Thermador - RES30 Specifications

RES30

30" Convection Range W/Electric Cooktop

Appearance

White Pattern or Black Ceramic Glass Top Surface

Oven Capacity - Cubic Feet 3

Glass Control Panel

Concealed Oven Vent, Top of Backsplash

Finishes: Black or White Glass, or Stainless Steel

Performance

Two Top Surface Dual-Size Ribbon Elements

Dual Element Thermal Bake

Convection Bake

Variable Temperature Open or Closed Door Broiling

Timed & Delay Timed Mode

Convenience

Variable Time Self-Cleaning Electric Oven

Motorized Door Lock

Minute Timer

Rack Positions 4

Oven Racks 3

Automatic and Manual Oven Light Switch

Broiler Pan & Grind

Removable Oven Door

Four Hot Surface Indicator Lights

Burner / Element "ON" Indicator Light(s) 2

Roll-Out Glass or Stainless Steel Front Storage Drawer

General Information

Fuel Electric

Broil / Bake Wattage 3,600 / 2,600

Dual-Rated 120/208-240 Volts, 3 Wire, 60Hz

AMPS 20

Approximate Shipping Weight (LBS.) 275

Dimensions

Overall Dimensions - A1*** 36 to 37 1/2

Overall Dimensions - B1** *** 29 15/16

Overall Dimensions - C1***† 25 3/16

Overall DImensions - D1***† 17 7/8

Front Left Wattage - BTU/HR†† 1,800 7"

Front Right Wattage - BTU/HR†† 1,000 to 2,500 6" - 9"

Rear Left Wattage - BTU/HR†† 1,000 to 2,200 5" - 8"

Rear Right Wattage - BTU/HR†† 1,500 6"

Thermador - RES30 Specifications

Oven Interior Dimensions - Height 15 1/2

Oven Interior Dimensions - Width 23 1/2

Oven Interior Dimensions - Depth 16

Overall Dimensions

Notes: 1) All height, width and depth dimensions are shown in inches. 2) LP Conversion kit available

(NLPKIT6) for Dual-Fuel models. 3) Venting requirements: Cook 'N'Vent® hoodless downdraft ventilation

system must be vented to outside. 4) The Thermador Cook 'N'Vent range with hoodless downdraft ventilation

system consists of the range (with the downdraft intake included) and the blower, which must be ordered

separately. Select a remote blower (model VTR1000Q or VTR600R) with a duct attachment box (model RD310

or RD7) or an integral blower (model VTN30RQ). A tow kick accessory can be installed on downdraft models to

achieve a slide-in look. Model RKPQ(indicate Black, White or Stanless).

*Overhead ventilation recommended for ranges.

**Measured from cabinet face.

***Please refer to installation instructions prior to making cutout.

†Dimension measures from rear of trim to front of control panel endcap.

††D.S. = Dual Size

Ranges and blowers are UL and CUL approved. For immediate critical installation dimensions by fax, use your

fax handset and call (775) 833-3600. Use code #8030 for a directory of Thermador products.

Ranges and cooktops are CGA and AGA approved.
