Telstra F5050 User manual
www.telstra.com
© COPYRIGHT 2005 Telstra Corporation Limited
This work is copyright.All rights reserved.Other than for purposes and subject to conditions prescribed under the Copyright
Act, no part of it may in any form or by any means (electronic, mechanical, photo copying, microcopying, scanning, recording
or otherwise) be reproduced, stored in a retrieval system or transmitted without prior permission from Telstra Corporation
Limited ABN 33 051 775 556.
™ Trade Mark of Telstra Corporation Limited
® Registered Trade Mark of Telstra Corporation Limited
If you have any problem with your phone, refer to the Help section
of this User Guide or call TecHelp on 1300 369 193.
Telstra F5050
Digital DECT Cordless Telephone with
Integrated Digital Answering Machine
User Guide
F5050TAM UG art 9/6/05 12:30 PM Page 1
2
Introduction
to your Telstra F5050
Digital DECT Cordless Telephone with
Integrated Digital Answering Machine
● 10 number memory
●Calling Number Display to see the number of the person calling and keep track of
unanswered calls
●Redial any of the last 10 number called
●Answering machine with up to 10 minutes recording time.
●Play, repeat and delete your messages from almost any other phone.
●Option to use the pre-recorded outgoing messages or record your own.
As a Digitally Enhanced Cordless Telecommunications (DECT)
product, your Telstra F5050 provides: -
●Digital voice clarity
●Digital security
●Digital range
3
IMPORTANT
This equipment is not designed for
making emergency telephone calls
when the power fails. Alternative
arrangements should be made for
access to emergency services.
This User Guide provides you with
all the information you need to get
the most from your phone.
Before you make your first call you
will need to set up your phone.
Follow the simple instructions in
‘Getting Started’, on the next few
pages.
Need help?
If you have any problems setting up
or using your Telstra F5050, please
contact the TecHelp line on 1300
369 193.
Alternatively, you may find the
answer in ‘Help’ at the back of this
guide.
Got everything?
●Telstra F5050 handset
●Telstra F5050 base unit
●2 x NiMH AAA rechargeable
batteries
●Battery compartment cover
●AC power adaptor
●Telephone line cord
●Telephone adaptor plug
In addition, if you have
purchased a Telstra F5050
with multiple handsets,
you will have received
additional components,
which are shown in the
Extension User Guide.
In this guide
4
Getting started 6
Location 6
Setting up 6
Set day and time 8
Check day and time 8
Getting to know your phone 9
Handset buttons 9
Handset display icons 10
Base 11
Navigating the menus 12
Menu map 13
Using your phone 14
Make a call 14
Preparatory dialling 14
End a call 14
Receiving calls 14
Earpiece volume 14
Handsfree 15
Make a call in handsfree 15
Answer a call in handsfree 15
Switch to handsfree during a call 15
Mute 16
Redial 16
To delete numbers from the
redial list 16
Page the handset(s) 16
Internal calls 17
Transferring calls 17
3 way conference 17
Memory 17
Store a number 18
Dial/view a number 18
Edit/delete a number 18
Delete all memories 19
Handset settings 19
Ringer melody 19
Ringer volume 19
Handset ringer off/on 20
Keypad lock 20
Restore default settings 20
Default handset settings 21
Telstra Network Services 22
Calling Number Display* 22
Using the Calls list 22
View/dial a number 22
Delete a number 23
Delete the entire Calls list 23
In this guide 5
Using the answering machine
Switch on/off 24
Loudspeaker volume 25
Outgoing messages 25
Answer and Record 25
Answer Only 26
Select answer mode 26
Record your own outgoing message 26
Play/check outgoing message 27
Reinstate pre-recorded outgoing
messages 27
Memory full 27
Answer delay 28
Check answer delay setting 28
Working with a fax machine 29
Audible message alert 29
To switch audible message alert on/off29
Message playback 30
Playing messages 30
Delete individual messages 30
Delete all old messages 30
Call screening 31
Record a memo 31
Remote access 32
To change the security code 32
Switch answering machine on 32
Check for messages 33
Message playback 33
Registering a Telstra F5050 handset 34
Registering additional handsets 34
Registering a Telstra F5050 handset 34
De-register a handset 35
Help 36
Replacing the handset batteries 36
General Information 38
Safety 38
General 38
Cleaning 39
Environmental 39
Technical information 40
How many telephones can you have? 40
Connecting to a PABX 40
PABX external line access code 40
Switching external line access code 40
Insert a pause 41
Recall(R) 41
Remote access code number 41
Product warranty &
Customer service 42
Getting started
6
WARNING
Do not place your
Telstra F5050 in the
bathroom or other
humid areas.
Handset range
The handset
reception range from
the base is up to
300m outdoors and
up to 50m indoors.
Thick stonewalls can
severely affect the
range.
Signal strength
The ANTENNA
symbol on your
handset screen
indicates when you
are in range. When
you are out of range,
it flashes.
Location
You need to place your Telstra F5050 within 2 metres of a mains
power and telephone socket so that the cables will reach.
Make sure it is at least 1 metre away from other electrical
appliances to avoid interference.
Your Telstra F5050 works by sending radio signals between the
handset and base. The strength of the signal depends on where
you site the base. Putting it as high as possible ensures the best
signal.
