Integrated Drawer

Service Manual

Page 2

2-2

#7030768 - Revision B - May, 2015

Electronic Control Info. INTEGRATED SERIES (DRAWERS)

INTEGRATED SERIES (DRAWERS)

ELECTRONIC CONTROL TERMINOLOGY & COMPONENT DESCRIPTIONS

The appliances described in this manual utilize an electronic control system which monitors, regulates, controls and

displays a variety of functions and operations in the appliance.

The table below defines some of the basic electronic control system terminology.

Term/Component Definition / Description

Main Control Board ..……….… (Also referred to as the Main “Controller” Board), is the printed-circuit board (PC

Board) which contains a microprocessor, relays, triacs and electrical connections

that monitor and control all functions of the appliance.

Microprocessor ……….….…... An electrical component on the control board which receives electrical signals from

other components, processes the information, then sends electrical signals to relays

and triacs on the board to open or close, switching components in the appliance

ON or OFF.

Relay ……………………….…. An electrical component on the control board which switches other components in

the appliance ON or OFF when instructed to do so by the microprocessor.

Triac ……………………....…… Similar in function to a relay, the triac is a three terminal semiconductor for control-

ling current in either direction.

User Interface Module (UIM) .. (a.k.a. Control Panel or Key Pad), is that part of the electronic control system where

all manual input operations are performed, also where all icons, words and codes

are displayed

LCD (Liquid Crystal Display) ... A semi-liquid substance sandwiched between glass in the control panel assembly.

The molecules of this semi-liquid substance have no specific orientation. However,

when electricity is applied to them, they react predictably, aligning and straightening

in such a way as to control light passage. In doing so, they can be manipulated

and arranged to form the indicators that appear in the LCD.

Indicators .....………….………... The icons, numbers and words that appear at the LCD

Fault Codes (Error Codes) ........The code number indicators that appear on the LCD during diagnostic mode This

coded data represents current and/or historical problematic events that specific

electronic components may have experienced.

Display Units of Measure……... Temperatures displayed at the LCD may be in fahrenheit units of measure (°F) or

celsius units of measure (°C). A series of key strokes allows the temperature dis-

play units of measure to be switched to read as either °F or °C.

Set-Point ……………………….. The zone temperature, established by pressing the COLDER or WARMER keys.

High Offset (Cut-in)……….….....As the zone air temperature cycles up and down, the high offset is the maximum

zone temperature that the electronic control system will allow before calling for

cooling.

Low Offset (Cut-out)…….……... As the zone air temperature cycles up and down, the low offset is the minimum

zone air temperature that the electronic control system will allow before interrupting

cooling.

Thermistor....….......................... (a.k.a. a Temperature sensor) A resistor with which resistance changes as the tem-

perature around it changes. For electronic control system purposes, the micro-

processor measures this resistance and displays it as a temperature reading at the

LCD.

Page 3

2-3 #7030768 - Revision B - May, 2015

INTEGRATED SERIES (DRAWERS)

INTEGRATED SERIES (DRAWERS) Electronic Control Info.

Figure 2-1. ID-30C/I and ID-3 Electronic Control System Schematic

N.O.

HIGH VOLTAGE

LOW VOLTAGE

115 VOLTS

60 CYCLES

L1 NEUTRAL

WHITE

BLACK

WHITE

TAN/WHITE

ICEMAKER WATER VALVE 160 Ω

MAIN CONTROL

BOARD

(DOT

DENOTES

PIN #1

LOCATION)

ST-1 ST-3 ST-4

4321

12345

ST-2

321

123456

ST-5

ST-12 ST-8 ST-9

ST-7 ST-10

ST-13

ST-11

UPPER

DRAWER SWITCH

BLACK

BLUE

PURPLE

GRAY/WHITE

BLUE

GRY/WHT

TAN

PINK

TAN/WHITE

ICEMAKER

DEF HEATER 30-26 Ω

FILL TUBE HEATER 1924-2261 Ω

FRE COMPRESSOR

STARTING RELAY

DEFROST

TERMINATOR

WHITE

TAN

REF EVAP FAN

CONDENSER FAN

RED

YLW/ORN

BLUE/ORN

RED

YELLOW

BLUE

BLACK/RED

MAIN CONTROL

BOARD

(DOT

DENOTES

PIN #1

LOCATION)

ST-1 ST-3 ST-4

ST-2

ST-5

ST-12 ST-8 ST-9

ST-7 ST-10

ST-13

ST-11

ST-6

1234567

2 4 6 8 10 12

1 3 5 7 9 11

LOWER

DRAWER SWITCH

BLACK/ORANGE

YLLW/ORN

RED/ORN

N.O.

