Subaru CROSSTREK 2020 User manual

2020 Quick Reference Guide

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Remote keyless entry system

Remote

transmitter key

(if equipped)

Access key

(if equipped)

Lock/Unlock doors

PANIC

*Grip the driver’s door handle to unlock the

driver’s door. Grip the front passenger’s door

handle to unlock all doors and the rear gate.

All doors and the rear gate will be locked/unlocked by the following procedures carrying the

access key on your person. (The driver should always carry the access key.)

Keyless access function (if equipped)

Side door (front door handles only):

1All doors and the rear gate will be locked.

2The driver’s door will be unlocked.

(To unlock all doors and the rear gate, briey

press the button a second time within 5

seconds.)

3Press the button to open the rear gate.

4The horn will sound and the hazard warning

ashes will ash.

BASIC OPERATION

For detailed operating and safety information, please refer to

your Owner’s Manual.

Lock

Unlock*

Door lock sensor

Grip

Touch

Rear gate:

Press

Unlock

Lock

Press

Ignition switch must be in ACC or ON position.

1Select side to adjust.

2To adjust the mirror, move the switch in the

direction of your desired position.

Adjust each component

1Forward and backward adjustment

2Seat height adjustment

3Seatback reclining adjustment

Tilt/telescopic steering wheel

Remote control mirror switch

1Adjust the seat position and pull the tilt/

telescopic lock lever down.

2Move the steering wheel to the desired level.

3Pull the lever up to lock the steering wheel in

place.

Make sure that the steering wheel is securely

locked by moving it up and down, and forward and

backward.

Driver’s seat

1Forward and backward adjustment

2Seat height adjustment

3Seatback reclining adjustment

Power seat (if equipped)

Manual seat (if equipped)

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Start/Stop engine

To start engine:

STEP1: Carry the access key, and sit in the driver’s

seat.

STEP2: Apply the parking brake.

STEP3: Shift the select lever into the Pposition.

STEP4: Depress the brake pedal until the indicator on

the push-button ignition switch turns green.

STEP5: While depressing the brake pedal, press the

push-button ignition switch.

To stop engine:

STEP1: Stop the vehicle completely.

STEP2: Move the select lever to the Pposition.

STEP3: Press the push-button ignition switch.

OFF ( Turned off ) ACC (Orange) ON (Orange)

Change of the power supply (Without starting engine)

The key can be turned from ACC to LOCK only when

the key is pushed in while turning it (all models) and the

select lever is in the Pposition (CVT models).

Push-button ignition switch (if equipped)

Ignition switch (if equipped)

Every time the button is pressed without depressing the brake pedal, the power is switched

in the sequence of OFF➞ACC➞ON➞OFF.

Operation

indicator

Operate Select lever/Shift lever

Continuously variable transmission (if equipped)

Models with

L position

Models with

manual mode

Shift paddle:

Gearshifts can be performed using the shift paddle

behind the steering wheel.

With the brake pedal depressed,

shift while pressing the Select

lever button in.

Shift while pressing the Select

lever button in.

Shift without pressing the Select

lever button.

L = L position:

Lis for using engine braking when going down a hill, etc. To select this mode, move the

select lever from the Dposition to the Lposition.

M = Manual mode:

With the vehicle either moving or stationary, move the select lever from the Dposition to the

Mposition to select the manual mode.

You must raise the slider and hold it in that position

before you can move the shift lever to the Rposition.

To change gears, fully depress the clutch pedal,

move the shift lever, and gradually let up on the

clutch pedal.

Manual transmission (if equipped)

Select lever

button

Downshift Upshift

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

MAIN PARTS AND OPERATION

1Headlights

2 Headlightasher,High/Lowbeamchange

3Turn signal

Headlight switch/Turn signal lever/Front fog light switch (if equipped)

The high beam assist function automatically

changes the headlight from high beam to low beam

(or vice versa).

The high beam assist function is activated

when:

1. The light control switch is in the AUTO position

and the low beam headlights are on automatically.

2.The turn signal lever is pushed forward.

When the high beam assist function is activated, the

indicator on the combination meter will illuminate.

High beam assist function (if equipped)

High beam assist indicator

* For models equipped with AUTO position.

GHD

1Windshield wiper

To operate the wiper, rotate knob to;

: Mist (for a single wipe)

: Off

: Intermittent

: Low speed

: High speed

2Wiper intermittent time control

3Windshield washer

4Rear window wiper and washer

To operate the wiper, rotate knob to;

: Continuous

: Intermittent

: Off

: Washer

Rotate knob to . The washer uid sprays and the

wiper operates.

Wiper and washer switch

To turn on the hazard warning asher, push the

button.

Use the hazard warning asher when you have to

park under emergency conditions.

 Hazardwarningasherswitch

4Front fog lights (if equipped)

To turn on the front fog lights, rotate dial to .

Front fog lights operate only when headlight switch

is in...

- position.

- AUTO position and the headlights are on.

* For models equipped with AUTO position.

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Turn the dial to adjust the illumination brightness of the

instrument panel.

To brighten, turn the control dial upward.

To darken, turn the control dial downward.

When the control dial is turned fully upward, the

illumination brightness becomes the maximum and the

automatic dimming function does not work at all.

Illumination brightness control dial

1Defrosting:

Press the defroster button to defrost the windshield.

2Defogger and deicer:

Press the button to turn on rear window defogger,

outside mirror defogger and windshield wiper

deicer. The function will automatically shut off after

approximately 15 minutes.

*The design may be slightly different from the

illustration depending on the models.

Defroster button/Rear window defogger button

Hood release knob

Pull

1For front left window

2For front right window

3For rear left window

4For rear right window

5Lock switch

Power window switches

Power door locking switch

1To lock all doors and the rear gate

2To unlock all doors and the rear gate

 Fuelllerlidreleaselever

This indicates that the fuel ller door (lid) is

located on the right side of the vehicle.

1 2

Pull

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Located on the edge of each rear door.

When the lever is in the LOCK position, the rear door

cannot be opened from the inside.

Pull the release knob

and slide the anchor

down.

Child safety locks

Front seat shoulder belt anchor height

To lower To raise

Pull the release knob

and slide the anchor

up.
