Subaru Impreza 2016 User manual

2016 Quick Reference Guide

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Remote keyless entry system

Remote

transmitter key

(if equipped)

Access key

(if equipped)

Lock/ Unlock doors

PANIC

BASIC OPERATION

*Grip the driver’s door handle to unlock the

driver’s door. Grip the front passenger’s door

handle to unlock all doors and the rear gate

(5-door).

All doors and the rear gate (5-door) will be locked/ unlocked by the following procedures

carrying the access key on your person. (The driver should always carry the access key.)

For detailed operating and safety information, please refer to

your Owner’s Manual.

Keyless access function (if equipped)

Opening trunk (4-door):

Side door (front door handles only):

1All doors and the rear gate (5-door)

will be locked.

2The driver’s door will be unlocked.

(To unlock all doors and the rear gate

(5-door), briey press the button a second

time within 5 seconds.)

3Press and hold to open the trunk lid (4-door)/

Press the button to open the rear gate (5-door).

4The horn will sound and the hazard warning

ashes will ash.

Locking

Unlocking*

Door lock sensor

Grip

Touch

Press

Rear gate (5-door):

Press

Unlock

Lock

Press

Ignition switch must be in ACC or ON position.

1Select side to adjust.

2To adjust the mirror, move the switch in the

direction of your desired position.

Adjustable components

1Forward and backward adjustment

2Seat cushion height adjustment (Driver’s seat only)

3Seatback reclining adjustment

Front seat

Tilt/ telescopic steering wheel

Remote control mirror switch

1Adjust the seat position and pull the tilt/

telescopic lock lever down.

2Move the steering wheel to the desired level.

3Pull the lever up to lock the steering wheel in

place.

Make sure that the steering wheel is securely

locked by moving it up and down, and forward and

backward.

1 2

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Start/ Stop engine

To start engine:

1. Carry the access key, and sit in the driver’s seat.

2. Apply the parking brake.

3. Shift the select lever into the Pposition.

4. Depress the brake pedal until the indicator on

the push-button ignition switch turns green.

5. While depressing the brake pedal, press the

push-button ignition switch.

To stop engine:

1. Stop the vehicle completely.

2. Move the select lever to the Pposition .

3. Press the push-button ignition switch.

Every time the button is pressed without depressing the brake pedal, the power is switched

in the sequence of OFF➞ACC➞ON➞OFF.

OFF ( Turned of f) ACC (Orange) ON (Orange)

Change of the power supply (Without starting engine)

The key can be turned from ACC to LOCK only when the key is pushed in while turning it (all

models) and the select lever is in the Pposition (CVT models).

Push-button ignition switch (if equipped)

Ignition switch (if equipped)

Operation

indicator

531

To change gears, fully depress the clutch pedal, move

the shift lever, and gradually let up on the clutch pedal.

Operate Select lever/ Shift lever

Continuously variable transmission (if equipped)

Manual transmission (if equipped)

Gearshifts can be performed using the shift paddle behind the

steering wheel.

To upshift to the next higher gear position, pull the shift paddle

that has +indicated on it. To downshift to the next lower gear

position, pull the shift paddle that has –indicated on it.

Rear view camera

When the ignition switch is ON and the select lever is set to R, the rear view camera

automatically displays the rear view image behind the vehicle.

M = Manual mode

With the vehicle either moving or stationary, move the select lever from the Dposition to the

Mposition to select the manual mode.

Models with

manual mode

With the brake pedal depressed,

shift while pressing the Select

lever button in.

Shift while pressing the Select

lever button in.

Shift without pressing the Select

lever button.

Select lever

button

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

DRIVER’S AREA

(if equipped)

1Headlights

2 Headlightasher,High/Lowbeamchange

3Turn signal

(if equipped)

Headlight switch/ Turn signal lever/ Front fog light switch (if equipped)

4Front fog lights (if equipped)

To turn on the front fog lights, rotate dial to .

Front fog lights operate only when headlight switch

is in:

- position.

- AUTO position and the headlights are on.

A L

F K

B C

1Windshield wiper

To operate the wiper, rotate knob to;

: Mist (for a single wipe)

: Off

: Intermittent

: Low speed

: High speed

2Wiper intermittent time control

3Windshield washer

4Rear window wiper and washer (5-door)

To operate the wiper, rotate knob to;

: Continuous

: Intermittent

: Off

: Washer

Rotate knob to . The washer uid sprays and the

wiper operates.

Wiper and washer switch

To turn on the hazard warning asher, push the button.

Use the hazard warning asher when you have to park

under emergency conditions.

 Hazardwarningasherswitch

Turn the dial to adjust the illumination brightness of the

instrument panel.

To brighten, turn the control dial upward.

To darken, turn the control dial downward.

When the control dial is turned fully upward, the

illumination brightness becomes the maximum and the

automatic dimming function does not work at all.

Illumination brightness control dial

*The design may be slightly different from the

illustration depending on the models.

Type A

Type B

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

1Defroster button:

Press the button to defrost the windshield.

2, Rear window defogger button:

Press the button to turn on rear window defogger,

outside mirror defogger or windshield wiper deicer

(if equipped). The function will automatically shut off

after approximately 15 minutes.

*The illustration of the print is Type A.

Defroster button/ Rear window defogger button

Trunk lid release lever (4-door)

Hood lock release knob

To open the trunk lid, pull the lever

upward.

Internal trunk lid release handle

To open the trunk lid from inside the trunk,

pull the handle upward.

Pull

1Lock switch

2For driver’s window (with one-touch

auto up and down feature)

3For front passenger’s window

4For rear left window

5For rear right window

Power window switches

To unlock all doors and the rear gate (5-door)

To lock all doors and the rear gate (5-door)

Power door locking switch

 Fuelllerlidreleaselever

Seat heater (if equipped)

1HI : Rapid heating

2LO : Normal heating

This indicates that the fuel ller door (lid) is

located on the right side of the vehicle.

Pull

Right side

Pull

5-door 4-door

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Located on the edge of each rear door.

When the lever is in the LOCK position, the rear door

cannot be opened from the inside.

Moonroof switches (if equipped)

Child safety locks

Audio control buttons

These buttons allow the driver to control audio functions

without taking his/ her hands off the steering wheel.

Tilting Sliding

1Raise

2Lower

1Open

2Close