UPR DRWR

LED

LWR DRWR

LED

THERMISTOR REF CAB

THERMISTOR FRE CAB

THERMISTOR FRE EVAP

THERMISTOR CONDENSER

BLUE/PURPLE

BROWN

BLUE

BROWN

BLUE/ORANGE

BLUE/BLACK

BLK/YLW

YLW/BLK

RED/WHITE

YLW/RED

YLW/WHITE

BROWN/WHITE

KEYPAD

YELLOW/WHITE

YELLOW/RED

YELLOW/BLACK

YELLOW/BROWN

REF AIR DUCT

BAFFLE

BASIC ELECTRONIC CONTROL SYSTEM

The electronic control system consists of high voltage and low voltage (See Figure 2-1 for High voltage Wire

Schematic and Low Voltage Wire Schematic for the models ID-30C/I and ID-36C/I).

Input operations for the electronic control system are performed at the control panel (UIM), with monitoring, regulat-

ing and controlling taking place at the control board. Temperatures and possible problems with the unit are dis-

played at the UIM depending on input commands given. The electronic control system is described in greater detail

on the following pages.

Page 4

2-4

#7030768 - Revision B - May, 2015

Electronic Control Info. INTEGRATED SERIES (DRAWERS)

INTEGRATED SERIES (DRAWERS)

MAIN CONTROL BOARD

(DOT DENOTES

PIN #1 LOCATION)

ST-1 ST-3 ST-4

ST-6

ST-5 ST-7 ST-10

ST-13

ST-11

ST-9

ST-8

ST-12

ST-2

Figure 2-2. Control Board Layout

Figure 2-3. Control Board Summary Table (ID-30C/I and ID-36C/I Summary Table Shown)

CONTROL BOARD LAYOUT AND SUMMARY TABLE

The electrical connection points on the control board are labeled alphanumerically. These labels correspond with

the alphanumeric control board summary table, located on the wiring diagrams. By referencing the summary table,

it is possible to identify which components are connected at which connection points on the control board. Below is

a layout diagram of the control board, and a copy of a summary table. (See Figures 2-2 and 2-3)

NOTE: All components on the control board are non-replaceable. If a problem with the control board is identified,

the complete control board must be replaced.

120 VOLT CIRCUIT

LOW VOLTAGE CIRCUITS

LOW VOLTAGE CIRCUITS CONT.

THERMISTOR CIRCUITS

ID-C CONTROL BOARD SUMMARY

CIRCUIT DESCRIPTION FUNCTION COLOR CIRCUIT DESCRIPTION

POWER INTO BOARD

POWER FRE COMPRESSOR

UNUSED

POWER DEF HEATER

BLACK

PURPLE

BLUE

POWER IN (L1)

