TaoTronics HELLO TT-BH11 User manual
TAOTRONICS TT-BH11 WIRELESS STEREO EARPHONES
User Guide
Hello
EUROPE
E-mail:
support.uk@taotronics.com(UK)
support.de@taotronics.com(DE)
support.fr@taotronics.com(FR)
support.es@taotronics.com(ES)
support.it@taotronics.com(IT)
EU Importer: ZBT International Trading
GmbH, Lederstr 21a, 22525 Hamburg,
Deutschland
TT-BH11
NORTH AMERICA
E-mail : support@taotronics.com(US)
support.ca@taotronics.com(CA)
Tel : 1-888-456-8468
(Monday-Friday: 9:00 – 17:00 PST)
Address:
46724 Lakeview Blvd, Fremont,CA 94538
E-mail : support.jp@taotronics.com(JP)
ASIA PACIFIC
www.taotronics.com
CONTENTS
English
Deutsch
Français
Español
Italiano
日本語
01/14
15/29
30/45
46/61
62/76
77/89
Thank you for choosing the TaoTronics TT-BH11 Wireless
Stereo Earphones.Please read this manual carefully and
keep it for future reference.
US UK CA
Package Contents
1 x TaoTronics
Wireless Stereo
Earphones
(Model:TT-BH11)
6 x Ear Buds
(two are equipped
on the earphones)
1 x USB Charging
Cable
1 x User Guide
TAOTRONICSTT-BH11 WIRELESS STEREO EARPHONES
User Guide
Hello
01/02
Specications Product Diagram
Bluetooth Prole
Audio Codex
Range
Working Time
Charging Time
Charging Input
Waterproof Rating
Dimensions
Weight
A2DP,AVRCP, HSP, HFP
aptX
33 feet (10 meters)
Approx. 6 hours
2 hours
USB DC 5V
IPX5
59 x 2.5 x 2.95 cm
23.2 x 0.98 x 1.16 in
20.3 g / 0.715 oz ① LED Indicator ② USB Charging Port ③ Volume + / Next Track
④ Multifunction Button ⑤ Volume - / Previous Track ⑥ Microphone
03/04
Control Functions
Power On
Power Off
Play / Pause
Volume Increase
/ Decrease
Next / Previous
Track
Answer Phone Call
Hang Up
Reject Phone Call
Press and hold the Multifunction Button for 3 seconds
Press and hold the Multifunction Button for 3 seconds
Press the Multifunction Button once
Press the Volume + / - Button once
Press and hold the Volume + / - Button for 2 seconds
Press the Multifunction Button once
Press the Multifunction Button once
Press the Multifunction Button twice
Note: During a phone call,press the Multifunction Button twice to switch the
call between your phone and the earphones.
LED Indicators
LED Indicators
Red LED on
LED off
Status
Charging
Fully charged or off
Pairing Mode
Activate Voice
Control
When the earphones are powered off, press the
Multifunction Button for 5 seconds until the LED
indicator ashes blue and red.
Press the Multifunction Button twice
05/06
▲Note: The earphones will not automatically connect to a Bluetooth®device
when switched on,please read the next section on how to connect to your
Bluetooth®device.
Flashes blue and red
Flashes red once
every 3 seconds
Flashes blue twice
every 5 seconds
Slowly ashes red
Fast ashes blue
In Pairing mode
Disconnected from the Bluetooth device
Paired with a Bluetooth device
Low battery when paired
Incoming call
How to Use
1. Charging
1) Connect the charging port with any USB charging adapter or active
computer USB port.
2) Charging will start automatically with the LED indicator turning red.
3) The earphones are fully charged when the LED indicator turns off.
2. Pairing
1) Make sure the earphones and your Bluetooth®device are next to each
other (within 3 feet / 1 meter).
2) Press and hold the Multifunction Button for 5 seconds to bring the
earphones into pairing mode with the LED indicator ashing blue and red.
3) Activate the Bluetooth®function on your phone and search for nearby
Bluetooth®connections:
07/08
Notes:
• Please note the “L” and “R” markings on the earphones, they correspond to
your left side and right side respectively.
• In addition to the earphones, two pairs of different sized ear buds are
included in the package. Please try them out and nd the most comfortable
t for you.
• For iOS: Settings > Bluetooth®> On
• For Android: Settings > Bluetooth®: On > Scan for devices
4) Find “TaoTronics TT-BH11” in the search results. Tap on the name to connect.
Once connected,the blue LED will ash twice every 5 seconds.
Note:
• If a PIN code is required for pairing, try “0000” (four zeros).
• The Bluetooth earphones can remember previously paired devices. If you
have previously paired the earphones with a device, simply turn on your
device and the earphones (by pressing the Multifunction Button for 3
seconds to turn on),they will connect to the last connected device
automatically without going into pairing mode.
3. How to Wear
Please wear the earphones as shown in the diagram:
09/10
Troubleshooting
Q: My earphones will not switch on.
A: Please recharge it and make sure it has enough power. Plug the unit to a
charger and see if the power button becomes solid red.
Q: Why can’t I pair the earphones with other Bluetooth®devices?
A: Please check the following points:
• Make sure your Bluetooth®device supports A2DP.
• Make sure the earphones and your device are next to each other
or within 3 feet / 1 meter.
• The earphones must be in pairing mode with the indicator ashing
blue and red.
• Try to reboot your Bluetooth®device.
Q: After connecting and pairing with my Bluetooth®device, I cannot
hear any music from the earphones.
A: Please check the following:
• Your sound system is connected to the earphones (If LED indicator ashes
blue twice every 5 seconds then they are connected).
• Make sure the music volume is at an audible level on both your Bluetooth®
device and earphones.
• Make sure your Bluetooth®device is playing music.
Care and Maintenance
• Charge the earphones at least once every 6 months.
• Keep the earphones away from heat and humidity.
11/12
• Do not put the product under direct sunlight or hot areas. High temperatures
will shorten the lifespan of the earphones and its battery.
• Do not try to take the product apart.
• Do not drop or knock your earphones on hard surfaces.
• Do not use chemicals or detergents to clean the product.
• Do not scrape the surface with sharp objects.
Warranty
TaoTronics earphones are covered by the TaoTronics Parts and Labor
Warranty for 12 months from the date of their original purchase. If the device
becomes defective, please contact TaoTronics Support to launch warranty
claim.We will instruct you on how to return the defective unit back to us for
repair and replacement.
The following are excluded from the TaoTronics warranty:
• Device purchased as 2nd hand, used or from unauthorized sellers
• Damage resulted from misuse and abusive action
• Damage resulted from chemical, re, radioactive substance, poison, liquid
• Damage resulted from natural disaster
• Damage caused to any 3rd party / person / object and beyond
No return will be accepted without seller authorization.
Statement
We can only provide after sale services for products that are sold by
TaoTronics or TaoTronics authorized retailer and distributor. If you have
purchased your unit from a different place, please contact the seller for
return and warranty issues.
13/14
Vielen Dank, dass Sie den TaoTronics TT-BH11 Bluetooth Stereo
Sportkopfhörer gekauft haben. Bitte lessen Sie die Anleitung vorsichtig
und halten Sie sie für zukünftige Referenz..
DE
Lieferumfang
1 x TaoTronics
Kabelloser Stereo
Kopfhörer
(Modell:TT-BH11)
6 x Ohr-Adapter
(zwei benden sich
am Kopfhörer)
1 x USB-Ladekabel
1 x
Bedienungsanleitung
TAOTRONICSTT-BH11 WIRELESS STEREO EARPHONES
User Guide
Hello
