Thermo Sphere QGW15-607 User manual

Infrared Quartz Heater

with Thermostat

Stop

Please read and understand this manual before any assembly

or use of this product.

Before beginning assembly of product, make sure all parts

are present.

Customer Service: 1-888-538-0082 / [email protected]

Instruction Manual

Infrared Quartz Heater

with Thermostat

Model No. QGW15-607

Infrared Quartz Heater with Thermostat

Table of Contents

Important Instructions

Operations Instructions

Safety Features

Cleaning, Maintenance and Storage

Infrared Quartz Heater with Thermostat

Important Instructions

When switching on the appliance for the ﬁrst time, allow it to run at full power for about two hours to get rid

of the odour. Make sure that the room in which the appliance is located is well ventilated during this

procedure. It is normal for the appliance to emit small crackling sounds when you turn it on for the ﬁrst time.

1. Read all instructions before using this heater.

2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible

materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3'/1 m from the front

and top of the heater and keep them away from the sides and rear. Keep the rear grille away from walls

or drapes so as not to block the air intake.

3. Always unplug heater when not in use.

4. Do not operate any heater with a damaged cord or plug or after the heater malfunctions or has been

dropped or damaged in any manner.

5. Do not use outdoors. This product is intended for normal household use only.

6. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never

locate heater where it may fall into a bathtub or other water containers.

7. Do not run cord under carpeting. Do not cover cord with throw rugs or runners. Arrange cord away

or pinched by furniture.

8. To disconnect the heater, turn control to "OFF", then remove the plug from outlet.

9. This appliance has a polarized plug. This plug is intended to ﬁt a polarized outlet only one way. If the

plug does not ﬁt fully in the outlet, reverse the plug. If it still does not ﬁt, consult a qualiﬁed electrician.

Do not connect the heater to an extension cord, surge protector, timer, direct breaker or an outlet with

other appliances connected to the same outlet. Risk of ﬁre, overheating, malfunctioning, property

damage, injury or even death may result if not adhered to.

10. Connect to properly polarized outlets only.

11. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an

electric shock, ﬁre, or damage to the heater.

12. To prevent a possible ﬁre, do not block air intakes or exhaust in any manner. Do not use on soft surfaces,

like a bed, where openings may become blocked.

13. The heater has hot or arcing or sparking pads inside. Do not use it in areas where gasoline, paint or

ﬂammable liquids are used or stored. Keep combustible materials such as furniture, pillows, bedding,

papers, clothes and curtains at least 3 feet / 1 m from the front of the heater and keep them away from

the sides and rear. To prevent a possible ﬁre, do not block air intakes or exhaust in any manner. Do not

use on soft surfaces, like a bed, where openings may become blocked. Do not place the heater near a

insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric

shock, ﬁre, or damage the heater.

PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS HEATER.

When using electrical appliances, basic precautions should always be followed to reduce risk of ﬁre,

electrical shock and injury to persons or property, including the following:

Infrared Quartz Heater with Thermostat

SAVE THESE INSTRUCTIONS

CAUTION: To prevent electric shock, match wide blade of plug to wide slot receptacle,

fully insert.

PET OWNERS WARNING: The health of some small pets including birds are extremely

sensitive to the fumes produced during the ﬁrst time use of many appliances. These fumes

are not harmful to humans, but we recommend that you do not use your heater around

birds and small pets during its initial use until the manufacturing corrosion (anti-corrosion)

14. Use this heater only as described in this manual. Any other use not recommended by the

manufacturer may cause ﬁre, electric shock, injury to persons or damage to property.

15. This heater must be plugged into a 120V, 15 amp (or more) circuit of its own. Nothing else can be

plugged into the same circuit. If unsure if your home meets this speciﬁcation, consult a certiﬁed

electrician prior to use. Risk of ﬁre, overheating, malfunctioning, property damage, injury or even

death may result if not adhered to.

16. To prevent overload and blown fuses and breakers, be sure that no other appliance is plugged into

the same outlet or into another outlet wired into the same circuit.

