Sunbeam PB9800 User manual

PB9800 café series II blender

Issue: A Page 1 of 16

SERVICE MANUAL

PB9800

café series II blender

ISSUE:

DATE: 28/05/2012

PB9800 café series II blender

Issue: A Page 2 of 16

SPARE PARTS LIST

Note: Not all parts are available as spare parts. Please check price list.

Item

Description

Material

QTY

Supplier's

Code

Sunbeam Part

No.

Items 1-2

Pusher assembly

PB98001

PUSHER ROD HANDLE

PP 6524 ( E31765 Basell)

PUSHER ROD CORE

PP 6524 ( E31765 Basell)

Measuring Cup

PB98003

3-4

Jug Lid & Measuring Cup

SAN PN-117 (E56070 Chi Mei)

PB98004

PP6524 overmould TPE

ITEMS 5-15 &

21-25

Blade assembly

PB98002

Shim

t1.4 SUS303 double DxOD14

Blade

t1.4 SUS420J2 HRC45 +/- 5

Aluminum Shim

t0.6 Double DxOD14 AL

Bearing Base

Chrome Plating o40(max)xH26

HRC20-25

Seal Ring

IE 3846 ID8xOD22x7

Aluminum Ring

t0.6 ID13.5xOD21.5 AL

O RING

Silicone Rubber SIRA55-60

FDA o29.3xo2.3

PB9800 café series II blender

Issue: A Page 3 of 16

Upper Shaft

SUS303 o8x45.8 hardness;

HRC25

Bearing

608-RS 8*22*7

Retaining ring

t=1.0mm 弹簧钢 Carbon

Spring Steels

Bearing Base Plugged

PA6+GF30% BKV03H10

(E245249 Lanxess AG)

Items 16-20

Jug assembly

PB98005

Jug

TX1001 FINISH: GLOSS

(E118289 Eastnman)

JUG HAND COVER

PP 6524 ( E31765 Basell)

Magnetic Lid

Silicone Rubber hardness：55-

Magnet

5x Dimension 5

magnetic cap

ABS PA757 (E56070 Chi mei0

sleeve

￠10x￠8XL12.5 SUS303

Part of blade assy

PB98004

Upper Gear

o25.5x14 Sintering

Stainless Steel(SUS304L)

Upper Gear Ring

t1.0 SUS304 OD8.6xID4.3mm

Spring Washer

M4 SPW SUS

Screw

4x10 CHM SUS

Small o-ring (Joint Ring Nut)

Silicone Rubber SIR A70 FDA

OD34.8(max)x1.5x2.3H

PB98007

PB9800 café series II blender

Issue: A Page 4 of 16

Bearing Base Fixture

PA6+Glass Filled 30% (NF100G3)

掛啤

PB9600-LATHE-02

軸承座螺母

)

※灰色

(SWATCH NCS 8203-

R95B)+

晒纹

( TEXTURE YS20002 C)

PB98006

27a

Large Friction O-ring

Silicone Rubber SIRA55-60

FDA o29.3xo2.3

PB98008

driven cap

PA6+GF30% BKV03H10

(E245249 Lanxess AG)

COUPLER GEARS LOWER

PA6+GF30% BKV03H10

overmould PB9800-CAST03 (

E245249 Lanxess)

PB98009

Screw

M5x8 PM-MSP SPW

Nut

Spring Washer

M4 SPW

Ring

PLW 4x8x0.5

Motor Fixing Plate

t2.0 Steel

Screw

4x10 PM

Motor Rubber Spacer

Silicone Rubber Black

SIRA70-75

ID10.2xOD20(max)x8H

Clamp Shim

t1.5 steel OD18xID5.2mm

Screw

5x10 PM

PB9800 café series II blender

Issue: A Page 5 of 16

Items 39-47

Motor assembly

Motor

U9835-230 ( 230V 50Hz)

Nut

Spring Washer

M3 SPW SUS

PCB assembly (Speed Sensor)

