Satellite®L640 Series

Resource Guide

Keep this Resource Guide in a convenient place to access important

information about your computer. To obtain additional information,

consult the comprehensive electronic User’s Guide preinstalled on

your computer (click Start, All Programs, My Toshiba, and then

User’s Guide).

If you need assistance:

❖Toshiba’s Support Web site

pcsupport.toshiba.com

❖Toshiba Customer Support Center

Calling within the United States (800) 457-7777

Calling from outside the United States (949) 859-4273

Please fill in for your reference and future use:

Model name______________________________________

Part number______________________________________

Serial number____________________________________

RG 5.375 x 8.375 ver 2.3.2

Contents

Introduction...................................................................................... 10

Setting up your computer and getting started................................... 13

Creating recovery DVDs/media ......................................................... 16

Learning the basics........................................................................... 17

Using the TouchPad™....................................................................... 18

Using the optical disc drive............................................................... 20

Using the Web Camera ..................................................................... 24

Using the Memory card reader ......................................................... 24

Moving the computer........................................................................ 26

Mobile computing............................................................................. 26

Taking care of your battery ............................................................... 30

If something goes wrong.................................................................. 32

If you need further assistance........................................................... 35

Power cord/cable connectors ........................................................... 36

Features and specifications............................................................... 36

5.375 x 8.375 ver 3.1

Handling the cord on this product will expose you to lead, a chemical known

to the State of California to cause birth defects or other reproductive harm.

Wash hands after handling.

Model: Satellite®L640 Series

Recordable and/or ReWritable Drive(s) and

Associated Software Warranty

The computer system you purchased may include Recordable and/or

ReWritable optical media drive(s) and associated software, among the most

advanced data storage technologies available. As with any new technology,

you must read and follow all set-up and usage instructions in the applicable

user guides and/or manuals enclosed or provided electronically. If you fail

to do so, this product may not function properly and you may lose data or

suffer other damage. TOSHIBA AMERICA INFORMATION SYSTEMS,

INC. (“TOSHIBA”), ITS AFFILIATES AND SUPPLIERS DO NOT

WARRANT THAT OPERATION OF THE PRODUCT WILL BE

UNINTERRUPTED OR ERROR FREE. YOU AGREE THAT TOSHIBA,

ITS AFFILIATES AND SUPPLIERS SHALL HAVE NO

RESPONSIBILITY FOR DAMAGE TO OR LOSS OF ANY BUSINESS,

PROFITS, PROGRAMS, DATA, NETWORK SYSTEMS OR

REMOVABLE STORAGE MEDIA ARISING OUT OF OR RESULTING

FROM THE USE OF THE PRODUCT, EVEN IF ADVISED OF THE

POSSIBILITY THEREOF.

Protection of Stored Data

For your important data, please make periodic back-up copies of all the

data stored on the hard disk or other storage devices as a precaution against

possible failures, alteration, or loss of the data. IF YOUR DATA IS

ALTERED OR LOST DUE TO ANY TROUBLE, FAILURE OR

MALFUNCTION OF THE HARD DISK DRIVE OR OTHER

STORAGE DEVICES AND THE DATA CANNOT BE RECOVERED,

TOSHIBA SHALL NOT BE LIABLE FOR ANY DAMAGE OR LOSS

OF DATA, OR ANY OTHER DAMAGE RESULTING

THEREFROM. WHEN COPYING OR TRANSFERRING YOUR

DATA, PLEASE BE SURE TO CONFIRM WHETHER THE DATA

HAS BEEN SUCCESSFULLY COPIED OR TRANSFERRED.

TOSHIBA DISCLAIMS ANY LIABILITY FOR THE FAILURE TO

COPY OR TRANSFER THE DATA CORRECTLY.

5.375 x 8.375 ver 3.1

Critical Applications

The computer you have purchased is not designed for any “critical

applications.” “Critical applications” means life support systems, medical

applications, connections to implanted medical devices, commercial

transportation, nuclear facilities or systems or any other applications where

product failure could lead to injury to persons or loss of life or catastrophic

property damage. ACCORDINGLY, TOSHIBA, ITS AFFILIATES

AND SUPPLIERS DISCLAIM ANY AND ALL LIABILITY

ARISING OUT OF THE USE OF THE COMPUTER PRODUCTS IN

ANY CRITICAL APPLICATIONS. IF YOU USE THE COMPUTER

PRODUCTS IN A CRITICAL APPLICATION, YOU, AND NOT

TOSHIBA, ASSUME FULL RESPONSIBILITY FOR SUCH USE.

