SystemBase C600ip-s User manual
Page 1
SystemBase
AoIP CODECS
QUICK START GUIDE
C600ip-s
REL329 upwards
Ta le of Contents
CONNECTING YOUR CODEC TO A BROWSER...................................................................3
CONFIGURE THE AOIP CODEC............................................................................................ 5
MAKE A CALL........................................................................................................................ 6
AUDIO OVER IP STATS.......................................................................................................... 8
Page 2
CONNECTING YOUR CODEC TO A BROWSER
The C600ip-s is designed to be configured by web browser only. To do this you will need to plug the LAN
Ethernet socket into your local network using a standard Ethernet cable. The C600ip-s is defaulted to obtain
an P address using DHCP, so it is essential that your local network has a DHCP server running.
When power is applied to your codec the front panel system status led will flash until the LAN is connected to
a network and a DHCP P address is obtained successfully. On success the system status LED will remain
light constantly.
To find the P address of the codec you can use one of the following freeware tools. These can be
downloaded from the internet here.
1/ https://www.advanced-ip-scanner.com/
2/ https://angryip.org/
nstall and RUN the chosen P scanner on your computer and you will find the P address of your C600ip-s
audio codec displayed like this:-
You can now clearly identify your C600ip audio codec by the model number and the serial number of the
unit. n this case it has been allocated the P address 192.168.1.253.
Page 3
Now you have the codec P address you can use your WEB browser to connect to the management
interface. This is done by entering the P address of the codec in the browsers address bar and pressing
enter. You will prompted with a sign in screen like this
Now enter the default user name “admin” and the default password “admin” and click Sign n.
Page 4
CONFIGURE THE AOIP CODEC
Firstly you will need to connect the Ao P Ethernet connector to you local network. Once connected
successfully the front panel LED will stop flashing and turn off.
Next you will need to configure the Ao P codec to make a call. This is done by proceeding to the P Config
tab on the browser.
Now you can enable the DHCP setting in the local settings menu to allocate a P address to the Ao P codec.
You can see that the unit has now been allocated the P address of 192.168.1.9.
Page 5
MAKE A CALL
Now that the Ao P codec has an P address we can proceed to make a call. This is done from the P audio
control tab. Simply enter the P address of the far end codec into the remote address field and specify the
audio mode that you require. n this case the far end P address is 192.168.1.11 and the chosen audio mode
is APTX, Stereo, 48KHz, Duplex with 1:4 FEC error correction. This is perfect for a FM radio transmitter link.
Note that the Link state has become active with a reported round trip delay of 0ms. Now you can make a call
by pressing the green Manual button.
Page 6
The call is now established with a entry in the active connection panel displaying some basic statistics. f you
wish this call to be 24/7 and remain connected following power outages and breaks in the P connection you
should use the AUTO On button rather than the MANUAL button.
Page 7
AUDIO OVER IP STATS
P statistics are available and can be useful for monitoring the performance of the Ao P connection.
Please note that it is not recommended to run audio codecs on a network that is shared with many
computers as the RTP streams are very sensitive to packet jitter. t is recommended that some QOS is
implemented using the codecs DSCP settings to elevate the priority of the RTP traffic in the routers queuing
system.
Page 8
Page
Page 10
Systembase Limited
Warminster
Wiltshire
BA12 6DG
UK
Website: www.systembase.com
E-Mail: [email protected]
nformation furnished is believed to be accurate and reliable at the time of publication. The manufacturer
reserves the right to change details without notice. Systembase is a trademark of Systembase Limited. apt-X is
a trademark of APT Licensing Ltd. All trademarks and tradenames acknowledged. This document is not part of
a contract or licence except as may be expressly agreed in writing.
Copyright 2009-2022 Systembase Limited - Printed in the UK - All Rights Reserved.
C600ip-s - ssue 1
