TP-Link TL-SF1005D User manual

Description:

Features:

Up to 200Mbps full duplex bandwidth for high-speed

data processing

60% of power consumption

Auto MDI/MDIX eliminates the need for crossover

cables

Auto-Negotiation ports provide smart integration

IEEE 802.3x ow control provides reliable data transfer

Plug and play design simplies installation

Innovative energy-ecient technology saves up to

between 10Mbps and 100Mbps hardware

The 5-Port 10/100Mbps desktop switch TL-SF1005D provides an easy way to expand your wired network. All

5 ports support Auto MDI/MDIX, eliminating the need to worry about the type of cable to use. Featuring full

duplex mode, the TL-SF1005D canprocess data at a rate of up to 200Mbpsmaking it an ideal choice for

expanding your high performance wired network. Moreover, with innovative energy-efficient technology, the

TL-SF1005D can save up to 60% of power consumption, making it an eco-friendly solution for your home or

office network.

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

TL-SF1005D

5-Port 10/100Mbps Desktop Switch

5 10/100Mbps Ethernet ports

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

-SF1005D

5-Port 10/100Mbps Desktop Switch

Specifications:

Standards

Protocol

Interface

Switching Features

Forwarding Rates

Data Rates

LEDs

Transfer Method

Power Supply

Dimensions

Environment

IEEE 802.3, IEEE 802.3u, IEEE 802.3x

CSMA/CD

5 10/100Mbps ports, Auto-Negotiation, Auto MDI/MDIX

Half and Full Duplex

MAC Address Learning

1.0 Gbps Backplane Bandwidth

10BASE-T: 14880pps/port

100BASE-TX: 148800pps/port

10/100Mbps at Half Duplex

20/200Mbps at Full Duplex

Power, Ethernet Ports (1, 2, 3, 4, 5)

Store and Forward

External Power Adapter (Output: 5.0V/0.6A)

CE, FCC, RoHS

4.1 x 2.8 x 0.9 in. (103.5 x 70 x 22 mm)

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~70°C (-40°F~158°F)

Operating Humidity: 10% ~ 90%, non-condensing

Storage Humidity: 5%~90% non-condensing

Diagram:

Package:

- 5-Port 10/100Mbps Desktop Switch

TL-SF1005D

- Power Adapter

- User Guide

Related Products:

- 150Mbps Wireless N ADSL2+ Modem Router

TD-W8951ND

- 8-Port 10/100Mbps Desktop Switch

TL-SF1008D

- 5-Port Gigabit Desktop Switch

TL-SG1005D