EU Declaration of Conformity

TOSHIBA declares that this product conforms to the following Standards:

This product is carrying the CE-Mark in accordance with the related

European Directives. The party responsible for CE-Marking is TOSHIBA

Europe GmbH, Hammfelddamm 8, 41460 Neuss, Germany.

The European Union WEEE (Waste from Electrical and

Electronic Equipment) Directive Information

The European Union WEEE (Waste from Electrical and Electronic Equipment)

Directive is intended to protect the quality of the environment and human health

through the responsible use of natural resources and the adoption of waste

management strategies that focus on recycling and reuse. This Directive requires

producers of electrical and electronic products put on the market in European

Union (EU) member countries after August 2005 to mark such products with a

crossed-out wheeled bin with a black bar symbol. If the product’s battery or

accumulator contains more than the specified values of lead (Pb), mercury (Hg),

and/or cadmium (Cd) defined in the Battery Directive (2006/66/EC), then the

chemical symbols for lead (Pb), mercury (Hg) and/or cadmium (Cd) will appear

below the crossed out wheeled bin symbol on the battery.

Supplementary

Information: *The product complies with the

requirements of the Low Voltage

Directive 73/23/EEC, the EMC Directive

89/336/EEC and/or the R&TTE

Directive 1999/5/EC.

Pb, Hg, Cd

5.375 x 8.375 ver 3.1

In the European Union, these symbols indicate that when the last end user wishes

to discard this product, it must be sent to appropriate facilities for recovery and

recycling. This Directive applies to EU member countries only and does not

apply to end users in other countries such as the United States.

Although the initial emphasis is in Europe, Toshiba is already working with

design engineers, suppliers, and other partners to determine appropriate

worldwide product life cycle planning and end-of-life strategies for our products.

Please contact your local government for applicable laws and regulations

governing the disposal of this product. For information on how to trade-in or

recycle your product, visit www.reuse.toshiba.com.

VCCI Class B Information

Modem Warning Notice

This information is only applicable if your computer has a modem.

Conformity Statement

The equipment has been approved to [Commission Decision “CTR21”] for

pan-European single terminal connection to the Public Switched Telephone

Network (PSTN).

However, due to differences between the individual PSTNs provided in

different countries/regions the approval does not, of itself, give an

unconditional assurance of successful operation on every PSTN network

termination point.

In the event of problems, you should contact your equipment supplier in the

first instance.

Taiwan

The legal communications mentioned in the above item refer to radio

communications operated in accordance with telecommunication laws and

regulations.

Article 14 Unless approved, for any model accredited low power radio frequency electric

machinery, any company, trader or user shall not change the frequency,

increase the power or change the features and functions of the original design.

Article 17 Any use of low power radio frequency electric machinery shall not affect

aviation safety and interfere with legal communications. In the event

interference is caused, the use of such electric machinery shall be immediately

discontinued. Operation of such products can be resumed only when they are

modified and can no longer cause interference.

5.375 x 8.375 ver 3.1

Low power radio frequency electric machinery shall resist against

interference from legal communications or from industrial, scientific and

medical radio emission electric machinery.

Using this Equipment in Japan

In Japan, the frequency bandwidth of 2,400 MHz to 2,483.5 MHz for

second generation low-power data communication systems such as this

equipment overlaps that of mobile object identification systems (premises

radio station and specified low-power radio station).

1. Sticker

Please put the following sticker on devices incorporating this product.

2. Indication

The indication shown below appears on this equipment.

12.4: This equipment uses a frequency of 2.4 GHz.

2DS: This equipment uses DS-SS modulation.

OF: This equipment uses OFDM modulation.

3The interference range of this equipment is less than 40m.

4This equipment uses a frequency bandwidth from

2,400 MHz to 2,483.5 MHz.

It is possible to avoid the band of mobile object identification systems.

The indication shown below appears on this equipment.

12.4: This equipment uses a frequency of 2.4 GHz.

2FH: This equipment uses FH-SS modulation.

The frequency bandwidth of this equipment may operate within the

same range as industrial devices, scientific devices, medical

devices, microwave ovens, licensed radio stations and non-licensed

specified low-power radio stations for mobile object identification

systems (RFID) used in factory product lines (Other Radio Stations).

1. Before using this equipment, ensure that it does not interfere with

any of the equipment listed above.

2. If this equipment causes RF interference to other radio stations,

promptly change the frequency being used, change the location

of use, or turn off the source of emissions.

3. Contact TOSHIBA Direct PC if you have problems with interference

caused by this product to Other Radio Stations.

