Toyota AYGO - S User manual
AYGO
Brief Guide
1
Tab e of Contents
Accessing your vehicle 2 – 3
Electric windows 4
Steering wheel (Vehicles with an
adjustable type) 4
Seat and seat belt adjustment 5
Instrument Panel overview 6
Instrument Cluster 7
Clock 8
Lights 9
Wipers 10
Gear change 11
Heating and Air Conditioning 12
Fuel tank opening 13
Bonnet opening 14
Eco-Driving 15
Introducing AYGO
Thank you for buying an AYGO. We trust this Brief Guide will enable you to become familiar with
your vehicle’s basic operations and assist you in enjoying your vehicle.
This Brief Guide does not replace or substitute the Owner’s Manual, which you will find in the
vehicle’s glove compartment. It is important that you review the full Owner’s Manual as well as
any further supplementary manuals as this will allow you to familiarise yourself with the
operating and safety instructions and to handle the vehicle within its limitations.
Please do read all documents in your pack as this will ensure you get maximum performance
from your car and learn about related services offered.
Your Centre and everyone at Toyota wish you many years of enjoyable driving in your new
AYGO.
NB: All information contained in this Brief Guide are current at the time of printing. Toyota
reserves the right to make changes at any time without notice.
2
Accessing your vehic e
The door cannot be opened from inside the vehicle
when the lock is set.
These locks can be set to prevent children from
opening the rear doors. Slide on each rear door
switch to lock both rear doors.
Re r door child-protector lock (5-door
models only)
1. Locks all the doors.
2. Unlocks all the doors.
1. ey (with a wireless remote control function).
2. ey (without a wireless remote control function).
3. ey number plate.
Your key number is shown on the plate. If you should
lose your keys or if you need additional keys,
duplicates can be made using the key number.
3
The vehicle c n be locked nd unlocked using the key or wireless remote control
1. Locks the door.
2. Unlocks the door.
1. Unlocks the door.
2. Locks the door.
Door lock oper tion
Locking and unlocking with key. Locking and unlocking with button.
The wireless remote control system can lock or unlock
all the side doors and back door from a distance
within approximately 1m of the vehicle.
Driver's door
Without a power door lock system.
1. Locks the door.
2. Unlocks the door.
With power door lock system.
1. Locks all the doors.
2. Unlocks all the doors.
4
E ectric windows
Steering whee
(Vehic es with an adjustab e type)
To change the steering wheel angle, hold the steering
wheel, push down the lock release lever, tilt the
steering wheel to the desired angle and return the
lever to its original position.
Tilt steering wheel
The power windows can be opened and closed using the switches.
Oper ting the switch moves the windows
s follows:
1. Closing
2. Opening
The steering wheel must not be djusted while the vehicle is in motion.
5
To fasten your belt, pull it out of the retractor and
insert the tab into the buckle.
You will hear a click when the tab locks into the
buckle.
The seat belt length automatically adjusts to your size
and the seat position.
Seat and seat be t adjustment
M ke sure th t ll occup nts re we ring their
se t belts before driving the vehicle.
Se t belts
1. Seat position adjusting lever
Pull the lever up. Then slide the seat to the desired
position with slight body pressure and release the
lever.
2. Seatback angle adjusting lever
Lean forward and pull the lever backward. Then
lean back to the desired angle and release the
lever.
1. Push the head restraints to the lowest position.
2. Unlock and fold down the seatback while pulling
the straps.
Adjusting front se ts Fold-down re r se t
Split rear seat
Non-split rear seats
6
Instrument Pane Overview
Gauges and meters
SRS front passenger airbag
Outside rear view mirror
remote control levers
Bonnet lock
release lever
A. Heating and A/C controls (page 12).
Windscreen wipers and washer switch
Rear window wiper and washer switch
Headlight switch
Turn signal lever
Fog light switch
Engine (ignition) switch
7
Instrument C uster
Brake system warning
light
Anti-lock brake system
warning light
Discharge
warning light
Low engine oil pressure
warning light
Malfunction indicator
lamp
“STOP” warning light Power steering system
warning light
Low fuel level indicator
light
Engine coolant high
temperature warning
light
Engine preheating
indicator light (Diesel
models only)
Fuel filter warning light
(Diesel models only)
SRS warning light Driver’s and front
passenger’s seat belt
reminder light
Turn signal indicator
lights
Headlight low beam
indicator light
Headlight high beam
indicator light
Rear fog light indicator
light
Multi-mode manual
transmission warning
light*
Vehicle stability control
system/
traction control system
warning light*
Slip indicator light*
*on some models
1. Tachometer (If equipped).
2. Speedometer.
3. Fuel gauge.
4. Odometer and trip meter.
5. Odometer/trip meter display change button.
M in indic tor symbols nd w rning lights
8
C ock
Press and hold the “CLOC ” button until you hear a
beep.
1. Adjust the hours.
2. Adjust the minutes.
Type A (On some models)
Press the “MENU” button;
press the (Config).
press the (Time).
Type B (On some models)
1. Adjust the hours.
2. Adjust the minutes.
3. 12/24 H display change button.
