Page 6
ASSEMBLY AND OPERATION
Disassemble the loop handle.
Position the upper handle over the upper shaft just in front of
-
side of the shaft and should line up with the four screw holes on
the upper handle. Secure with four screws, washers and nuts.
Connect the latch on the shoulder harness to the harness eye,
located on the upper shaft.
Adjust the strap to a comfortable position.
Bnt
The attachment connects to the power unit by means of a
coupler device.
Loosen the knob on the coupler of the upper shaft.
Push in the button on the bent shaft.
Align the button with the guide recess on the coupler and slide
the two shafts together.
Rotate the lower shaft until the button locks in the positioning
hole.
Tighten the knob securely.
Note: If the button does not release completely in the positioning
hole, the shafts are not locked in place. Slightly rotate from side to
side until the button locks.
bracket.
Fix the bolt through the holes in the tabs on the shield and the
slots in the bracket on the attachment shaft.
Tighten securely and remove the protective packaging from the
line cut-off blade.
djusting the Throttle Cable:
• After releasing the throttle lever, pull the throttle cable.
• The normal play is 1 or 2 mm when measured at the
carburettor side end.
• If the play is too short or long, take off the air cleaner
cover, loosen the locknut (1) and adjust (2).