2.4DSOF4

(1) (2) (3)

(4)

2.4FH1

(1) (2) (3)

(4)

5.375 x 8.375 ver 3.1

3The interference range of this equipment is less than 10m.

4This equipment uses a frequency bandwidth from 2,400 MHz to

2,483.5 MHz.

3. TOSHIBA Direct PC

Monday – Friday: 10:00 – 17:00

Toll Free Tel: 0120-15-1048

Direct Dial: 03-3457-4850

Fax: 03-3457-4868

Device Authorization

This device obtains the Technical Regulation Conformity Certification and

the Technical Conditions Compliance Approval, and it belongs to the

device class of radio equipment of low-power data communication system

radio station stipulated in the Radio Law and the Telecommunications

Business Law of Japan.

The name of the radio equipment: refer to the equipment label provided on

the computer

Approved by both the JAPAN APPROVALS INSTITUTE FOR

TELECOMMUNICATIONS EQUIPMENT and the TELECOM

ENGINEERING CENTER

The following restrictions apply:

❖Do not disassemble or modify the device.

❖Do not install the embedded wireless module into other device.

❖5.17 GHz to 5.23 GHz for indoor use only.

Regulatory statements

This product complies with any mandatory product specification in any

country/region where the product is sold. In addition, the product complies

with the following:

European Union (EU) and EFTA

This equipment complies with the R&TTE directive 1999/5/EC and has

been provided with the CE mark accordingly.

Canada — Industry Canada (IC)

This device complies with RSS 210 of Industry Canada.

5.375 x 8.375 ver 3.1

Taiwan

The legal communications mentioned in the above item refer to radio

communications operated in accordance with telecommunication laws and

regulations.

Low power radio frequency electric machinery shall resist against

interference from legal communications or from industrial, scientific and

medical radio emission electric machinery.

Optical Disc Drive Safety Instructions

This appliance contains a laser system and is classified as a CLASS 1

LASER PRODUCT. To use this model properly, read the user’s guide

carefully and keep it for your future reference.

Never attempt to disassemble, adjust or repair an optical disc drive. You

could damage the drive. You would also be exposed to laser light or other

safety hazards, resulting in serious injury. Always contact an authorized

Toshiba service provider, if any repair or adjustment is required.

Location of the Required Label

(Sample shown below. Location of the label and manufacturing

information may vary.)

Article 14 Unless approved, for any model accredited low power radio frequency

electric machinery, any company, trader or user shall not change the

frequency, increase the power or change the features and functions of the

original design.

Article 17 Any use of low power radio frequency electric machinery shall not affect

aviation safety and interfere with legal communications. In the event

interference is caused, the use of such electric machinery shall be

immediately discontinued. Operation of such products can be resumed

only when they are modified and can no longer cause interference.

5.375 x 8.375 ver 3.1

This guide is copyrighted by Toshiba America Information Systems, Inc.

reproduced in any form without the prior written permission of Toshiba. No

patent liability is assumed, however, with respect to the use of the

information contained herein.

Export Administration Regulation

This document contains technical data that may be controlled under the

U.S. Export Administration Regulations, and may be subject to the

approval of the U.S. Department of Commerce prior to export. Any export,

directly or indirectly, in contravention of the U.S. Export Administration

Regulations is prohibited.

Notice

The information contained in this manual, including but not limited to any

product specifications, is subject to change without notice.

TOSHIBA CORPORATION AND TOSHIBA AMERICA

INFORMATION SYSTEMS, INC. (TOSHIBA) PROVIDES NO

WARRANTY WITH REGARD TO THIS MANUAL OR ANY OTHER

INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY

DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY

OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO

ANY OF THE FOREGOING. TOSHIBA ASSUMES NO LIABILITY

FOR ANY DAMAGES INCURRED DIRECTLY OR INDIRECTLY

FROM ANY TECHNICAL OR TYPOGRAPHICAL ERRORS OR

OMISSIONS CONTAINED HEREIN OR FOR DISCREPANCIES

BETWEEN THE PRODUCT AND THE MANUAL. IN NO EVENT

SHALL TOSHIBA BE LIABLE FOR ANY INCIDENTAL,

CONSEQUENTIAL, SPECIAL, OR EXEMPLARY DAMAGES,

WHETHER BASED ON TORT, CONTRACT OR OTHERWISE,

ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL OR

ANY OTHER INFORMATION CONTAINED HEREIN OR THE USE

THEREOF.

