Tascam MX-2424 User manual

Jumper configurations for the Hitachi GF-2050 DVD-RAM drive when connected to the MX-2424

Termination

The jumper positions indicated below are as seen from the rear of the drive from left to right with the SCSI connector on the right.

The indicated settings are for installation into the front panel of the MX-2424 or into an external drive enclosure with proper

termination as indicated in the SCSI Instructions document. Installed jumpers are indicated with an "X".

Factory default SCSI ID setting is ID 3.

ID = 4

ID = 2

ID = 6

ID = 1

ID = 3

SCSI Address

X

X

X

ID = 5

Term Power

(Internal)

X

X

X

X

X

X

Term Power

(SCSI Bus)

X

X

X

X

X

X

SCSI Address

X

X

X

X

X

SCSI Address

X

Not Used Not Used