17. It is normal for the heater's plug and cord to feel warm to the touch. A plug or cord which becomes

hot to the touch or becomes distorted in shape may be a result of a worn electrical outlet. Worn

outlets should be replaced prior to further use of the heater. Plugging heater into a worn outlet may

result in overheating of the power cord or ﬁre.

18. Ensure the heater is on a stable, secure surface to eliminate the potential of it tipping over.

19. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or

relocatable power tap (outlet/power strip).

20. Be sure that the plug is fully inserted into the appropriate outlet/receptacle. Periodically check that

your outlet is in good condition to avoid overheating or deformation of the plug.

21. Check that neither the appliance or the power cable has been damaged in any way during

transportation.

22. Make sure that no pieces of polystyrene or other packaging materials have been left on the appliance.

It may be necessary to pass over the appliance with a vacuum cleaner.

23. This appliance is not intended for use by persons (including children) with reduced physical, sensory

or mental capabilities, or lack of experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person responsible for their safely. Children should

be supervised to ensure that they do not play with the appliance.

Infrared Quartz Heater with Thermostat

Operations Instructions

Control panel

Heater operation:

Always operate the heater in the upright position following all instructions and recommendations listed

in this manual.

Heater location:

Place the heater in the area of the room that is coldest.

Heater connection:

Plug heater directly into 120V AC, 60 Hz wall outlet. Be sure plug ﬁts tightly in outlet. A loose

connection may cause overheating and damage to the plug or heater.

Power control dial:

This heater has two heat settings: High (II) and Low (I). Use the higher setting (1500W) to raise the room

temperature quickly. When the desired temperature is reached use the Low setting. It is usually

Setting thermostat:

After heater has been turned on and the room has reached the desired temperature, slowly rotate the

leaving the thermostat at this setting it will automatically maintain this temperature. To lower

temperature, rotate the knob further counterclockwise (towards the LOW position (-)). To raise the

temperature, rotate the thermostat knob clockwise (towards the HIGH position (+)).

Turn the dial to the OFF position before unplugging or plugging in the heater. Heater should be

unplugged when not in use.

Quartz tubes:

Do not use with either quartz tube cracked or broken.

1. Power indicator light

2. Power control dial

3. Thermostat control

NOTE: To prevent overloading a circuit, do not plug the heater into a circuit that is servicing other

electrical needs.

Power indicator:

This heater is equipped with a Power Indicator Light. The power light will illuminate when the unit is

plugged in to alert you that the unit has power.

Turning heater on:

To start the heater, turn the Power Control Dial from the OFF position (o) to the LOW (I) or HIGH (II) setting.

Then rotate the Thermostat Control clockwise to the HIGH THERMOSTAT position (+) as described below.

(During the heaters initial use, you may experience a slight odour or smoking. This is the result of the

few minutes of use.) Ensure room in which the heater is situated is well ventilated.

Infrared Quartz Heater with Thermostat

Safety Features

The power indicator light, located near the control panel, lights whenever the heater is plugged in. The

heater is equipped with an automatic overheat protection device located inside the body of the heater. If

the heater grille is obstructed, or if the heater gets too hot for any reason, the automatic overheat protec-

tion device will turn the heater o. To reset the heater, simply turn power o and unplug the heater for 10

minutes until it cools down and you may plug in and restart the heater. Be sure that the heater is on a

smooth level surface with no obstructions. If the heater is tipped over, the automatic tip over switch will

turn o the heating elements until the heater is upright.

Cleaning, Maintenance and Storage

Storage:

1. Perform the cleaning procedures noted above and wipe all parts dry.

2. Pack the heater in its original box and store in a cool dry place.

Before any cleaning:

1. Make sure the heater is turned OFF and allow the heater to cool completely.

2. Disconnect power supply at source by removing plug from power outlet.

Regular cleaning:

1. Do not spray cleaning liquid or other chemicals on the unit.

2. To clean the exterior, use a clean, soft and lightly damp cloth to gently wipe o the dirt from the

surface of the unit. Be sure not to wet the heating element and the switches. Allow the unit to dry

completely before using it.

REPAIR: DO NOT OPERATE THE HEATER WITHOUT THE GRILLE IN PLACE. DO NOT USE THE

HEATER IF IT HAS MALFUNCTIONED OR IS DAMAGED IN ANY WAY.
