Targus Stow-N-Go Notebook Mouse User manual

USER GUIDE

Visit our Website at www.targus.com Features and

specifications subject to change without notice.

AMW25US / 410-1098-001A

Wireless Optical

Stow-N-GoTM

Notebook Mouse

WIRELESS OPTICAL

STOW-N-GOTM

NOTEBOOK MOUSE

Introduction

Congratulations on your purchase of the Wireless Optical Stow-N-GoTM

Notebook Mouse. This mouse features a tracking resolution switch for

users who require more precision or speed with various applications.

The Stow-N-Go receiver clips onto the mouse for ease of use while

traveling or on the go. This mouse also features a 4-way scrolling tilt-

wheel which allows for both vertical and horizontal navigation.

• Hardware - USB port

• Windows® 2000/XP

• Windows Vista™

• Mac OS X 10.2.8 (or greater)

System Requirements

Installing the Batteries

Wireless Optical Stow-N-GoTM Notebook Mouse

2. Insert two AA-size batteries, making sure that the positive (+) and

negative (-) ends of each battery match the polarity indicators inside

the battery compartment. To replace the battery cover, place the

cover on top of the mouse and slide forward until it clicks into place.

NOTE: WHEN THE BATTERY IS LOW, THE LOW POWER INDICATOR LIGHT LOCATED

IN THE DPI SWITCHING BUTTON WILL FLASH RED. PLEASE REPLACE WITH TWO

NEW AA-SIZE BATTERIES.

1. Remove the battery cover from the back of the mouse by sliding off

the cover of the mouse. Hold the mouse in your hands and with the

back of the mouse away from you. Press down on the corners of the

battery cover and slide towards the back of the mouse. Lift the cover

off from the back of the mouse.

When power is on, the mouse goes into "sleep mode" after 8

minutes of inactivity. To activate the mouse, press any mouse key.

DPI switching

button

Wireless Optical Stow-N-GoTM Notebook Mouse

(A) Remove the USB receiver from the bottom of the mouse.

This will activate the on/off switch.

Establishing the Connection

(B)

(A)

(C)

(D)

(B) Plug the USB receiver into an available USB port on your computer.

(D) Press the setup key on the bottom of the mouse.

This device has 256 identification codes that allow the mouse and its

receiver to operate without interference from other radio frequency

devices. If you experience interference during use, repeat steps C and

D to change the connection channel.

NOTE: TO TURN THE MOUSE OFF, SIMPLY PLACE THE USB RECEIVER BACK INTO THE

STORAGE SLOT. THIS WILL MAXIMIZE BATTERY LIFE WHEN NOT IN USE.

Wireless Optical Stow-N-GoTM Notebook Mouse

This mouse is equipped with a 4-way scrolling function.

Installing the tilt-wheel software driver

To enable the tilt-wheel function, the software driver must be installed.

NOTE: PLEASE SELECT THE "3 BUTTON MOUSE" OPTION WHEN PROMPTED TO

DO SO.

2. The Installation Wizard window will prompt.

Follow the on-screen instructions to complete the installation.

1. Insert the driver software CD into your computer’s CD-ROM drive.

If setup does not begin automatically, click Start, Run, and enter

D:\Setup.exe (where D: is the path of your CD-ROM drive) and then

click OK.

After the software driver is successfully installed, there will be a “Tilt

Mouse” icon located in the task bar.

NOTE: THE TILT-WHEEL FEATURE IS SUPPORTED BY THE MAC OPERATING

SYSTEM. NO DRIVER INSTALLATION IS NECESSARY. THE FOLLOWING STEPS

ARE FOR WINDOWS OPERATING SYSTEMS ONLY.

1. Please download the software driver (Model # AMW25) from the

official Targus web site: http://www.targus.com

Save the setup.exe file to your computer and double click on the icon

to launch the installation process.