1 set

PCB

PCB 71X28X1.6mm UL94V0

霍尔IC

I/C 137 OH 10, TO-92 ROHS

霍尔IC

I/C 霍尔 ATS 137 , TO-92 ROHS

组合

L/W 3P UL2468 22AWG

P+210+3MM ROHS

spacer

￠9 X Φ3 X L8.3 PBT

Ring

PLW 3x6x0.5t SUS

Screw

3x30 PM

magnetic base

PA+30﹪GF

Motor Fan

supplier by Motor factory (

Johson)

Motor Cover

PP FH44+ V0 Black

PB9800 café series II blender

Issue: A Page 6 of 16

Screw

9/4x14 PWM

Rubber Mat / Dampening Mat

ABS overmould TPE

PB98010(set of 4)

Enclosure / Main Body

Die Casting AL

RING

PLW 3.6x7x0.5t STEEL

Badge

ABS PA757 Chrom-plate

Items 54-55

PCB assembly

HALL EFFECT PCB BOX

PP FH44+ V0 ( E140331 Samsung)

2+1

PCB assembly (Jug Safety Sensor)

3set

PCB

PCB 17.5*20.5*1.6mm UL94V0

霍尔IC

I/C 137,OH 10 TO-92 ROHS

霍尔IC

I/C ATS 137 , TO-92 ROHS

组合

L/W 3P UL2468 26AWG P+190+3MM

ROHS

HALL EFFECT PCB SCREW BASE

PP FH44+ V0 ( E140331 Samsung)

Screw

3x6 PM

Screw

3x8 BT

Screw

4x6 PM -MSP

Screw

2.6x6 PA

Base Veil Block

PP6524 (E31765 Basell)

Screw

4x10 PT 彩鋅

Cord Clamp

PP6524 (E31765 Basell)

Base

PP6524 (E31765 Basell)

Screw

9/4x14 PWA

Items 68,69,71,72

Front Foot assembly

PB9800 café series II blender

Issue: A Page 7 of 16

Items 66,67, 70,72

Back Foot assembly

Foot / Feet - D

Silicone Rubber hardness ：55-60

Foot / Feet - B

Silicone Rubber hardness ：55-60

Foot / Feet - A

Silicone Rubber hardness ：55-60

Foot / Feet - C

Silicone Rubber hardness ：55-60

Foot ShimB

t0.8 SUS304

Foot ShimA

t0.8 SUS304

Screw

3x8 BT SUS

Items 57-58, 73-83

Front panel assembly

PCB assembly

1sets

PCB

PCB 149.3*30*1.6mm UL94V0

轻触开关

TACT SMD 6*6*5mm 250±50g ROHS

贴片电阻

R/S 4K7 ±5% 1/8W 0805 SMD ROHS

贴片LED

LED 120 SMD 0805 ROHS

贴片电阻

R/S 1K ±5% 1/8W 0805 SMD ROHS

贴片电阻

R/S 0; 1/8W 0806 SMD ROHS

组合

L/W 6P UL2468 26AWG P+100+3MM

Led light ring

PC 2458 ( E41613 Bayer AG )

Spring

OD5.5x5.5Lx5T o0.4

Button-1

ABS PA757 ( E56070 Chi Mei)【SLOW

START】

Button-2

ABS PA757 ( E56070 Chi

Mei)【SMOOTHIE】

PB9800 café series II blender

Issue: A Page 8 of 16

Button-3

ABS PA757 ( E56070 Chi Mei)【ICE

CRUSH 】

Button-4

ABS PA757 ( E56070 Chi Mei)【PRE

CLEAN 】

control plate

ABS PA757 ( E56070 Chi Mei)

Button Seal Ring -B

Silicone Rubber hardness：55-60

button frame

ABS PA757 ( E56070 Chi Mei)

