TEINNOVA MULTIPRO User manual
Electro-pneumatic brushing robot
user manual EN
multipromultipro
original manual translation
Electro-pneumatic brushing robot 2-52
multipromultipro
introduction
Training service
Technical service
Thank you very much for placing your trust in a quality product from TEINNOVA.
This product is manufactured using modern production processes and extensive
quality assurance measures.
We try to do everything possible to ensure that you are satisfied with this product and
can work with it without any problems.
If you have any questions about this product, please contact your dealer or our
company directly.
Before operating the machine, carefully read the operating instructions for your
equipment.
Please consider this manual as part of the machine and keep it handy for future
reference.
We offer the option of providing companies with specific training in the use of
our equipment and training their operators to provide the best service and thus
contribute to the success of their end customers.
Aspects such as knowing how to draw up a good estimate objectively, responding to
specific problems that may arise, or offering a more professional and efficient service.
Thanks to our own manufacturing of cleaning equipment we can control at all times
the quality and performance of each machine we manufacture, and this has allowed
us to have very low repair ratios which have always been solved with our own
Technical Service led by the same team that manufactures it, and in very short
periods of time.
We have all types of spare parts for your equipment, as well as related accessories.
These operating instructions are protected by copyright. We reserve all rights, in particular the right of
production, translation and processing with electronic systems.
Dear customer:
©
Electro-pneumatic brushing robot 3-52
multipromultipro
symbology
safety warnings
conditions of use
know your machine
control panel
accessories and related equipment
operating instructions
5-52
6-52
7-52
8-52
9-52
11-52
19-52
remote control
10-52
index
Electro-pneumatic brushing robot 4-52
multipromultipro
use of chemical products
transport
maintenance and care
waste management
technical specifications
CE declaration of conformity
43-52
44-52
45-52
49-52
50-52
52-52
warranty conditions
51-52
index
Electro-pneumatic brushing robot 5-52
multipromultipro
symbology
DANGER!
WARNING!
CAUTION!
IMPORTANT NOTE!
All the existing graphic symbols in this manual as well as those indicated on the equipment itself are explained
in this section, it is important to read with special attention the text related to this symbology since it is related to
personal and equipment safety.
This symbol alerts you to a potentially hazardous situation which can result in
death or serious injury if the instructions are not followed properly. Be sure to
read all instructions described in the “Safety Information” section.
This symbol alerts you to a potentially hazardous situation which may result in
minor or moderate injury, or property damage resulting in personal injury if you
do not properly follow the instructions.
This symbol alerts you to a situation that may result in property damage
without personal injury if you do not properly follow the instructions.
This symbol alerts you to information regarding the optimal use of the
equipment to avoid possible misuse.
Electro-pneumatic brushing robot 6-52
multipromultipro
The MULTIPRO equipment must NOT be used for purposes other than those described in this instruction
manual.
Before starting up the equipment, make sure that all electrical and fluid connections are correct.
Before starting the equipment, make sure that the brush is inside the duct to be cleaned.
Be careful to place your MULTIPRO on a smooth and stable surface. Lock the brakes on the front wheels
so that the machine remains stable while working.
Persons operating MULTIPRO equipment must be sufficiently trained.
Hold the hose firmly before operating the air brush motor. Keep a firm grip on the hose at all times while
operating the brush.
Safety goggles must be worn to prevent chemical splashes or dust from reaching the operator’s eyes.
Properly secure your MULTIPRO and activate the wheel lock when transporting it in a vehicle.
Do not open the control box of your MULTIPRO duct cleaning robot. In the event of a fault, please contact
TEINNOVA’s Technical Assistance Service on +34 941 44 50 56.
safety warnings
Electro-pneumatic brushing robot 7-52
multipromultipro
Any other use is strictly prohibited
without the written permission of
the manufacturer.
Do not place the equipment in a
horizontal position as this will cause
serious internal damage.
LEYENDA
Unless otherwise indicated, the
degreasing chemical should be
the one recommended by the
COMEGRAS manufacturer.
The use of a different chemical will
void the warranty and may cause
irreparable damage to your TEGRAS
equipment.
MULTIPRO is a machine for cleaning both circular ducts, with diameters of 100-1000 mm, and rectangular ducts.
Ducts may be for smoke extraction, chimneys or even air-conditioning installations. Suitable fittings must be
provided for each duct.
It includes a 30 metre hose so that 60 metres of pipe can be cleaned from a single point on the pipe. It can be
used in flues and extraction hoods.
This equipment performs dry or wet cleaning, generating and applying active foam that is subsequently rinsed
with water.
It can be used with the AR20 compressor as shown in the diagram.
chemical and low pressure rinsing
power supply
compressed air
mains water
AR20
Compressed air generator
conditions of use
multipro
Electro-pneumatic brushing robot
for duct cleaning
Electro-pneumatic brushing robot 8-52
multipromultipro
Components:
1- Control panel
2- Reel
3- Reel rotation lock
4- Rear wheel
5- Liquid inlet
6- Compressed air inlet
7- Electrical connection cable
8- Chemical support tray
9- 10-litre chemical tank
10- Chemical suction rod
11- Front wheel with brake
12- Carrying handle
13- On/off button
14- LED indicator
15- Hose
16- Brush head
17- Brush coupling
18- Brush
know your machine
13
14
7
6
5
9
8
10
4
3
11
18 15
16
1
2
12
17
Electro-pneumatic brushing robot 9-52
multipromultipro
Main control panel:
control panel
1
2
3
General Switch
Touch screen
Emergency Mushroom
Switching the equipment on and off
Emergency stop
The equipment is controlled via the touch screen.
4LED Strip Indicates the status of the machine
Electro-pneumatic brushing robot 10-52
multipromultipro
Remote control:
2
3
4
1
5
6
Unlock button
Right Turn
Foaming
Left Turn
Centring button
Rinsing
Button for activating the above functions. In order to start a
function, both buttons must always be pressed at the same
time.
Actuates the motor of the planing machine so that its rotational
movement is counterclockwise.
Used to open/close/stop the centring device of the MULTIPRO
planing machine.
It drives and stops the foaming function of the machine.
Activates and stops the rinsing function of the machine.
Actuates the motor of the planing machine so that its rotational
movement is clockwise.
1 Battery12V.
Alkaline 23A
remote control
4
2
5
6
1
3