10 Introduction

5.375 x 8.375 ver 3.1

Trademarks

Satellite is a registered trademark of Toshiba America Information Systems, Inc.

and/or Toshiba Corporation.

Blu-ray Disc is a trademark of the BD Association.

Memory Stick, Memory Stick Pro, and Memory Stick PRO Duo are trademarks

or registered trademarks of Sony Corporation.

Microsoft, Outlook, Windows, and Windows Media are either registered

trademarks or trademarks of Microsoft Corporation in the United States and/or

other countries.

MultiMediaCard and MMC are registered trademarks of MultiMediaCard

Association.

Secure Digital and SD are trademarks of SD Card Association.

TouchPad is a trademark of Synaptics, Inc.

All other brand and product names are trademarks or registered trademarks of

their respective companies.

Computer Disposal Information

The LCD display lamp in this product may contain mercury. Disposal of

this product may be regulated due to environmental considerations. For

disposal, reuse or recycling information, please contact your local

government or the Electronic Industries Alliance at www.eiae.org.

As part of Toshiba’s commitment to preserving the environment, Toshiba

supports various trade-in and recycling programs. For details, please visit

www.laptops.toshiba.com/green.

Introduction

Welcome to the world of powerful and portable multimedia

computers!

Some software may differ from its retail version (if available), and

may not include user manuals or all program functionality.

Your computer model may be ENERGY STAR®qualified. If the

model you purchased is qualified, it is labeled with the ENERGY

STAR®logo on the computer and the following information

applies.

Toshiba is a partner in the Environmental Protection Agency’s

(EPA) ENERGY STAR®Program and has designed this computer

to meet the latest ENERGY STAR®guidelines for energy

efficiency. Your computer ships with the power management

options preset to a configuration that will provide the most stable

operating environment and optimum system performance for both

AC power and battery modes.

Other manuals for L640-BT2N13

This manual suits for next models

Table of contents

Other Toshiba Laptop manuals

Toshiba

Toshiba Satellite P870 User manual

Toshiba

Toshiba L645-S4060 User manual

Toshiba

Toshiba L640D-ST2N03 User manual

Toshiba

Toshiba T130-EZ1301 User manual

Toshiba

Toshiba M65-S9062 User manual

Toshiba

Toshiba A105-S4004 - Satellite - Core Duo 1.66 GHz User manual

Toshiba

Toshiba T135D-S1322 User manual

Toshiba

Toshiba Satellite 2210CDT User manual

Toshiba

Toshiba Satellite Pro S300-EZ1512 User manual

Toshiba

Toshiba PS241U-2DC2P7 User manual

Toshiba

Toshiba TECRA S1 Series User manual

Toshiba

Toshiba Satellite Pro 4300 User manual

Toshiba

Toshiba A355-SC2902 User manual

Toshiba

Toshiba Tecra M5-S5331 User manual

Toshiba

Toshiba A105-S1014 User manual

Toshiba

Toshiba Satellite P205-S6297 Owner's manual

Toshiba

Toshiba Satellite S55T-A User manual

Toshiba

Toshiba Satellite L745D-S4220 User manual

Toshiba

Toshiba Satellite L755-S5253 User manual

Toshiba

Toshiba Satellite C655 User manual

Toshiba

Toshiba M60-S8112ST User manual

Toshiba

Toshiba A355-S6943 User manual

Toshiba

Toshiba L515 S4925 - Satellite - Pentium 2.1 GHz User manual

Toshiba

Toshiba Qosmio X305-Q701 User manual

Popular Laptop manuals by other brands

HP ze2401xt - Pavilion Notebook PC datasheet

Velocity

Velocity NoteMagix M10 quick start guide

Dell

Dell Alienware 17 R2 Service manual

HP ENVY 17 Maintenance and service guide

Winbook

Winbook LM user guide

Dell

Dell Inspiron 1464 Setup guide

Dell

Dell Inspiron 15R 5537 quick start guide

HP PROBOOK 4520S Maintenance and service guide

Dell

Dell Latitude ATG D620 Service manual

Sony

Sony VAIO PCG-FX270 Specifications

Dell

Dell Latitude 7310 Service manual

Dell

Dell Precision GU806 Quick reference guide

Sony

Sony VAIO PCG-R505JLK user guide

Lenovo

Lenovo THINKPAD X32 Setup guide

HP Compaq tc4200 Software guide

Lenovo

Lenovo ThinkPad X201 Tablet Manual

Lenovo

Lenovo THINKPAD X31 Manual

Sony

Sony VGN-T240P VAIO Specifications
