FormNo.3451-388RevB
BackhoeFit-UpKit
TX1000CompactToolCarrier
ModelNo.23126
InstallationInstructions
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Preparethemachine.
2Tilt-cylinderpin1Replacethetilt-cylinderpin.
Quick-attachplate1
Smallbolt2
Largebolt8
Smallwasher4
Largewasher24
Spacer8
Nut10
Tie-downlink2
3
Pinlock4
Installthequick-attachplateand
tie-downlinks.
Jumperwire(foruseontractionunits
withserialnumber3999999999and
belowonly)
2
Fit-upkitelectricalharness1
Electricalharnesscap1
4
Cabletie4
Installthewireharness.
5Heatshield1Installtheheatshield.
6Hook-and-loopstrap(20inchesx1inch)1Installthehook-and-loopstrap.
©2022—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3451-388*
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Engagetheparkingbrake.
3.Lowertheloaderarms.
4.Shutofftheengine,removethekey,andallowthemachinetocool.
5.Opentherear-accesscoverandenginehood.
6.Turnthebattery-disconnectswitchtotheOFFposition.
7.Removethecoverplatebyremovingthe3boltsholdingitinplace(Figure1).
Note:Retainthecoverplateandcorrespondingboltsforlaterinstallation.
g355550
Figure1
1.Coverplate
2
2
ReplacingtheTilt-CylinderPin
Partsneededforthisprocedure:
1Tilt-cylinderpin
Procedure
1.Tiltthetractionunitattachmentmountplateatandgentlyresttheattachmentmountplateontopofa
block.
2.Placeablockinfrontofthemountplatesothatitcannotswingforwardwhenyouremovethetilt-cylinder
pin.
CAUTION
Whenyouremovethetilt-cylinderpin,themountplatemayswingforward,crushing
yourfeetorhands,orthoseofbystanders.
Placeablockinfrontofthemountplatebeforeremovingthetilt-cylinderpin.
3.Removetheboltandnutsecuringtheuppertilt-cylinderpinonthetractionunit(Figure2).
4.Usingahammerandpunch,removethetilt-cylinderpin.
5.Installthenewpinintopositionandsecureitwiththeboltandnutremovedpreviously,usingthemiddle
holeonthepin(Figure2).
6.Greasethepinusingthettingonthetiltcylinder.
Note:Leavethenewpininstalled,evenwhenthebackhoeisremoved.
3
g351625
Figure2
1.Bolt4.Newtilt-cylinderpin
2.Tiltcylinder5.Middlehole
3.Nut
3
InstallingtheQuick-AttachPlateandTie-DownLinks
Partsneededforthisprocedure:
1Quick-attachplate
2Smallbolt
8Largebolt
4Smallwasher
24Largewasher
8Spacer
10Nut
2Tie-downlink
4Pinlock
Procedure
1.Installthequick-attachplateontothebackhoeusing2smallbolts,4smallwashers,8largebolts,24large
washers,8spacers,and10nuts(Figure3).T orquetheboltsto94to102Nm(70to75ft-lb).
4
g378752
Figure3
1.Smallbolt(2)4.Largewasher(24)
2.Smallwasher(4)5.Spacer(8)
3.Nut(10)6.Largebolt(8)
2.Connectthetractionunitreceiverplatetothebackhoequick-attachplateandengagethequick-attach
pins;refertothetractionunitOperator’sManual.
3.Installatie-downlinkasshowninFigure4.Securethetie-downlinkwith2pinlocks.
4.Repeatstep3ontheothersideofthemachine.
5
g352719
Figure4
1.Pinlocks(4)2.Tie-downlink(2)
5.Connectthehydraulichoses;refertothetractionunitOperator’sManual.
4
InstallingtheWireHarness
Partsneededforthisprocedure:
2Jumperwire(foruseontractionunitswithserialnumber3999999999andbelowonly)
1Fit-upkitelectricalharness
1Electricalharnesscap
4Cabletie
Procedure
Note:Usethejumperwiresontractionunitswithserialnumber3999999999andbelowonly.
1.Plugthet-upkitharnessconnectorintothebackhoeelectricalharnessconnector(Figure5).
Note:Whenyouarenotusingthebackhoe,ensuretoinstalltheelectricalharnesscaponthebackhoe
endofthet-upkitharness.
2.Routethet-upkitelectricalharnessalongsidethehydraulichosesasshowninFigure5.
3.Routetheharnessthroughthehydraulichoseaccessholeintotheundersideofthecontrolpanel
(Figure5).
Note:Usethehydraulichosetiedownstosecuretheharness.
6
g352089
Figure5
1.Harnessroutedthroughaccesshole2.T obackhoeelectricalharnessconnector
4.Opentherear-accesscover.
5.Fortractionunitswithserialnumbers3999999999andbelow:
A.Plugthe2jumperwiresintothecorrespondingt-upkitharnessconnectors(Figure6).
g355376
Figure6
B.Underthecontrolpanel,removethetractionunitharnessterminalfromtheignitionswitch(Figure7).
7
g355397
Figure7
1.Ignitionswitch2.Tractionunitharnessterminal
C.Plugthetractionunitharnessignitionterminalintothecorrespondingjumperterminal(Figure8).
D.Plugtheotherjumperterminalintotheignitionswitch(Figure8).
g355400
Figure8
1.Ignitionswitch3.Jumperterminal(totractionunitharnessignitionterminal)
2.Jumperterminal(toignitionswitch)4.Tractionunitharnessignitionterminal(tojumperterminal)
8
