Toyota Coaster 2015 User manual

For your safety and comfort,

read carefully and keep in the vehicle.

Quick index

•If a service reminder indicator or warning buzzer comes on.......................... 43

•If your vehicle will not start............................................................................. 102

•If your engine stalls while driving ................................................................... 105

•If your vehicle overheats................................................................................ 106

•If you have a flat tire....................................................................................... 107

•If your vehicle needs to be towed................................................................... 119

•Tips for driving during break–in period........................................................... 76

•How to start the engine.................................................................................. 88

•Pre–trip safety check...................................................................................... 89

•Complete index.............................................................................................. 173

Gas station information

Fuel type:

Diesel fuel that contains 50 ppm or less of sulphur, cetane number 50 (cetane

index 45) or higher

See page 76 for detailed information.

Fuel tank capacity: 95 L (25.1 gal., 20.9 Imp. gal.)

Engine oil:

API CD, CE, CF, CH-4, CI-4 or CJ-4

ACEA E-3, E-4, E-5, E-6 or E-9

API CJ-4, ACEA E-6 or E-9 is preferred.

See page 143 for detailed information.

Tire information: See pages146 through 151.

Tire inflation pressure: See page 169.

Publication No. OM36689E

Part No. 01999-36689

Printed in Japan 01–1501–00

コースター (豪州E)Z

ワQ–8

DIC87 Black COASTER_36689E

NOT FOR REPRODUCTION

COASTER_AE

Foreword

Welcome to the growing group of value−conscious people who drive Toyotas. We

are proud of the advanced engineering and quality construction of each vehicle we

build.

This Owner’s Manual explains the operation of your new Toyota. Please read

it thoroughly and have all the occupants follow the instructions carefully.

Doing so will help you enjoy many years of safe and trouble−free motoring.

For important information about this manual and your Toyota, read the follow-

ing pages carefully.

When it comes to service, remember that your Toyota dealer knows your vehicle

very well and is interested in your complete satisfaction. Your Toyota dealer will

provide quality maintenance and any other assistance you may require.

Please leave this Owner’s Manual in this vehicle at the time of resale. The next

owner will need this information also.

All information and specifications in this manual are current at the time of printing.

However, because of Toyota’s policy of continual product improvement, we reserve

the right to make changes at any time without notice.

Please note that this manual applies to all models and explains all equipment,

including options. Therefore, you may find some explanations for equipment

not installed on your vehicle.

ã2015 TOYOTA MOTOR CORPORATION

part, without the written permission of Toyota Motor Corporation.

NOT FOR REPRODUCTION

COASTER_AE

Important information about this manual

Safety and vehicle damage warnings

Throughout this manual, you will see safety and vehicle dam-

age warnings. You must follow these warnings carefully to

avoid possible injury or damage.

The types of warnings, what they look like, and how they are

used in this manual are explained as follows:

CAUTION

This is a warning against anything which may cause

injury to people if the warning is ignored. You are

informed about what you must or must not do in order

to reduce the risk of injury to yourself and others.

NOTICE

This is a warning against anything which may cause

damage to the vehicle or its equipment if the warning

is ignored. You are informed about what you must or

must not do in order to avoid or reduce the risk of

damage to your vehicle and its equipment.

Safety symbol

When you see the safety symbol

shown above, it means: “Do not...”;

“Do not do this”; or “Do not let this

happen”.

NOT FOR REPRODUCTION

COASTER_AE

iii

Important information about your Toyota

Accessories, spare parts and

modification of your Toyota

A wide variety of non−genuine spare parts and accessories

for Toyota vehicles are currently available in the market.

Using these spare parts and accessories which are not

genuine Toyota products may adversely affect the safety of

your vehicle, even though these parts may be approved by

certain authorities in your country. Toyota therefore cannot

accept any liability or guarantee spare parts and accesso-

ries which are not genuine Toyota products, nor for re-

placement or installation involving such parts.

This vehicle should not be modified with non−genuine

Toyota products. Modification with non−genuine Toyota

products could affect its performance, safety or durabili-

ty, and may even violate governmental regulations. In

addition, damage or performance problems resulting from

the modification may not be covered under warranty.

Fuel information

Use only low sulphur diesel fuel (50 ppm or less of sul-

phur contents). See “Fuel” in Section 2 for details.

Installation of an

RF−transmitter system

As the installation of an RF−transmitter system in your

vehicle could affect electronic systems such as multiport

fuel injection system/sequential multiport fuel injection

system, electronic engine control system and anti−lock

brake system, be sure to check with your Toyota dealer

for precautionary measures or special instructions regard-

ing installation.

NOT FOR REPRODUCTION

COASTER_AE

Maintenance schedule

Please refer to the separate “Warranty and Service

Booklet”.

Operation of the power steering

When the steering wheel is turned to the extreme right or

left position, reduce the force applied and do not attempt

to turn it further. Applying excessive force to the steering

wheel may cause damage to its power steering mecha-

nism.

NOT FOR REPRODUCTION

COASTER_AE

1 OPERATION OF INSTRUMENTS AND CONTROLS Page

1 Overview of instruments and controls 1...........................

2 Keys and Doors 7.............................................

3 Seats, Seat belts, Steering wheel and Mirrors 21...................

4 Lights, Wipers and Defogger 33.................................

5 Gauges, Meters and Service reminder indicators 39................

6 Engine (ignition) switch, Transmission and Parking brake 49.........

7 Air conditioning system 57.....................................

8 Other equipment 69...........................................

2 INFORMATION BEFORE DRIVING YOUR TOYOTA 75............

3 STARTING AND DRIVING 87....................................

4 IN CASE OF AN EMERGENCY 101..............................

5 CORROSION PREVENTION AND APPEARANCE CARE 125......

6 MAINTENANCE REQUIREMENTS 131...........................

7DO−IT−YOURSELF MAINTENANCE

1 Introduction 135..............................................

2 Engine and Chassis 141.......................................

3 Electrical components 153.....................................

8 SPECIFICATIONS 165..........................................

9 INDEX 173.....................................................

Table of contents

NOT FOR REPRODUCTION

COASTER_AE

NOT FOR REPRODUCTION

COASTER_AE

OPERATION OF INSTRUMENTS AND

CONTROLS

Overview of instruments and controls

Instrument panel overview 2....................................

Instrument cluster overview 4...................................

Indicator symbols on the instrument panel 5......................

Finish

SECTION 1−1

NOT FOR REPRODUCTION

COASTER_AE

1. Side defroster outlet

2. Clock

3. Passengers’ door check mirror

4. Center vent

5. Instrument cluster

6. Side vents

7. Passengers’ door control switch

8. Power door lock switch

9. Fuel filler door opener

10. Parking brake lever

11. Manual transmission gear shift lever or

automatic transmission shift lever

12. Windshield washer fluid tank

Finish

Instrument panel overview

NOT FOR REPRODUCTION

COASTER_AE

1. Auxiliary box

2. Rear heater controls

3. Front heater controls

4. Emergency flasher switch

5. Front interior light switch

6. Rear interior light switch

7. Cooler controls

8. Wiper, washer and exhaust retarder

switches

9. Headlight and turn signal switches

10. Engine switch

11. Tilt and telescopic steering lock release

lever

12. DPF (Diesel Particulate Filter) system

manual regeneration switch

13. Rear window defogger switch

14. Ashtray

15. Cigarette lighter

16. Cup holder

Finish

NOT FOR REPRODUCTION
