６
Q1: What should be noted when setting the AP button?
A1: Make sure the power is off.
Q2: How dose the AP work without power supply?
A2: The AP gets the power via the cable. It is called POE. Two cables are needed for
the connection. STP CAT5e cable is strongly recommended for this case.
Q3: How long the POE cable can be?
A3: The length of the cable depends on the power voltage and cable quality. For 24V
power, the length of the cable can be 40 meters, while 10-20 meters for 12V
power.
Q4: Why the signal light does not work after switching the button?
A4: Please turn off the AP power first. It is recommended to do the troubleshooting
test as below. For the transmitter, keep the button from “1” to “10” UP. For the
receiver, keep the button “1” DOWN, and the button from “2” to “10” UP. After
finishing, turn on the power and wait for three minutes. The distance between the
transmitter and the receiver should be more than 2 meters.
1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9 10
Ｔｒａｎｓｍｉｔｔｅｒ Ｒｅｃｅｉｖｅｒ
Q5: Why the local network connection is choppy after the AP installation?
A5: Shoot the trouble with below methods:
1. Change the cable to see if it is a cable problem
2. Change the wireless channel to avoid the signal interference.
Q&A
５
Transmit Power Configuration: The default is the maximum value, the transmit
power should be reduced appropriately when the signal is too strong.
Encryption Configuration: Customized key can be used for security. (The same
key should be set in the transmitter and receiver.)
Distance Configuration: Default value is two kilometers, it should be set according
to practical situation. (The same distance value should be set in the transmitter and
receiver. If not, it will lead to high latency, low bandwidth network connection.)
Country code: In text (manual) mode, the channels are determined by the the
dial-up button. It is automatically selected in other modes.
Step 2 Type the IP address of corresponding AP device in IE browser to get into
the WEP page, the default password is “password”. Signal power can be set after
logging.
Signal power setting
Status
Logout
Transmit Power
Mode
Router Access
Time
Backup / Restore
Update Firmware
Reboot
System
Country code
Country code： Test （Text）
Transmit Power Configuration
Power:
Client Signal Threshold
dBm
Encryption Configuration
Use Custom Key:
Distance Configuration
Distance:
Signal Threshold: (Only for Station)
show
Close
2KM
.............
Save Changes Reset
