Swann DVR8-NET-8000 User manual

DVR8-Net-8000™

Digital Video Recorder

Multi function monitoring & recording solution

www.swannsecurity.com

Enquiries: [email protected]

Product Code: SW243-8N8

Monitoring Kits & Recording

• Quick & easy to setup – plug & play

• Connects to your existing network for

use over the web *

• Use with any TV & security cameras

• Play back & search while still recording

• Motion detection – saves hard drive space

• Four optional levels of image quality

• On-screen display (OSD) in 6 languages (Eng, Esp, Fra, Ger, Pol, Ita)

• The perfect monitoring solution for any home or business

MONITORING

Warranty

month

Easy back-up

to CDR/RW

OFFICEHOME

RETAIL WAREHOUSE

Plugs into your TV

Remote

viewing

over the web

or network

USB

Compatible

Massive

250GB

Hard Drive

Inside

512MB

USB Memory

Stick

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.

MONITORING

to PC

via USB

Back Up

DVR8-Net-8000™

Digital Video Recorder

Multi function monitoring & recording solution

Technical Specifications For Digital Video Recorder

Compression Format M-JPEG

Video Input BNC×8

Video Output BNC×2, S-Video

Display Resolution 720x576 (PAL), 720x480 (NTSC)

Record Resolution 720×288 or 360×288 (PAL),

720×240 or 360×240 (NTSC)

Display Frame Rate 200fps (PAL) 240fps (NTSC)

Recording Frame Rate 100fps (PAL) 120fps (NTSC)

Audio Input RCA×4

Audio Output RCA×2

Recording Mode Manual / Timer / Motion Detection / Sensor

Simplex/Duplex/Triplex Triplex

Network Interface RJ45 (LAN, INTERNET)

PTZ Control YES

Communication Port RS485

Remote Controller YES (Batteries not included, uses 2 x AAA)

USB USB2.0

Power Supply DC12V, 5A

Storage Temperature & Humidity -4~149°F (-20~65°C) / 20~95% RH (No Condenser)

Operation Temperature & Humidity 23~122°F (-5~50°C) / 20~80% RH (No Condenser)

Dimension (L×W×H) 17” x 23” x 2.75” (430 x 580 x 70mm)

* Requires the use of a broadband internet connection

Package Contents

• DVR8-Net-8000™

• 250GB Hard Drive (pre-installed)

• Power Adapter

• Power Cable

• Remote Viewing Software (PC Only)

• Video Cable 3ft (1m)

• 512MB USB Memory Stick

• Remote Control

(Batteries not included, uses 2 x AAA)

• Instruction Manual

OFFICEHOME

RETAIL WAREHOUSE
