Toshiba PDR-4300 Mounting instructions

You should read this first before you use this software.

Notice and Request Regarding Software and Instruction Manual

(1) Copying or duplication of the software and Instruction Manual packaged with this Software

Application in part or in whole is not allowed without the prior permission of Toshiba

Corporation.

(2) Use of the software and Instruction Manual packaged with this Software Application is allowed

only on one personal computer.

(3) Toshiba Corporation is not liable whatsoever for any damages to the user or a third party as a

result of use of a device by the software and Instruction Manual packaged with this Software

Application.

(4) Every effort has been made in assuring the quality during production of the CD-ROM contained

in this package. If for any reason the CD-ROM has been damaged during production and within

the warranty, the disk will be replaced free of charge. For all other nonconformities or damages

made other than during the production of the CD-ROM, Toshiba Corporation will not be held

liable whatsoever.

(5) The contents of the software, Design, Specifications and Instruction Manual packaged with this

Software Application are subject to change without notice.

(6) The personal computer screens shown in this Instruction Manual are examples, and may differ from

actual screens.

(7) Toshiba Corporation is not liable whatsoever for any compensation arising from errors in descriptions

in this Instruction Manual.

(8) Do not play back the CD-ROM packaged with this Software Application on a musical CD player or

a similar device. Doing so might damage the headphones or speakers, or injure your ears.

IMPORTANT

Operations in

ACD See

When Using

Macintosh

When Using

Windows

Getting Ready

Before Reading This Manual

This Instruction Manual describes how to install the software provided and a brief explanation of how to use

the Software Application.

To ensure that you use this Software Application correctly, read this Instruction Manual carefully before you

start using the Software Application.

This document has been written assuming that you basically understand how to use the Toshiba PDR-4300

Digital Still Camera and your personal computer that the Software Application is running on.

For basic details on the PDR-4300 and your personal computer, refer to the Toshiba PDR-4300 Digital Still

Camera’s Instruction Manual or the Instruction Manual for your personal computer.

Trademark Information

Microsoft and Windows are registered trademarks of the Microsoft Corporation of the U.S. registered in

the USA and other countries.

Windows is an abbreviated term referring to the Microsoft Windows Operating System.

Macintosh is a trademark of Apple Computer, Inc.

ACDSee is a registered trademark of ACD Systems Ltd.

Direct X is a registered trademark of Microsoft Corporation.

SD is a trademark .

Other companies or product names are trademarks or registered trademarks of the respective companies.

Conventions Used In This Manual

• Indicates items or details that you should observe to prevent loss of data, malfunction and impaired

performance. Also indicates information relating to specifications and functions.

• Indicates extra useful information.

When Using

Macintosh

When Using

Windows Getting Ready

Operations in

ACD See

Before Reading This Manual (continued)

Abbreviations Used In This Manual

Windows 98

This refers to the Microsoft Windows 98 operating system.

Windows 2000

This refers to the Microsoft Windows 2000 Professional operating system.

Windows ME

This refers to the Microsoft Windows ME operating system.

Windows XP

This refers to the Microsoft Windows XP operating system.

Images

This refers to both still images and movies.

About bundle software in CD-ROM

After USB connection between the camera and the computer is established, the system will automatically

launch ACDSeeTM software.

Either using Classic or X environment mode on Macintosh, the software installations remain the same.

About OS Platform

Macintosh

Do not remove SD Memory Card from your camera or your PC card adapter until USB connection is properly

terminated between the computer and the camera.

At Windows 2000, software installation is required on Administrator mode.

Windows

On Macintosh OS X, the images reviewed via ACDSee software cannot be copied or moved to another storage

media.

On Macintosh, ACDSee software does not support [Copy to Camera] function.

Operations in

ACD See

When Using

Macintosh

When Using

Windows

Getting Ready

Before Reading This Manual (continued)

Make sure that you have all of the items below before you start using your software application.

USB cable (1)

Software Manual(1)

(this manual)

Software application(1)

(CD-ROM)

When Using

Macintosh

When Using

Windows Getting Ready

Operations in

ACD See

Contents

Getting Ready

Before Reading This Manual ...................... 1

Contents ..................................................... 4

Features of This Software Application........ 5

About Files .................................................. 6

About the Software ...................................... 8

Pre-installation Checks .............................. 9

When Using Windows

Installation Procedure .............................. 10



Using USB Cables

(Windows 98/2000/ME/XP) ........................

Copying Images to Camera ..................... 15

When Using Macintosh

Installation Procedure .............................. 17

Operations in ACDSee

General Operations ......................................

Starting the Photo Enhancer........................

Playing Movies...............................................

Installing DirectX............................................

How to Access the Service and Support....

Global Contacts .............................................

Operations in

ACD See

When Using

Macintosh

When Using

Windows

Getting Ready

Features of This Software Application

If you install the software and drivers on your personal computer, you can perform the following:

Importing Images

You can import images taken on the Toshiba PDR-4300 Digital Still Camera into your personal computer.

To import images, you need to use the USB cable (packaged with this camera), or PC card adapter.

Editing Still Images

You can edit imported still images using ACDSee, or print them out on a printer connected to the

personal computer you are using.

Playing Movies

You can play imported movies.

Saving Images

You can save imported images or edited images on the personal computer you are using.

When You Use SD Memory Card on Your Personal Computer

When you use SD Memory Card on your personal computer, do not change or delete the folder or names of

files (image data) on the SD Memory Card. Otherwise, you may no longer be able to use the SD Memory

Card on the PDR-4300.



Format the

SD Memory Card

on the PDR-4300.



To edit image data, first copy the image data to the personal computer’s hard disk, and edit the copied

image data.

When Using

Macintosh

When Using

Windows Getting Ready

Operations in

ACD See

About Files

File Structure of SD Memory Card

The images taken on the Toshiba PDR-4300 Digital Still Camera are stored to the SD Memory Card as shown

below.

Operations in

ACD See

When Using

Macintosh

When Using

Windows

Getting Ready

About Files (continued)

About Still Picture Data

On the PDR-4300, still image data is saved in Exif format. This format is JPEG data that includes a

thumbnail image and the photographic settings.

Still image data is saved as follows as shown on page 6:

Folder name : XXXTOSHI (XXX is any number within the range 100 to 999)

File name : PDR_XXXX (XXXX is any number within the range 0001 to 9999)

About Movie Data

Movie data is saved in the following format on the PDR-4300:

File format : AVI

Movie size : 320 x 240 or 160 x 120

Movie codec : Motion-JPEG

• The quality or size of movie data cannot be changed.

When Using

Macintosh

When Using

Windows Getting Ready

Operations in

ACD See

About the Software

You can install the following software from the CD-ROM:

ACDSee

This software allows you to edit and print imported still images and to playback movies.

USB driver(Ver. 1.1)(for Windows 98 only)

This USB driver provided on the CD-ROM is exclusively for Windows 98. Installing the USB driver for use in

Windows 2000, Windows ME, Windows XP and Macintosh is not necessary.

Direct X

This software allows you to playback movies.
