Toyota AVALON - 2011 User manual

QUICK REFERENCE

GUIDE

AVALON

2011

414590M1 1 2/11/10 5:48 PM

Information Provided by:

2011

Avalon

!A word about safe vehicle operations

This Quick Reference Guide is a summary of basic vehicle

operations. It contains brief descriptions of fundamental

operations so you can locate and use the vehicle’s main

equipment quickly and easily.

The Quick Reference Guide is not intended as a substitute for

the Owner’s Manual located in your vehicle’s glove box. We

strongly encourage you to review the Owner’s Manual and

supplementary manuals so you will have a better understanding

of your vehicle’s capabilities and limitations.

Your dealership and the entire staff of Toyota Motor Sales,

U.S.A., Inc. wish you many years of satisfied driving in your

new Avalon.

This Quick Reference Guide is not a full description of Avalon

operations. Every Avalon owner should review the Owner’s

Manual that accompanies this vehicle.

Pay special attention to the boxed information highlighted in

color throughout the Owner’s Manual. Each box contains safe

operating instructions to help you avoid injury or equipment

malfunction.

All information in this Quick Reference Guide is current at

the time of printing. Toyota reserves the right to make

changes at any time without notice.

Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

INDEX

Engine maintenance 9

Fuel tank door release and cap 8

Hood release 9

Indicator symbols 4-5

Instrument cluster 4

Instrument panel 2-3

Keyless entry16

Light control-Instrument panel 8

Smart Key system27

Trunk release 8

Air Conditioning/Heating 20

Audio 18-19

Auto lock functions210

Automatic Transmission 10

Clock 21

Cruise control 15

Cup holders 22

Door locks 10

Garage door opener (HomeLink®)315

Lights1& turn signals 13

Moonroof 17

Multi-information display 17

Parking brake 11

Power outlets 22

Seat adjustments-Front 12

Seat adjustments-Rear 12

Seat ventilators/Heaters 21

Seats-Head restraints 12

Steering lock release 11

Steering wheel switches 19

Sunshade-Rear116

Telephone controls (Bluetooth®)16

Tilt and telescopic steering wheel 11

Windows-Power 14

Windshield wipers & washers114

Doors-Child safety locks 23

Seat belt comfort guide 24

Seat belts 23

Seat belts-Shoulder belt anchor 23

Spare tire & tools 25

Tire Pressure Monitoring (warning) System 24

Trunk-Internal release 25

OVERVIEW

FEATURES/OPERATIONS

SAFETY AND

EMERGENCY FEATURES

1 Visit your Toyota dealer for information on customizing this feature.

2 Programmable by customer. Refer to the Owner’s Manual for instructions and

more information.

3HomeLink®is a registered trademark of Johnson Controls, Inc.

Information Provided by:

Steering wheel controls

OVERVIEW

Instrument panel

Steering wheel audio controls

Telephone controls1

Steering wheel climate controls

Ignition switch (standard key)1

Voice command button1

Multi-information display button

Driving position memory switches1

Headlight, turn signal and front fog light controls

“ENGINE START STOP” button (Smart Key)1

Wiper and washer controls

Clock

Emergency flasher button

Audio system/Navigation system1,2

Air Conditioning controls

Outside rearview mirror1/Rear window defogger button

Storage compartment

Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Cruise control

Tire Pressure Monitoring (warning) System reset

Tilt lock release lever

Telescopic lock release

Power rearview mirror control

VSC OFF switch

Glass breakage sensor1

Rear sunshade switch1

Trunk opener

Fuel filler door opener

1If equipped

2For details, refer to the “Navigation System Owner’s Manual.”

Information Provided by:

OVERVIEW

Indicator symbols

Instrument cluster

Engine coolant temperature

Tachometer

Service indicator and reminder

Speedometer

Fuel gauge

Odometer/Trip meter and trip meter reset button

Odometer/Trip meter display

Automatic Transmission shift position indicator

Multi-information display

Charging system warning1

Brake system warning1

1If indicator does not turn off within a few seconds of starting engine, there may

be a malfunction. Have vehicle inspected by your Toyota dealer.

Driver seat belt reminder

(alarm will sound if speed is over 9 mph)

Front passenger seat belt reminder

(alarm will sound if speed is over 9 mph)

Low engine oil pressure warning1

Front passenger occupant classification indicator/

Front passenger airbag ON/OFF indicator

For details, refer to “Indicators and warning lights,” Section 2-2, 2011

Owner’s Manual.

Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Anti-lock Brake System warning1

Headlight low/high beam indicator

Turn signal indicator

Slip indicator1

Vehicle Stability Control OFF indicator1

Cruise control indicator2

Tire Pressure Warning1

Security indicator

Open door warning

Airbag SRS warning1

Low windshield washer fluid level warning1

Malfunction/Check Engine indicator1

Engine oil replacement reminder1

Low fuel level warning

Automatic headlight leveling system warning1

Smart Key system warning1

2If this light flashes, refer to “Cruise control,” Section 2-4, 2011 Owner’s Manual.

Traction Control OFF indicator

Cruise control SET indicator2

Information Provided by:

OVERVIEW

Keyless entry

Push

Push ONCE: Driver door

TWICE: All doors

Locking operation

Unlocking operation

Without Smart Key system With Smart Key system

Trunk lid operation

Panic button

Push and hold

NOTE: If a door is not opened within 60 seconds of unlocking, all doors will

relock for safety.

Without Smart Key system With Smart Key system

Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Smart Key system (if equipped)

Start function

NOTE: Gear shift lever must be in Park and brake pedal depressed.

Push

Depress

brake pedal

Carrying

Green indicator ON

Without depressing the brake pedal, pressing the “ENGINE START STOP”

switch will change the operation mode in succession from:

Power (without starting engine)

* Driver door unlocking function can be programmed to unlock driver door

only, or all doors. Grasping passenger door handle will unlock all doors.

NOTE: Doors may also be locked/unlocked using remote.

Accessories such as the radio will operate.

Power ON; the engine not running.

All systems OFF.

ACC

OFF

Trunk access

Opening trunk

Locking operation Unlocking operation

Carry remote to lock Carry remote to unlock

Front door lock Front door unlock*

Push

Grasp

Push

Carry remote

to lock/unlock

Information Provided by:

Fuel tank door release and cap

NOTE: Tighten until one click is

heard. If the cap is not tightened

enough, Check Engine “ ”

indicator may illuminate.

Push

Tu r n

Store

Light control-Instrument panel

Brightness

control -+

Trunk release

Push

Trunk opener

OVERVIEW

Information Provided by:
