thomann millenium User manual
Synth Drum
hand-drum pad
user manual
Musikhaus Thomann e.K.
Treppendorf 30
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
email: [email protected]
Internet: www.thomann.de
25.01.2012
Table of contents
1 General notes............................................................................................................................................... 4
2 Safety instructions..................................................................................................................................... 6
3 Features.......................................................................................................................................................... 9
4 Operating elements............................................................................................................................... 10
5 The functions of the device................................................................................................................ 14
6 Use.................................................................................................................................................................. 27
7 Replacement of components............................................................................................................. 32
8 Patch list....................................................................................................................................................... 34
9 Loop list........................................................................................................................................................ 47
10 Technical specifications....................................................................................................................... 50
11 Cleaning....................................................................................................................................................... 52
12 Protecting the environment.............................................................................................................. 53
Table of contents
Synth Drum
3
1 General notes
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
This section gives an overview of the symbols and signal words used in this user manual.Symbols and signal words
General notes
hand-drum pad
4
Signal word Meaning
DANGER! This combination of symbol and signal word
indicates an immediate dangerous situation
that will result in death or serious injury if it is
not avoided.
CAUTION! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in minor injury if it is not avoided.
NOTICE! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in material and environmental
damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General notes
Synth Drum
5
2 Safety instructions
Use the device only as described in this user manual. Any other use or use under other oper‐
ating conditions is considered to be improper and may result in personal injury or property
damage. No liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
hand-drum pad
6
CAUTION!
Possible hearing damage
With loudspeakers or headphones connected, the device can produce volume
levels that may cause temporary or permanent hearing impairment.
Do not operate the device permanently at a high volume level. Decrease the
volume level immediately if you experience ringing in your ears or hearing
impairment.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
Synth Drum
7
NOTICE!
External power supply
The device is powered by an external power supply. Before connecting the
external power supply, ensure that the input voltage (AC outlet) matches the
voltage rating of the device and that the AC outlet is protected by a residual cur‐
rent circuit breaker. Failure to do so could result in damage to the device and pos‐
sibly the user.
Unplug the external power supply before electrical storms occur and when the
device is unused for long periods of time to reduce the risk of electric shock or
fire.
Safety instructions
hand-drum pad
8
3 Features
nAluminium alloy frame
nStriking surface made of high grade materials
nPlayable in 100 different style / tempo loops
(50 drum loops and 50 melody loops)
n200 preset and user patches
(Changed parameters are storable per user patch)
n5 global effect types
n5 pressure-dependant effects
nAdjustable sensitivity
n9 different velocity curves
nHeadphone output (1/4" socket) and Aux input (1/8" socket)
nDC 9 V power adaptor
Features
Synth Drum
9
4 Operating elements
Front panel
Operating elements
hand-drum pad
10
