TomTom 4CS03 User manual

What’s in the box

What’s in

the box aTomTom GO

AOn/Off button

BMicrophone

CLight sensor

DSpeaker

EMemory card (micro SD card) slot

bActive Dock cUSB car charger

dUSB cable eDocumentation pack

Siena-USA-UG-NONLIVE.book Page 2 Thursday, June 24, 2010 2:32 PM

Mounting your device EN

Mount-

ing your

device Mounting your navigation device

1. Push the EasyPort™ Mount on your TomTom GO against the windshield in your car.

2. Lock the EasyPort Mount by twisting the base.

Siena-USA-UG-NONLIVE.book Page 3 Thursday, June 24, 2010 2:32 PM

Mounting your device

3. Lock the EasyPort Mount by twisting the base.

4. Insert the Car Charger into your device. Insert the Car Charger into the cigarette lighter

in your car.

Siena-USA-UG-NONLIVE.book Page 4 Thursday, June 24, 2010 2:32 PM

Mounting your device EN

5. Switch your device on by pressing the On/Off button on the top of your device.

6. You now have to answer some questions to set up your device. Tap the screen to answer

the questions.

Siena-USA-UG-NONLIVE.book Page 5 Thursday, June 24, 2010 2:32 PM

Mounting your device

7. To remove the Mount from your windshield, first unlock the EasyPort Mount, then gently

pull one of the tabs. The Mount comes away from the windshield.

Siena-USA-UG-NONLIVE.book Page 6 Thursday, June 24, 2010 2:32 PM

Getting started

Getting

started Switching on and off

Install your TomTom GO navigation device

in your car following the instructions in the

installation section at the start of this book.

To switch on your navigation device, press

and hold the On/Off button until you see the

start-up screen. The first time you switch on

your device, it may take a short time to start.

Setting up

When you first switch on your device, you

have to answer a few questions to set up the

device. Answer the questions by tapping

the screen.

You are asked whether you make regular

trips to the same locations. If you tap YES,

you can enter these destinations as your

favourite destinations. Every time you

switch on your device, you can immediately

select one of these locations as your desti-

nation.

To change these destinations or select a

new destination, tap Start-up preferences in

the Preferences menu, then select Ask for a

destination.

Device not starting

In rare cases, your TomTom GO navigation

device may not start correctly or may stop

responding to your taps.

First, check that the battery is properly

charged. To charge the battery, connect

your device to the car charger. It can take up

to 2 hours to fully charge the battery.

If this does not solve the problem, you can

reset the device. To do this, press and hold

the On/Off button for 15 seconds and

release the button when your device begins

to restart.

Siena-USA-UG-NONLIVE.book Page 7 Thursday, June 24, 2010 2:32 PM

Getting started

Battery notes

The battery in your TomTom GO navigation

device charges when you connect it to the

car charger or to your computer.

When you connect your device to a com-

puter, you are asked if you want to connect

to the computer. If you select No and then

do not tap the screen within three minutes,

the device will automatically switch off. This

happens so that the battery can charge

faster.

Note: You should plug the USB connector

directly into a USB port on your computer and

not into a USB hub or USB port on a keyboard

or monitor.

GPS reception

When you first start your TomTom GO nav-

igation device, the device may need a few

minutes to determine your GPS position

and show your current position on the map.

In future, your position will be found much

faster, usually within a few seconds.

To ensure good GPS reception, you should

use your device outdoors. Large objects

such as tall buildings can sometimes inter-

fere with reception.

Siena-USA-UG-NONLIVE.book Page 8 Thursday, June 24, 2010 2:32 PM

Safety

Safety Positioning the EasyClick Mount

Consider carefully where to attach the

mount in your car. The mount should not

block or interfere with any of the following:

• Your view of the road

• Any of the controls in your car

• Any of your mirrors

• The airbag

When your navigation device is in the

mount, you should be able to reach the

device easily without leaning or stretching.

The diagrams show where you can safely

attach the mount.

You can attach the mount to the wind-

screen, side window or use a Dashboard

Mount Disk to attach the mount to your

dashboard. TomTom also offers alternative

mounting solutions for your TomTom navi-

gation device. For more information about

Dashboard Mount Disks and alternative

mounting solutions, go to tomtom.com/

accessories.

Installing the Active Dock

Make sure that both the Active Dock and

your window are clean and dry.

1. Press the suction cup firmly against the

window on an area where the glass is

flat.

2. Twist the rubber grip near the base of the

Active Dock in a clockwise direction until

you hear a click.

The Active Dock is now installed.

Siena-USA-UG-NONLIVE.book Page 9 Thursday, June 24, 2010 2:32 PM

Planning a route

Planning

a route Planning a route with your ProductName-

Long navigation device is easy. To plan a

route, follow the steps below.

Important: For safety reasons, you should

always plan a route before you start your

journey.

1. Tap the screen to bring up the Main

Menu.

Note: The buttons on your navigation device

are shown in full colour unless a button is cur-

rently unavailable.

2. Tap Navigate to... Plan route.

3. Tap Address.

In this example, we will enter an address.

cMakingYourFirstJourney-nonLIVE.fm Page 10 Thursday, June 24, 2010 3:29 PM

Planning a route EN

4. Tap Street and house number.

Note: When planning a trip for the first time

your navigation device asks you to choose a

state or country. Your choice is saved and used

for all routes you plan.

You can change this setting at any time by tap-

ping the flag.

5. Start to type the name of the town where

you want to go. Tap the name when it is

shown in the list.

Tip: Instead of typing the name,

tap this button to say the address

by speaking to your navigation

device.

6. Start to type the street name. Tap the

name when it is shown in the list.

cMakingYourFirstJourney-nonLIVE.fm Page 11 Thursday, June 24, 2010 3:29 PM
