcharges, courts-circuits, surintensités, températures
excessives et décharges profondes.
•Boîtier ABS robuste : conception étanche certifiée IP64.
•Homologué CE | Certifié UN38.3 | Garantie 12 mois.
PRÉSENTATION GENÉRALE
CARACTÉRISTIQUES
9
BP2607 - II BP2616 - II BP2624 - II
Tension 12V 12V 12V
Ampère-
heure 7Ah 16Ah 24Ah
Watt-heure 84Wh 192Wh 288Wh
Durée de
recharge
4-6 hrs
(4A Chargeur)
8-9 hrs
(4A Chargeur)
12-13 hrs
(4A Chargeur)
Intensité max-
imum
de décharge
10A 10A 10A
Intensité maxi-
mum (pendant
10 ms)
30A 40A 40A
Poids 0.99 kg 2.22 kg 2.9 kg
Dimensions 90 x 145
x 65 mm
125 x 175
x 80 mm
138 x 187
x 94 mm
CARACTÉRISTIQUES TECHNIQUES
10
CHARGE
CHARGE SUR LE SECTEUR:
Avertissement: utilisez uniquement le chargeur Tracer
LiFePO4remis avec cette batterie.
1.Branchez le chargeur sur le secteur et la LED
s’allume alors en vert.
2. Branchez correctement le conducteur du chargeur à
la batterie, la LED vire alors au rouge pour indiquer
que la recharge a commencé.
3.Lorsque la LED redevient verte, la batterie est
chargée au maximum.
4.Débranchez le chargeur du bloc batterie et du
secteur.
5.Ne laissez pas le chargeur branché au bloc-batterie
pendant de longues périodes après avoir chargé
ce dernier.
CHARGE SUR COURANT CONTINU EN VOITURE:
Un chargeur voiture (TR8180) adapté à une
alimentation en courant continu (survolteur-dévolteur)
est disponible à la vente sur le site
www.tracerpower.com
