Foreword

Welcome to the growing group of value–conscious people who drive Toyotas. We are proud of the advanced engineering and

quality construction of each vehicle we build.

This Owner’s Manual explains the operation of your new Toyota. Please read it thoroughly and have all the occupants

follow the instructions carefully. Doing so will help you enjoy many years of safe and trouble–free motoring. For

important information about this manual and your Toyota, read the following pages carefully.

When it comes to service, remember that your Toyota dealer knows your vehicle best and is interested in your complete

satisfaction. He will provide quality maintenance and any other assistance you may require.

If there is not a Toyota dealer near you, or you need emergency assistance for any reason, please call the following number:

!U.S. OWNERS: Toyota Customer Assistance Center Toll–free:1–800–331–4331

!CANADIAN OWNERS: Toyota Canada Customer Interaction Centre Toll–free:1–888–TOYOTA–8 (1–888–869–6828)

Please leave this Owner’s Manual in this vehicle at the time of resale. The next owner will need this information also.

All information and specifications in this manual are current at the time of printing. However, because of Toyota’s policy of

continual product improvement, we reserve the right to make changes at any time without notice.

Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may

find some explanations for equipment not installed on your vehicle.

2001 TOYOTA MOTOR CORPORATION

Motor Corporation.

2002MY ECHO U L/O0109

ii 2002 ECHO (OM52463U)

Important information about this manual

Safety and vehicle damage warnings

Throughout this manual, you will see safety and vehicle

damage warnings. You must follow these warnings carefully

to avoid possible injury or damage.

The types of warnings, what they look like, and how they

are used in this manual are explained as follows.

CAUTION

This is a warning against something which may cause

injury to people if the warning is ignored. You are

informed about what you must or must not do in

order to avoid or reduce the risk to yourself and other

people.

NOTICE

This is a warning against something which may cause

damage to the vehicle or its equipment if the warning

is ignored. You are informed what you must or must

not do in order to avoid or reduce the risk of damage

to your vehicle and its equipment.

Safety symbol

When you see the safety symbol

shown above, it means: “Do not...”;

“Do not do this”; or “Do not let this

happen”.

2002MY ECHO U L/O0109

iii 2002 ECHO (OM52463U)

Important information about your Toyota

New vehicle warranty

Your new vehicle is covered by the following Toyota

limited warranties:

!New vehicle warranty

!Emission control systems warranty

!Others

For further information, please refer to the “Owner’s

Warranty Information Booklet” or “Owner’s Manual

Supplement”.

Your responsibility for maintenance

It is the owner’s responsibility to make sure that the

specified maintenance is performed. Section 6 gives de-

tails of these maintenance requirements. Also included

in Section 6 is general maintenance. For scheduled

maintenance information, please refer to the “Scheduled

Maintenance Guide” or “Owner’s Manual Supplement”.

Accessories, spare parts and modifi-

cation of your Toyota

A wide variety of non–genuine spare parts and accesso-

ries for Toyota vehicles are currently available in the

market. You should know that Toyota does not warrant

these products and is not responsible for their perfor-

mance, repair, or replacement, or for any damage they

may cause to, or adverse effect they may have on,

your Toyota vehicle.

This vehicle should not be modified with non–genuine

To y ot a p r o du c t s . M o di f i c a t i o n w i t h n o n– g en u i ne Toy o t a

products could affect its performance, safety or durabili-

ty, and may even violate governmental regulations. In

addition, damage or performance problems resulting from

the modification may not be covered under warranty.

2002MY ECHO U L/O0109

iv 2002 ECHO (OM52463U)

Spark ignition system of your Toyo-

The spark ignition system in your Toyota meets all re-

quirements of the Canadian Interference–Causing Equip-

ment Standard.

Installation of a mobile two–way ra-

dio system

As the installation of a mobile two–way radio system in

your vehicle could affect electronic systems such as

multiport fuel injection system/sequential multiport fuel

injection system, cruise control system, anti–lock brake

system, SRS airbag system and seat belt pretensioner

system, be sure to check with your Toyota dealer for

precautionary measures or special instructions regarding

installation.

