TEFAL OPTIGRILL User manual

Instructions for use

OPTIGRILL

TEF-OPTIGRILL-Aus-NC00117232 01/03/13 08:59 Page1

IMPORTANT SAFEGUARDS

When using electric appliances, basic safety precautions should always be followed, including the

following:

1. Read all instructions before using.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against electric shock, do not immerse or partially immerse cord, plugs, or appliance

in water or other liquid.

4. Not intended for use by children. Close supervision is necessary when any appliance is used by

or near children.

5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or

taking off parts, and before cleaning the appliance.

6. Do not operate the appliance with a damaged cord or plug or after the appliance malfunctions,

or has been damaged in any manner. Return the appliance to the nearest authorized service

facility for examination, repair or adjustment.

7. The use of accessory attachments not recommended by the appliance manufacturer may

cause injuries.

8. Do not use outdoors.

9. Do not let cord hang over the edge of table or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or electric burner, or in a heated oven.

11. Do not use appliance for other than intended use.

12. Extreme caution must be used when moving an appliance containing hot oil or other hot liq-

uids.

13. Check that the electrical installation is compatible with the wattage and voltage stated on the

bottom of the appliance.

14. f this appliance has a polarized plug (one blade is wider than the other), it is to reduce the risk

of electric shock, this plug is intended to fit into a polarized outlet only one way. f the plug

does not fit fully into the outlet, reverse the plug. f it still does not fit, contact a qualified elec-

trician. Do not attempt to modify the plug in any way.

15. CAUT ON - To ensure continued protection against risk of electric shock, connect to properly

grounded outlets only.

16. Always attach plug to appliance first, then plug cord into the wall outlet.To disconnect, turn

any control to off, then remove plug from wall outlet.

SAVE THESE INSTRUCTIONS.

Safety instructions

• Never leave the appliance unattended when in use.

• To prevent the appliance from overheating, do not place it in a corner or against a wall.

• Never leave the appliance plugged in when not in use.

TEF-OPTIGRILL-Aus-NC00117232 01/03/13 08:59 Page2

• Do not place the hot plate under water or on a fragile surface.

• f you have any problems, contact the authorized after-sales service center or the internet address

www.tefal.com.au and www.tefal.co.nz

Short Cord instructions

A short power-supply cord (or detachable power-supply cord) is to be provided to reduce the

risk resulting from becoming entangled in or tripping over a longer cord.

Longer detachable power-supply cords or extension cords are available and may be used if care is

exercised in their use.

f a long detachable power-supply cord or extension cord is used :

1) The marked electrical rating of the cord or extension cord should be at least as great as the elec-

trical rating of the appliance;

2) f the appliance is of the grounded type, the extension cord should be a grounding-type3-wire

cord; and

3) The longer cord should be arranged so that it does not drape over the countertop or table top

where it can be pulled on by children or tripped over unintentionally.

THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLD ONL .

Thank you for buying this appliance. Read the instructions in this leaflet carefully

and keep them within reach. Any commercial use, inappropriate use or failure to

comply with the instructions, the manufacturer accepts no responsibility and the

guarantee will not apply.

For your safety, this product conforms to all applicable standards and regulations (Electric

Safety, Food Compliant Materials, …).

Our company has an ongoing policy of research and development and may modify these

products without prior notice.

• Do not consume foodstuff that comes into contact with the parts marked with logo.

• Only use parts or accessories provided with the appliance or bought from an Approved-

Service Center. Do not use them for other appliances or intention.

• To avoid spoiling your product, do not use flambé recipes in connection with it at any

time.

• This appliance is not intended to be used in the following applications, and the guarantee

will not apply for:

- staff kitchen areas in shops, offices and other working environments;

- farm houses;

- by clients in hotels, motels and other residential type environments;

- bed and breakfast type environments.

• This appliance is not intended to be operated by means of an external timer or separate

remote-control system.

TEF-OPTIGRILL-Aus-NC00117232 01/03/13 08:59 Page3

• f an accident occurs, rinse the burn immediately with cold water and call a doctor if nec-

essary.