FRE COMPRESSOR

UNUSED

DEF HEATER

ICEMAKER

UNUSED

ICEMAKER WATER VALVE

POWER ICEMAKER

UNUSED

POWERS IM WATER VALVES

PINK

TAN/WHITE

LINE POWER SUPPLY

NEUTRAL

EARTH GROUND

POWER INTO BOARD

NEUTRAL INTO BOARD

GROUND

BLACK

WHITE

GREEN/YELLOW

ST1-1

ST1-2

ST1-3

ST1-4

FUNCTION COLOR

DRAWER SWITCH INPUT

UNUSED

YELLOW/BLACK

DRAWER SWITCH

UNUSED

ST9-1

ST9-2

ST9-3

ST9-4

UNUSED

ST9-5

ST9-6

ST9-7

ST9-8

GROUND BLACK/YELLOWDOOR SWITCH GROUNDST9-9

UNUSED

UIM POWER

RED/WHITE

UNUSED

UIM 12 V POWER

ST10-1

ST10-2

ST10-3

ST10-4

UIM CAN_H

UIM CAN_L

UIM RETURN

YELLOW/RED

YELLOW/WHITE

BROWN/WHITE

UIM CAN BUS

UIM GROUND RETURN

ST10-5

ST10-6

ST10-7

UNUSED

ST11-1

ST11-2

ST11-3

ST11-4

POWER OUT HALF BRIDGE 1

POWER OUT HALF BRIDGE 2

POWER OUT HALF BRIDGE 3

GRAY/WHITE

GRAY/RED

GRAY/BLACK

BAFFLE

ST11-5

ST11-6

ST11-7

POWER OUT HALF BRIDGE 4 GRAY/BROWNBAFFLEST11-8

UNUSED

ST12-1

ST12-2

ST12-3

UNUSED --UNUSEDST12-4

ST2-1

ST2-2

ST2-3

ST3-1

ST3-2

ST3-3

ST3-4

ST3-5

NEUTRAL NEUTRAL INTO BOARD WHITE

ST4-1

WATER VALVE INPUT SENSES WATER VALVE ACTIVATION TAN

ST4-2

NEUTRAL NEUTRAL INTO BOARD WHITE

ST4-3

DEF BI-METAL

SENSES WHEN DEF HEATER SHUTS OFF

GRAY/WHITE

ST4-4

UNUSED UNUSED --

ST4-5

UNUSED UNUSED --

ST4-6

UNUSED UNUSED --

ST7-1

UNUSED UNUSED --

ST7-2

UNUSED UNUSED --

ST7-3

UNUSED UNUSED --

ST7-4

EVAP FAN 12 VDC POWER EVAP FAN POWER RED

ST7-5

REF EVAP FAN VAR. SPEED CONTROL OUT YELLOW

ST7-6

REF EVAP FAN TACH INPUT BLUE

ST7-7

EVAP FAN GROUND RETURN EVAP FAN RETURN BLACK/RED

ST7-8

UNUSED UNUSED --

ST7-9

UNUSED UNUSED --

ST7-10

CONDENSER FAN VAR. SPEED CONTROL OUT YELLOW/ORANGEST7-11

CONDENSER FAN TACH INPUT BLUE/ORANGE

ST7-12

DRAWER LED DRAWER LED POWER RED/ORANGE

ST8-1

DRAWER LED DRAWER LED PWM YELLOW/ORANGE

ST8-2

DRAWER LED DRAWER LED GROUND BLACK/ORANGE

ST8-3

UNUSED UNUSED --ST8-4

UNUSED UNUSED

ST8-5

UNUSED UNUSED --

ST8-6

SENSES TEMPERATURE

SENSES TMEPERATURE

UNUSED

BLUE/ORANGE

BROWN

REF CABINET

UNUSED

ST6-1

ST6-7

ST6-2

UNUSED --UNUSEDST6-8

SENSES TEMPERATURE

BLUE

BROWN

BLUE/BLACK

FRE CABINET

FRE EVAPORATOR

ST6-3

ST6-9

ST6-4

SENSES TEMPERATURE BROWNFRE EVAPORATORST6-10

SENSES TEMPERATURE

UNUSED

BLUE/PURPLE

BROWN

CONDENSER

UNUSED

ST6-5

ST6-11

ST6-6

UNUSED --UNUSEDST6-12

Page 5

2-5 #7030768 - Revision B - May, 2015

INTEGRATED SERIES (DRAWERS)

INTEGRATED SERIES (DRAWERS) Electronic Control Info.

UIM (User Interface Module)

Please note that there are many possible UIM model configurations and many facets to, or “screens” on, the UIM in

general. For the sake of this section of the manual, a UIM for a ID-30C/I is displayed unless otherwise specified.

Following are renditions of the different Screens that may be viewed on the UIM.

Boot-up Screen

This screen would only be seen when power is initially supplied to the unit. (See Figure 2-4)

Power

Figure 2-5. Power Screen. Touch screen to Switch Unit On.

Loading, Please Wait...