Scrapping of your Toyota

The SRS airbag and seat belt pretensioner devices in

your Toyota contain explosive chemicals. If the vehicle

is scrapped with the airbags and pretensioners left as

they are, it may cause an accident such as a fire. Be

sure to have the systems of the SRS airbag and seat

belt pretensioner removed and disposed of by the quali-

fied service shop or by your Toyota dealer before you

dispose of your vehicle.

2002MY ECHO U L/O0109

2002 ECHO (OM52463U)

Publication No. OM52463U

Part No. 01999-52463

Printed in Japan 01- 0109- 00

Quick index

!If a service reminder indicator or warning buzzer comes on 154. . . . . . .

!If your vehicle will not start 296. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!If your engine stalls while driving 299. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!If your vehicle overheats 299. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!If you have a flat tire 300. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!If your vehicle needs to be towed 308. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!Tips for driving during break-in period 252. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!How to start the engine 280. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!General maintenance 345. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!Complete index NO TAG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Gas station information

Fuel type:

UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)

or higher

See page 252 for detailed information.

Fuel tank capacity:

45 L (11.9 gal., 9.9 lmp.gal.)

Engine oil:

API grade SJ “Energy- Conserving”, SL “Energy- Conserving” or ILSAC

multigrade engine oil is recommended.

See page 372 for detailed information.

Automatic transmission fluid:

Automatic transmission fluid Type T- IV

See page 418 for detailed information.

Tire information: See pages 377 through 381.

Tire pressure: See page 419.

2002MY ECHO (U) L/O0109

2002 ECHO (OM52463U)

OPERATION OF INSTRUMENTS AND

CONTROLS

Overview of instruments and controls

Instrument panel overview 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Instrument cluster overview 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Indicator symbols on the instrument panel 5. . . . . . . . . . . . . . . . . . . . . . .

SECTION

–

2001MY ECHO (U) L/O0008

22002 ECHO (OM52463U)

Instrument panel overview

1. Side vents

2. Instrument cluster

3. Center vents

4. Rear view mirror remote control levers

5. Auxiliary box

6. Power door lock switches

(with power windows)

7. Power window switches

8. Glove box

9. Automatic transmission selector lever or

manual transmission gear shift lever

10. Parking brake lever

11. Power door lock switch

(without power windows)

12. Hood lock release lever

13. Window lock switch

SU11001

2002MY ECHO (U) L/O0109

2002 ECHO (OM52463U)

1. Headlight and turn signal switch

2. Wiper and washer switches

3. Rear window defogger switch

4. Emergency flasher switch

5. Clock

6. Air conditioning controls

7. Security indicator light/Front passenger’s

seat belt reminder light

8. Car audio

9. Cigarette lighter/Power outlet

10. Ashtray/Coin box

11. Ignition switch

12. Tilt steering lock release lever

13. Instrument panel light control knob

SU11002

2001MY ECHO (U) L/O0008

42002 ECHO (OM52463U)

SU11007

1. Service reminder indicators and

indicator lights

2. Speedometer

3. Fuel gauge

4. Odometer and two trip meters

5. Trip meter reset knob

Instrument cluster overview

2002MY ECHO (U) L/O0109

2002 ECHO (OM52463U)

Indicator symbols on the instrument panel

or Brake system warning light∗

Driver’s seat belt reminder light∗

Discharge warning light∗

Malfunction indicator lamp∗

Low engine oil pressure warning light∗

Anti-lock brake system warning light∗

SRS warning light∗

Low windshield washer fluid level warning light∗

Low fuel level warning light∗

Turn signal indicator lights

Headlight high beam indicator light

Overdrive–off indicator light

Low engine coolant temperature indicator light

(in blue)∗

High engine coolant temperature warning light

(in red)∗

Front passenger’s seat belt reminder light∗

Open door warning light∗

∗: For details, see “Service reminder indicators and warning

buzzers” in Section 1–5.