• When using for the first time, wash the plate(s), pour a little cooking oil on the plate or

on the inside of the pot and then wipe it with an absorbent kitchen towel.

• To avoid damaging the non-stick coating of the cooking plate, always use plastic or

wooden utensils.

• Dot not use aluminum foil or other objects between the plates and the food being

cooked.

• Do not place cooking utensils on the cooking surfaces of the appliance.

• Do not cook food in aluminium foil

• Do not remove the grease collection tray while cooking, f the grease collection tray be-

comes full when cooking: let the appliance cool down before emptying

• On first use, there may be a slight odour and a little smoke during the first few minutes.

n these cases open the window an wait until there is no more smoke or odour.

• This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by

an adult responsible for their safety. Children should be supervised to ensure that they

do not play with the appliance.

• Accessible surface temperatures can be high when the appliance is operating.

Never touch the hot surfaces of the appliance, always use the handles.

• Cooking fumes may be dangerous for animals which have a particularly sensitive res-

piratory system, such as birds, We advise bird owners to keep them away from the

cooking area.

Prevention of accidents at home

Environment protection first!

The packaging of your product is made of recyclable materials. Don’t throw it in

your usual dustbin, take it to a nearby separated waste collection center.

Please take your used appliance to a recycling depot in your area. Thank you for

being environmentally friendly.

TEF-OPTIGRILL-Aus-NC00117232 01/03/13 08:59 Page4

A1 A2 A4 A5A3 A6

TEF-OPTIGRILL-Aus-NC00117232 01/03/13 08:59 Page5

Description

AControl panel

A1 On/off button

A2 Frozen food mode

A3 Cooking programs

A4 Manual mode

A5 OK button

A6 Cooking level indicator

BBody

CHandle

DCooking plates

EJuice collection tray

FPower cord

Guide of LED colors

cooking - ready to eat

Poultry

Sandwich

Pork/sausage/lamb

Red meat

Fish

Manual mode:

Traditional grill

for manual

operation

PURPLE

FLASH NG

Preheating.

GREEN

During the cooking in

progress, a beep sounds

to warn the user that

the level "Rare" cooking

(yellow) will soon come.

YELLOW

"Rare" cooking.

RED FLASH NG

End of

cooking for

"Well done".

WH TE F XED

Manual function

selected or mishandling,

refer to

"Trouble shooting guide".

ORANGE

"Medium" cooking.

RED

"Well done" cooking.

WH TE FLASH NG

Refer to

"Trouble shooting guide"

(return, calling the

consumers service...)

Guide of cooking programs

PURPLE

F XED

End of

preheating

Waiting for

food.

BLUE

Starting

of cooking.

Burger

keep warm

preheating starting of cooking

FLASHING

TEF-OPTIGRILL-Aus-NC00117232 01/03/13 08:59 Page6

1Remove all packaging materials, stickers

and accessories from the inside and the

outside of the appliance.

2Before using for the first time, remove

the plates, thoroughly clean with warm

water and a little washing-up liquid, rinse

and dry thoroughly.

3-4 Position the removable juice collection

tray at the front of the appliance.

5f desired for the best results you may

wipe the cooking plates using a paper

towel dipped in a little cooking oil, to

improve the non-stick release.

6Remove any surplus oil using a clean

kitchen paper towel.

7Connect the appliance to the mains.

(note the cable should be fully unwound).

8Press the On/Off button.

5 6

Setting

Pre-heating

rill

TEF-OPTIGRILL-Aus-NC00117232 01/03/13 08:59 Page7

9f the food that you wish to cook is

frozen, press the button “frozen food".

10 Select the appropriate cooking mode

according to what type of food you wish

to cook.

11 Press the “OK” button: the appliance

starts pre-heating and the cooking level

indicator flashes purple.

12 Wait for 4-7 minutes.

13 An audible tone is heard and the cooking

level indicator stops flashing purple the

pre-heating mode is complete.

9 10

11 12

4-7

minutes

6 cooking programs and a manual mode
