充电：电源指示灯长亮红灯，表示电量较低，需及时给麦克风充电

内放：开机状态下循环点按电源按钮，指示灯长亮绿灯，表示内放开启；指示灯熄灭，表示

内放关闭。

内放指示灯

音量+/-：调节麦克风音量，根据个

人对音量大小的适应情况适当调节

音效：点按切换8种美声效果，同时

有相应的语音提示

电源指示灯

电声基调：在音效切换到“电音”

效果模式后，点按切换电音基调，

根据演唱歌曲的基调进行选择

开关：开关机，开启

内放功能（内放功能解释详见说

明书）

长按2秒点按

2

3

耳机接口：连接耳机（带麦或

不带麦的耳机都可以兼容）

连接方法

伴奏接口：通过标配的音频线连

接外部音源设备，方便直播时播

放伴奏

手机接口：与手机Φ3.5mm接口

连接，如手机没有Φ3.5mm接口，

需配合OTG转接头使用

USB接口：通过Micro USB

数据线给麦克风充电或实现

OTG功能

连麦接口：通过标配的音频

线与第2支PH 200的手机接

口连接，实现双人合唱

1

Charging: that the power LED keeps lighting up red means low power supply. Please

charge the microphone in time.

Mixing: after turning on the mic press the power switch. That LED keeps lighting up

green means the mixing function is on, and LED lights off means mixing function is off.

Mixing LED

Volume +/-: adjusting mic

volume to a proper level.

Sound effect: 8 sound effects for

switching, and there are relative

sound prompt.

Power LED

Autotune: when it is switched to

autotune mode, press it to switch

autotune. Select the autotune

according to specific song.

Switch: to

turn on mic. to turn on

mixing function (refer to mixing

function section in the manual for details).

press it for 2 seconds

Press it

2

3

Headset connector: linking

with headset (headset with

or without mic).

Connection

Accompaniment connector:

linking with external audio

equipment via standard audio

cable for playing

accompaniment.

Cell phone connector：

linking with cell phone

Φ3.5mm connector. If the cell

phone has no Φ3.5mm

connector, use OTG adapter.

USB interface: charging

mic or achieving OTG

function via Micro USB

charging cable.

Mic connector: linking

with the second PH200 mic

via standard audio cable

for chorus.

1

Function operation

Others

Quick Start Guide
