Thermaltake Purepower W0328 User manual

Purepower Series TM

Purepower Series

All trademarks are the property of their respective owners.

Reproduction in whole or in part without written permission is prohibited.

Purepower Series

www.thermaltake.com

Unmatched

Performance

250x176mm

Purepower Series TM

Purepower Series

Table of contents

01. Warnings & Caution -----------------

02. Components Check -----------------

03. Power Connector Introduction --

04. Installation Steps --------------------

05. Product Features -------------------

06. Output Specification -----------------

07. Total Protection ----------------------

08. EMI & SAFETY -----------------------

09. Environments -------------------------

10. Trouble Shooting ---------------------

250x176mm

Purepower Series TM

Purepower Series

1. Do not unplug the AC power cord when the power supply is in

use. Doing so may cause damage to your components.

2. Do not place the power supply in a high humidity and/or

temperature environment.

3. High voltages exist in the power supply. Do not open the

power supply case unless you are an authorized service

technician or electrician. Doing so will void the warranty.

4. PSU should be powered by the source indicated on the rating

label.

5. All warranties and guarantees will be voided, if failure to

comply with any of the warnings and cautions covered in this

manual.

1. Warnings and Caution 2. Components Check

01 02

- Power supply unit

- User manual

- AC power cord

- Mounting screws

250x176mm

Purepower Series TM

Purepower Series

3. Power Connector Introduction

Connector Type Connectors & Cable length

20+4pin

ATX 12V 4pin

SATA

4. Installation Steps

03 04

Cable

P/N Model

W0330 550W

W0329 450W

1 1 4 6 2 1

1 1 25111. Open your computer case; please refer to the direction in your

case manual.

2. Install the PSU into the case with the four screws provided.

3. Connect the 24 pin Main Power Connector to your

motherboard and peripheral. If your motherboard uses a 20-pin

connector, detach the 4-pin attachment on the 24-pin connector.

4. Connect the 8-pin or 4-pin connector for the CPUs.

5. Connect other peripheral power connectors to devices such as

hard drives, optical drives, etc.

6. Close your computer case and connect the AC power cord to

the power supply AC inlet.

Note: The detachable 4-pin section cannot be used in place of a 4-pin +12V

connector.

Note: Make sure that your system is turned off and unplugged.

Disconnect the AC power cord from your old power supply.

20+4pin Main

Connector 4pin +12V CPU

Connector SATA

Connector Peripheral

Connector Floppy

Connector 6pin PCI-E

Connector

W0328 350W 1 1 2510

MODELS

W0330

W0329

W0328

Molex & FDD

W0330

W0329

W0328

W0330

W0329

W0328

W0330

W0329

SATA

PCI-E 6pin

1 x 24pin Main connector

(400mm)

1 x ATX 12V 4pin connector

(400mm)

3 x Peripheral, 1 x FDD connectors

(400mm + 150mm + 150mm + 150mm)

3 x Peripheral, 1 x FDD connectors

(400mm + 150mm + 150mm + 150mm)

3 x Peripheral, 1 x FDD connectors

(400mm + 150mm + 150mm + 150mm)

2 x Peripheral connectors

(400mm + 150mm)

3 x Peripheral connectors

(400mm + 150mm + 150mm)

2 x Peripheral, 1 x FDD connectors

(400mm + 150mm + 150mm)

2 x SATA connectors

(400mm +150mm)

2 x SATA connectors

(400mm +150mm)

2 x SATA connectors

(400mm + 150mm)

1 x 6pin PCI-E connectors

(400mm)

250x176mm

Purepower Series TM

Purepower Series

5. Product Features

05 06

- Ultra-efficient circuitry design.

- Near-silent thermal engineering.

- Stable true power output.

- Intel ATX 12V 2.2 Compatible

- Dual +12V output circuit provides outstanding steady output

for system.

- Adjustable AC input (115V/230V) for different country.

- Intel & AMD CPU compliance.

- Compatible with latest PCI-Express (450W / 550W).

- Super quiet and stable 8cm fan.

- High reliability: MTBF>100,000 hours.

- Protections: Over Power, Over Voltage, and Short-Circuit

protection.

- Safety / EMI Approvals: UL and FCC certified.

OUTPUT

POWER

+5Vsb

-12V+12V1

+3.3V +5V

DC OUTPUT

MODEL

INPUT VOLTAGE: 115V/230V, FREQUENCY:47HZ-63HZ

405W

2.0A0.3A18A

18A 28A

MAX Current

W0330

355W

2.5A0.3A15A

21A 18A

W0329

6. Output Specification

7. Total Protection

Over Voltage Protection

Voltage Source

+3.3V

+5V

+12V

Protection Point

4.5V Max.

Short Circuit Protection

A short circuit placed between dc return and output rail (Approximately

0.03ohm) shall cause no damage to power supply and the main output

shall shut down and latch off, but the 5Vsb might recovery automatically.

+12V2

18A

15A

PEAK

POWER

550W

450W

MIN Current

MAX Current

MIN Current

0A0A1.0A

0.3A 2A 1.0A

0A0A0.5A

0.3A 0.5A 0.5A

255W

2.5A0.3A10A

19A 18A

MAX Current

W0328

10A

350W

MIN Current 0A0A0.5A

0.3A 0.5A 0.5A

7.0V Max.

15.6V Max.

250x176mm
