Toyota Corolla Verso User manual

Rica

bility

car measurement reference sheet

October 2005

Toyota Corolla Verso 1.8 VVT-i T3

5 door MPV

Space around the door and seat

SILL HEIGHT

To ground 377mm

To floor of car 120mm

DOOR OPENING ANGLE

Opening angle, including door pocket 67 degrees

SIZE OF DOOROPENING

Width at the bottom 718mm

Width in the middle 912mm

Height 200mm from back 1046mm

Height 400mm from back 978mm

DASHBOARD AND FASCIA

Passenger Driver

How far sticks out beyond door 220mm 223mm

Height of rear projection 470mm 470mm

SPACE AROUND THE SEAT

Passenger Driver

Back of seat to A post/dash 958mm 1013mm

Seat to sill 236mm 229mm

Seat to A post (fully forward) 295mm 310mm

Seat to A post (fully back) 496mm 517mm

Seat back to steering wheel (min) 205mm

Seat back to steering wheel (max) 526mm

Seat to steering wheel —Position 1 247mm

Seat to steering wheel —Position 2 173mm

Seat to steering wheel —Position 3 210mm

EDGE OF SEAT TO GROUND

Passenger Driver

Seat edge to ground (min) 635mm 637mm

Seat edge to ground (max) 668mm 671mm

HEADROOM

Passenger Driver

When getting in 772mm 781mm

When inside 1041mm1048mm

DOOR AND GRAB HANDLES

Passenger Driver

Interior door catch open grip open grip

Roof grab handle open grip open grip

sprung sprung

Seat back lever lever

LHS RHS

Rica

bility

car measurement reference sheet

October 2005

SILL HEIGHT

To ground 672mm

To floor of car 4mm

WIDTH OF OPENING

Width at bottom 1010mm

Width in the middle 1122mm

Width at top 975mm

HEIGHT OF OPENING

Top to bottom 858mm

Roof to floor 837mm

FLOOR LENGTH

Back row fully upright 213mm

Back row folded 885mm

Back and middle row folded 1680mm

FLOORWIDTH

Width at narrowest point 1060mm

FITTING IN AFOLDED WHEELCHAIR

Back row of seats upright

Parcel shelf in place

wheelchair flat no parcel shelf

wheelchair standing no parcel shelf

parcel shelf removed

wheelchair flat no

wheelchair standing no

Back row of seats folded

wheelchair flat facing sideways only

wheelchair standing facing sideways only

Back and middle row of seats folded

wheelchair flat yes

wheelchair standing yes

FITTING IN AN UNFOLDED WHEELCHAIR

Back row of seats upright

parcel shelf in place na

parcel shelf removed na

Back row of seats folded yes

Back and middle row of seats folded yes

Carrying space in the boot or hatch
