Toro PowerMax 38614 Manual

FormNo.3366-129RevB

PowerMax®Snowthrower

ModelNo.38614

SetupInstructions

Setup

Important:RefertoyourOperator’sManualfor

safety,maintenance,andwarrantyinformation.

1.Positiontheupperhandleoverthelowerhandle.

Note:Donotremovetherubberbanduntilyou

haveinstalledthehandle.

Important:Routethe2cablesattachedto

theQuickStickinsidetheupperhandlelegs

(Figure1).Donotpinchthecables.

Figure1

1.Cables

2.Securetheupperhandle(Figure1).

3.Removethehairpincotterandwasherfromtheend

ofthespeedcontrolrodandinserttheendintothe

lowerlinkarm(Figure2).

Figure2

4.Securetherodendwiththewasherandhairpin

cotter.

5.Removethehairpincotterandtheouterwasher

fromthetrunnionontheupperendofthespeed

controlrod(Figure3).

Figure3

1.Speedselectorlever3.Innerwasher

2.Trunnion4.Outerwasher

Note:Donotremovetheinnerwasher(Figure3).

6.ShiftthespeedselectorleverintoPositionR2.

7.Rotatethelowerlinkarmup(Figure4).

Figure4

8.Liftupthespeedcontrolrodandinsertthetrunnion

intheholeinthespeedselectorleverlocatedunder

thecontrolpanel(Figure3).

Note:Ifthetrunniondoesnottintothehole

whenyouliftupthespeedcontrolrod,rotatethe

trunnionupordownonthespeedcontrolroduntil

itts.

9.Securethetrunnionandupperendofthespeed

controlrodwiththeouterwasherandahairpin

cotter.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved

Note:Foreasierinstallation,lookdownthrough

theopeninginthespeedselector(Figure5).

Figure5

1.Speedselector

10.UnwraptheQuickStickandrotateitsothatitis

uprightandinthecenter.

11.Holdthebluecapdownandpulltheleverfullyback.

Note:Thedischargechuteanddeectorshould

faceforward.Iftheydonot,holdthebluecapdown

(butdonotmovetheQuickStick),androtatethe

dischargechuteuntiltheydo.

12.Aligntheattenedendofthelongrodwiththe

attenedendoftheshortrodthatextendsfromthe

controlpanelsotheynesttogether(Figure6).

Figure6

1.Shortrod2.Longrod

13.Insertthelongrodendintothebackofthechute

gearcoveruntilitslidesintothegear(Figure7).

Figure7

14.Aligntheholesinthenestedendsoftherodsand

insert2boltsthroughtheshortrodfromtheleft

side(fromtheoperatingposition).

15.Insertthecableclipthatsupportsthedeectorcable

ontheforwardbolt,andsecuretheboltswiththe

locknutsprovided(Figure8).

Figure8

1.Cableclip2.Deectorcable

16.HoldthebluecapdownandrotatetheQuickStick

inacircletoensurethatthechuteanddeector

worksmoothly.

17.Tooperatethesnowthrowerusingtheself-propel

feature,slidethewheelsoutwardandinserttheaxle

pinsthroughtheholesinthewheelhubsandthe

inneraxleholes(Figure9).

Figure9