Setting up
1. Plug the mains power cable into the base and plug the other
end into the mains power socket.
Power
adaptor
cable
Getting started 7
IMPORTANT
Do not connect
the telephone line
until at least one
of the handsets is
fully charged. The
base station must
be plugged into the
mains power at all
times.
Which socket?
Power socket
Telephone line
socket
When the handset
is in the base or
charger, the red
Charging light stays
on and the battery
icon in the display
continues to cycle
from 1 to 3 bars even
when the batteries
are full charged.
Talk/Standby time
Under ideal
conditions, fully
charged handset
batteries should
give about 10 hours
talktime or 100 hours
standby on a single
charge.
2. Insert the 2 x AAA NiMH batteries supplied into the handset.
Slide the battery compartment cover into place.
3. Charge the handset for at least 16 hours by placing the handset
on the base. The red charging light comes on.
The handset is pre-registered to the base as HS 1.
This is shown on the display. When the handset is fully charged
the display shows the BATTERY symbol.
4. After 16 hours, plug the telephone line cord into your Telstra
F5050 base and the telephone wall socket.
Line cord
Getting started
8
Battery low warning
If the symbol is
flashing, you will need
to recharge your
handset before using it.
Battery performance
To keep your batteries
in the best condition,
leave the handset
off the base for a few
hours at a time (after
the initial 16 hour
charge). New NiMH
batteries do not reach
full capacity until they
have been in normal
use for several days
Running the batteries
right down at least
once a week will help
them last as long as
possible.
The charge capacity
of rechargeable
batteries will reduce
with time as they
wear out, so reducing
the talk/standby
time of the handset.
Eventually they will
need to be replaced.
New batteries can be
obtained from TecHelp
on 1300 396 193 or
your nearest electrical
retailer.
Set day and time
Your Telstra F5050 answering machine automatically adds the
day and time to all messages and memos recorded.
The default setting is Saturday 12:01pm.
1. Press and hold until you hear "Please set day and time"
and the current setting on the message counter flashes.
2. Press or to hear and select the day then press
to confirm.
You can scroll through the settings by holding down
the button.
1= Monday,
7= Sunday.
3. Press or to hear and select the hour then press
to confirm.
4. Press or to hear and select the minute then press
to confirm.
The day and time setting is announced in full.
Check day and time
1. Press and release . The current day and time are
announced.
Your Telstra F5050 is now ready for use and the answering
machine is switched ON.
Getting to know your phone 9
Clear
Used to delete digits,
page 18 and to switch
Secrecy (Mute) on and
off, page 16.
Calls
Opens the Calls list, page
22.
Prog/Handsfree
Press to activate
handsfree (loudspeaker)
mode, page 15.
Press and hold to set
menu options.
Phone
Press to make, receive
and end phone calls,
page 14.
#/Lock
Press and hold to lock/
unlock the keypad, page
20.
Handset buttons
Memory
Used to store and dial
up to 10 numbers,
page 17.
Redial
Used to redial one of
the last 10 numbers
called, page 16.
R/ Intercom
Used when connected
to a switchboard/PABX
page 41, and with
some Telstra Calling
Features.
Press and hold to make
internal calls with
another Telstra F5050
handset, page 17.
*/Bell
Press and hold to
switch the ringer on/
off, page 20.
A
B
C
D
i
g
i
t
a
l
C
l
a
r
i
t
y
3
12
46
5
79
8
*#
0
R
Memory
D
E
F
J
K
L
M
N
O
T
U
V
W
X
Y
Z
P
Q
R
S
G
H
I
Clear /
Mute
C
a
l
l
s
R
e
d
i
a
l
I
n
t
e
r
c
o
m
H
a
n
d
s
f
r
e
e
Prog
V
o
l
Getting to know your phone
10
Handset display icons
* For these features to work you must subscribe to your Calling Number Display service.
Icon Steady Flashing
In range Out of range
Handset in use Incoming call
Secrecy
Ring volume off
Keypad lock on
Making internal
call or transferring
external call
Handsfree on
Missed call(s)
Icon Steady
Battery empty
Battery low
Battery half full
Battery full
Directs you back
in the calls list*
Directs you forwards
in the calls list*
Phonebook
These are the symbols you will see on your handset screen.
Table of contents
Other Telstra Cordless Telephone manuals
Telstra
Telstra 7200 User manual
Telstra
Telstra 8950 User manual
Telstra
Telstra Long Range 9750 User manual
Telstra
Telstra 5600 User manual
Telstra
Telstra 8200 User manual
Telstra
Telstra TEC-C User manual
Telstra
Telstra V1600 SMS Colour Screen User manual
Telstra
Telstra Outdoor 900 User manual
Telstra
Telstra 6100 User manual
Telstra
Telstra V1600 User manual
Telstra
Telstra 13950 User manual
Telstra
Telstra V850a User manual
Telstra
Telstra 5200a User manual
Telstra
Telstra 2400 User manual
Telstra
Telstra Slim Touch 9650 User manual
Telstra
Telstra Easy View 3400 Twin User manual
Telstra
Telstra Voice Control TVC-C Assembly instructions
Telstra
Telstra F2400 User manual
Telstra
Telstra Slim Touch 9650 User manual
Telstra
Telstra V950a User manual