0000000000

Figure 2-4. Initial Boot-up Only

Power Screen

This screen appears after initial boot-up. To switch the unit on, touch the screen and current internal temperature

readings will appear on the UIM. (See Figure 2-5)

power

° °

7070

Figure 2-6. Home Screen (ID-30C/I UIM Shown). Touch Appropriate Temperature to Adjust Set-Point

(Touch “power” for approximately two (2) seconds to switch unit off)

Home Screen

This screen appears after the power screen is touched meaning the unit is powered on. Real time temperatures are

shown. To view and/or adjust set-points touch the appropriate zone temperature (See Figure 2-6)

Figure 2-7. Set-Point Adjust Screen. Touch Appropriate “+” or “-” icon to Adjust Set-Point

Temperature Set-Point Adjust Screen

This screen appears after a temperature reading is touched. Adjust the set-point by touching the “+” or “-” icon in

multiple strokes (See Figure 2-7). Freezer Temperature range is -5°F (-21°C) to 5°F (-15°C); Refrigerator is 34°F

(1°C) to 45° (7°C). When done, touch the te temperature to return to the home screen.

Page 6

2-6

#7030768 - Revision B - May, 2015

Electronic Control Info. INTEGRATED SERIES (DRAWERS)

INTEGRATED SERIES (DRAWERS)

select option

Figure 2-9. Option Screen - Freezer Only (ID-30F/I) and Combo Freezer/Refrigerator (ID-30C/I, ID-36C/I)

select option

Figure 2-10. Option Screen - Refrigerator Only w/Air Purifier (ID-30RP, ID-36RP)

select option

Figure 2-11. Option Screen - Refrigerator Only w/o Air Purifier (ID-24R, ID-27R, ID-30R, ID-36R)

Option Screen

After a unit has been switched on, whenever the top drawer is opened the option screen will appear for 2 to 4 sec-

onds, or from the home screen press the arrow icon. below are the different option screens depending on the

model. Touch the icon option desired on or off (see Option Screens Icon table below). A dark icon means that fea-

ture is active.

OPTIONS SCREEN ICONS

Touch to activate or deactivate ice maker system

and max ice feature.

Touch to activate or deactivate door/drawer alarm.

system.

Touch to view settings screen.

Figure 2-12. Option Screen Icons Explained

NOTE: Touching the arrow icon will return to the home screen, or wait 10 - 15 seconds after the last icon press.

Page 7

2-7 #7030768 - Revision B - May, 2015

INTEGRATED SERIES (DRAWERS)

INTEGRATED SERIES (DRAWERS) Electronic Control Info.

Settings Screen

Touching the settings icon (the cog) will bring up the settings screen, allowing the different settings to be adjusted.

The settings screen scrolls in a loop, but the icons are shown in static format below (See Figure 2-14). Also see

Settings Screen Quick reference Table (See Figure 2-15).

Settings

Figure 2-14. Settings Screen and All Icons

SETTINGS SCREEN QUICK REFERENCE TABLE

Touch to view model information.

Touch to select temperature unit, Fahrenheit or Celsius.

Touch to adjust control panel brightness and contrast.

Touch to adjust door/drawer alarm volume and pitch.

Touch to adjust door/drawer alarm duration.

Touch to enter Sabbath mode.

Touch to view troubleshooting and service information.

Touch to set clock.

Touch to select smart home options.

(Not availabel at this writing)

Touch to select language options.

Touch to adjust soft on lighting.

Figure 2-15. Settings Screen Quick Reference

Lighting Screen

Choose the lighting screen (light bulb icon) to adjust the lighting delay effect and the intensity. Touch the appropriate

slide bar(s) to adjust (See Figure 2-16).

NOTE: Touching the Arrow key wil step back one screen. If the screen is not touched for 10 to 15 seconds, the

home screen will reappear.

Soft On

Dimming Accent

Figure 2-16. Lighting Screen

Page 8

2-8

#7030768 - Revision B - May, 2015

Electronic Control Info. INTEGRATED SERIES (DRAWERS)

INTEGRATED SERIES (DRAWERS)

Clock Screen

Choose the clock screen to view or adjust the clock time. Touch the hour, minute or the AM / PM indicator to adjust

the appropriate icons (See Figure 2-17).

