Totemtek AT09 User manual
AT09 4G Quick Start Guide
Please Make sure you have download below docs
before you start:
1. AT09 online document support:
https://en.totemtek.com/support/documents/gps-tracker-at09/
--- User manual, configurator, configuration manual.
2. AT09 online video reference:
https://en.totemtek.com/category/blog/video/
Use a pin to push the SIM drawer
out, and put SIM inside the device.
1
Switch on the device
switch to right side.
2
connect device to PC with
configurator via micro USB.
3
Connect GSM and GPS
antenna, put GPS
antenna open to sky.
4
Connect desired IO
port for data collection
and finish the installation
5
PIN 8: color: Red - VCC
PIN 7: color: Black - GND
Power / Ignition detection / cut engine
Emergency button (SOS)
PIN 13: color: Brown- ACC+
PIN 11: color: Orange - DO A (-)
PIN 15: color: black - SOS
PIN 16: color: red - SOS
PIN 1:
PIN 9:
PIN 2:
PIN 10:
Relay
Oil pump
L
O
C
K
A
C
C
O
N
S
T
A
R
T
Storage
battery
/
Fuse
color: black with gray strip - ANI 2
color: gray with black strip - ANI 4
color: yellow - ANI 1
color: gray - ANI 3
12V / 24V
ignition detection
remote cut off
Order Number: relay
Maximum length: 3000mm
ANI input for Fuel level detection / voltage collection
Fuel level detection / iButtion identification
DI input for door detection
Negative trigger
camera (picture purpose only) RS485 fuel sensor
Positive trigger
Door positive
trigger connection
Door light
Door switch
12V
Door negative
trigger connection
Door light
Door switch
Section A
www.totemtek.com [email protected]
external door sensor
Ver: EN 1.0
Date: 2022-12-20
standard USB cable
Configurator
PIN 3:
PIN 12:
color: purple - DO B(-)
color: white- DO C(-)
PIN 4: color: blue - DO D(-)
Cut able Capacitor Fuel sensor
12V
Audio alarm buzzervisible alarm buzzer
12V
PIN 5:
PIN 14:
color: white with black strip - DI2 (+)
PIN 6: color: yellow with green strip - DI4 (-)
color: green - DI3 (-)
Section A
RS232_TX1
RS232_RX1
RS232_TX2
RS232_RX2
PIN 4:
PIN 8:
PIN 3:
PIN 7:
RS485 A
5V
RS485 B
GND
PIN 2:
PIN 5:
PIN 6:
PIN 1:
Section B
12V / 24V
USB
Red: PWR
Green: GSM
Blue: GPS
LEDs {
push yellow button
Model
:
CAUTION: Inward power DC 5V
AT08 3G
TPMS
LORA
RS485
RS232
MIC
SPK
CAN
TTL
1WIRE
1WIRE
SECTION B
ANI - OUTPUT - INPUT - PWR
SECTION A
Vehicle Tracking Locator
Model: AT09
CAUTION: Inward power DC 12 ~ 50V
GSM GPS
USB
OFF ON
SIM
GSM GPS
Section A
Section B
Section B
1 2 3 4
1
1 2 3 4
5 6 78
(this IO is duplicated using with TTL-TX)
(this IO is duplicated using with BLE_module)
(this IO is duplicated using with TTL-RX)
(this IO is duplicated using with BLE_module)
1
9
2
10
3
11
4
12
5
13
6
14
7
15
8
16
Section A
USB
Section A
RS232 port can connect with different accessories with variant firmware version.
Accessory will come with the proper connector to plug into AT09 device.
if the device is WIFI/BLE version, there is no extra external antenna required.
Both device antenna is on board or has installed before out of the factory.
Standard package: AT09 4G device, section A cable, GPS antenna, GSM antenna,
TPMS antenna ( TPMS version only)
433Mhz antenna for AT09
TPMS/LORA version only.
all the accessories mentioned here is NOT including in the standard package.
Section B
Speaker
Microphone
Speaker
mic
MIC
Speaker
PIN 1:
PIN 2:
PIN 3:
PIN 4:
Connect the TPMS antenna
f if your device is TPMS version
device.
6
www.totemtek.com
Car door with circuit For truck door without circuit
temperature sensor
cable up to 15 meter
iButton reader
2
TTL_RX
CAN_H
CAN_L
TTL_TX
PIN 1:
PIN 2:
PIN 3:
PIN 4:
3
GND
3V3
1-WIRE_1
1_WIRE_2
PIN 1:
PIN 2:
PIN 3:
PIN 4:
4
1 2
3 4
1 2
3 4
1 2
3 4
(this IO is duplicated using with RS232_TX1)
(this IO is duplicated using with RS232_RX1)
1 2 3 4
433Mhz antenna
for tyre sensor.