Wireless Optical Stow-N-GoTM Notebook Mouse

Adjusting the DPI Setting

This mouse features 3 selectable resolution settings (1600 / 1200 /

800 DPI). By pressing the resolution switch, you can instantly adjust

the tracking speed of the mouse. When the DPI is set at 1600, the

indicator light will glow brightest and when it is set at 1200, the light will

become dimmer. The indicator will be off when the DPI is set at 800

DPI. The setting will be saved when the mouse is turned off. The

indicator light will shut off in 10 seconds after selecting the desired

resolution.

1600 DPI

1200 DPI

800 DPI

Pressing the scroll-wheel left or right, enables the horizontal scrolling

feature.

Using the 4-way scrolling tilt-wheel

NOTE: DOUBLE CLICK ON THE “TILT MOUSE” ICON IN THE TASK BAR WILL LAUNCH

THE MOUSE SETTINGS SCREEN. YOU CAN EDIT THE SETTINGS AND PREFERENCES

IN THIS WINDOW.

Wireless Optical Stow-N-GoTM Notebook Mouse

Mac OS

Mac OS:

After selecting the desired resolution, you can also fine tune the

sensitivity. This can be adjusted in the “System Preference” of the

Mac operating system.

Click on the Apple logo --> System Preference --> Keyboard & Mouse

In the “Keyboard & Mouse” window, locate the “Trackpad” tab. Under

“tracking speed”, use the slider to change the speed of the mouse.

Windows XP

Windows XP:

After selecting the desired resolution, you can also fine tune the

sensitivity. This can be adjusted in the “control panel” of the Windows

operating system.

Click on Start --> Setting --> Control Panel --> Mouse

In the “mouse properties” window, locate the “pointer options” tab.

Under “motion”, use the slider to change the speed of the mouse. Click

apply to confirm the changes.

Transmitter

Receiver

RF • 27.045Mhz

Interface • USB 1.1

Power • USB Bus Powered 5V DC

Product Specification

RF • 27.045Mhz

Battery Type • Alkaline battery AA

Effective RF

Communication Range • 1.2 meters max

RF output Power • Below 1mW max

Power Consumption • 15mA max

Wireless Optical Stow-N-GoTM Notebook Mouse

This mouse is equipped with the latest sensor technology that conserves

power and provides up to six months of battery life. Battery life is determined

using one hour of continuous use, five days per week.

Wireless Optical Stow-N-GoTM Notebook Mouse

Technical Support

For technical questions, please visit:

US Internet: www.targus.com/support.asp

Australia Internet: www.targus.com/au

Email: infoaust@targus.com

Telephone: 1800-641-645

New Zealand Telephone: 0800-633-222

Product Registration

This device complies with Part 15 of the FCC Rules. Opera-

tion is subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) This device must

accept any interference received, including interference that

may cause undesired operation.

Regulatory Compliance

Targus warrants this product to be free from defects in materi-

als and workmanship for one year. If your Targus accessory is

found to be defective within that time, we will promptly repair

or replace it. This warranty does not cover accidental damage,

wear and tear, or consequential or incidental loss. Under no

conditions is Targus liable for loss of, or damage to a devices

nor loss of, or damage to, programs, records, or data; nor any

consequential or incidental damages, even if Targus has been

informed of their possibility. This warranty does not affect your

statutory rights.

Targus recommends that you register your Targus accessory

shortly after purchasing it. Go to:

http://www.targus.com/registration.asp. You will need to

provide your full name, email address, phone number, and

company information (if applicable).

Warranty

Wireless Optical Stow-N-GoTM Notebook Mouse

This equipment has been tested and found to comply with the limits of

a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and if not installed and

used in accordance with the instructions, may cause harmful interfer-

ence to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna;

• Increase the separation between the equipment and receiver;

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected;

• Consult the dealer or an experienced radio/TV technician for help.

Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks

of Microsoft Corporation in the United States and/or other countries. All trademarks

and registered trademarks are the properties of their respective owners. All rights

reserved.

FCC Statement

Tested to Comply

Changes or modifications not authorized by the party responsible for

compliance could void the user’s authority to operate this product.

Declaration of Conformity

Hereby, Targus, declares that this device is in compliance with the

essential requirements and other relevant provisions of Directive

1999/5/EC.