Button Seal Ring -A

Silicone Rubber hardness：55-60

Screw

3x7 BT

PCB assembly

1 set

主控制板

PCB 131.5*84*1.6mm FR-4 UL94V0

二极管

R/D HER105 1A/400V DIP ROHS

集成电路

LNK304P DIP-8 ROHS

可控硅

TRIAC Q6012RH5 TO-220

继电器

RELAY GH-1A-12L 12A 250VAC ROHS

4PINS SHEN ZHENGOLDEN ELECTRICAL

APPLIANCES. CO.LTD TUV :R50158866

继电器

RELAY HRS4H-S-DC12V 10A 250V

ZHEJIANG HKE RELAY CO. LTD TUV:

R50116136

保险丝

FUSE (PB9500)

10A 250V 5*20MM

安规电容

X2/C 224K 275V CHANGZHOU DEFU

ELECTRIC CO. LTD. ENEC :69240012

PB9800 café series II blender

Issue: A Page 9 of 16

安规电容

X2/C 224K 275V CARLI ELECTRONIC CO

LTD. VDE:40008520

安规电容

X2/C 224K 275V DONG GUAN HUA JIA

ELECTRONIC CO. LTD.VDE:40009259

安规电容

X2/C 224K 275V ULTRA TECH XIPHI

ENTERPRISE CO. LTD. VDE:40024534

安规电容

X2/C 224K 275V SONGTIAN

ENTERPRICE CO.LTD. TUV:R50136379

金属氧化膜电阻

R/S 100 ±5% 1/2W TAPIN ROHS

压敏电阻

VARISTOR 7D471K BRIGHTKING

SHENZHEN CO LTD. VDE:40027827

压敏电阻

VARISTOR 7D471K (ZOV)ROHS

压敏电阻

VARISTOR STE07D471K SHANTOU HIGH

NEW TECHNOLOGY DEV.ZONE

SONGTIAN ENTERPRISE CO.LTD.

VDE:40023049

电解电容

E/C 4.7uF 400V M 105℃10*13mm

ROHS

电解电容

E/C 10UF 35V 105℃5*11MM ROHS

电解电容

E/C 100UF 35V 105℃6.3*12MM ROHS

电解电容

E/C 220UF 10V M 105℃6MM*7MM

ROHS

螺丝

SCREW 3.0*8mm TR ）ROHS

螺丝帽

NUT M3

散热片

HEATER SINK 35*13*25MM ROHS

垫片

M3.2 ROHS

电容

C/C 103M 1KV ROHS

Y2電容

Y/C 1500PF M 250V SONGTIAN

ENTERPRISE CO. LTD. VDE 40025748

PB9800 café series II blender

Issue: A Page 10 of 16

Y2電容

Y/C 1500PF M 250V (CT7 )ROHS

Y2電容

Y/C 1500PF M 250V HSUAN TAI

ELECTRONIC CO. LTD,. VDE:118413

工型电感

D=10MM L=12MM ≥350MA ROHS

工型电感

D=8MM L=10MM 1.2MH ≥350MA

ROHS

共模电感

19*12mm 0.8mm 5T 4MH DIP4 5A

ROHS

端子

PCB TERMINAL 187

ROHS;0.187’,T0.5mm

陶瓷晶振

Ceramic resonator 8MHz

RESONATOR_THT_3LEAD_3.4X7.4

ROHS

电位器

15K ±5% WX110(010) 24.5MM ROHS

电位器

SVR 5K MPN:SM065-02-B502-EP B

3PIN ROHS

微动开关

TACT SW 19.8*6.4*10.6MM 90 ROHS

微动开关

DMB-1206,5A,250VAC

插座

WAFER 3P P=2.0mm 180° PH-3A

ROHS

插座

WAFER 6P P=2.0mm 180° PH-6A

ROHS

二极管

R/D 1N4007 SMD ROHS

贴片二极管

S/D 1N4148 1206 SMD ROHS

稳压二极管

Z/D 5V6 1/2W ±5% SMD ROHS

贴片三极管

NPN MMBT5551LT1 HFE:100-200 SMD

SOT-23 ROHS