NOTE: Touching the Arrow key wil step back one screen. If the screen is not touched for 10 to 15 seconds, the

home screen will reappear.

:17

Clock

Figure 2-17. Clock Screen (changing minutes)

Language Screen

Choose the language screen (globe icon) to display the words on the UIM in the desired language. Touch the lan-

guage desired (See Figure 2-18).

NOTE: Touching the Arrow key wil step back one screen. If the screen is not touched for 10 to 15 seconds, the

home screen will reappear.

Languages

English Spanish Italian

French German

Figure 2-18. Language Screen (choosing English)

Information Screen

Choose the information screen (circle with an “i” in the middle icon) to display filter life, versions of the software,

error codes and serial numbers. Touch the heading of the information to be displayed (See Figure 2-19).

NOTE: Touching the Arrow key wil step back one screen. If the screen is not touched for 10 to 15 seconds, the

home screen will reappear.

Info

Filters Versions Errors

Customer Service 1-800-222-7820

Serial#

Figure 2-19. Information Screen

Page 9

2-9 #7030768 - Revision B - May, 2015

INTEGRATED SERIES (DRAWERS)

INTEGRATED SERIES (DRAWERS) Electronic Control Info.

Temperature Units of Measure Screen (choosing Fahrenheit or Celsius Temperature Display)

Choose the Temperature Units of Measure screen (°C/°F icon) to view or change the units of measure. To choose,

touch the desired unit of measure (See Figure 2-20).

NOTE: Touching the Arrow key wil step back one screen. If the screen is not touched for 10 to 15 seconds, the

home screen will reappear.

Select Units

°C °F

Figure 2-20. Units of Measure Screen (Fahrenheit chosen)

Brightness and Contrast Screen (choosing Fahrenheit or Celsius Temperature Display)

Choose the brightness and contrast screen (1/2 dark sun icon) to view or change the brightness and/or contrast of

the LCD of the UIM. Touch the appropriate slide bar(s) to adjust (See Figure 2-21).

NOTE: Touching the Arrow key wil step back one screen. If the screen is not touched for 10 to 15 seconds, the

home screen will reappear.

Brightness & Contrast

Figure 2-21. Brightness & Contrast Screen

Sound Screen

Choose the drawer alarm volume and pitch with this screen (speaker icon) to view or change the volume and/or

pitch of the alarm when a drawer is left open. Touch the appropriate volume or pitch icon(s) to adjust (See Figure 2-

22).

NOTE: Touching the Arrow key wil step back one screen. If the screen is not touched for 10 to 15 seconds, the

home screen will reappear.

Sound

Volume Pitch

Figure 2-22. Brightness & Contrast Screen

Page 10

2-10

#7030768 - Revision B - May, 2015

Electronic Control Info. INTEGRATED SERIES (DRAWERS)

INTEGRATED SERIES (DRAWERS)

Drawer Alarm Time Screen

Choose the drawer alarm time screen (bell with clock inside icon) to adjust the amount of time it takes for a drawer

to be open before the alarm chimes when a drawer is left open. Touch the appropriate “+” or “-” icon to adjust (See

Figure 2-23).

NOTE: Touching the Arrow key wil step back one screen. If the screen is not touched for 10 to 15 seconds, the

home screen will reappear.

60S+-

Door Alarm Time

Figure 2-23. Drawer Alarm Time Screen (sixty seconds chosen)

Star-K (Sabbath Mode) Screen

Choose the Star-K screen (Star with “K” inside icon) to enable the Sabbath mode. Press and hold the Star-K icon

for the (10) seconds to enable Sabbath mode (See Figure 2-24). When in Sabbath mode the screen will go dark

and slowly flash “Sabbath: Touch Screen for 5s to Exit” (See Figure 2-25). This will then return to the home screen.

Press and Hold 10s

to Enable Sabbath

Figure 2-24. Star-K Screen (Press Star-K for 10 Seconds to Enable Sabbath Mode)

Sabbath: Touch

Screen for 5s to Exit

Figure 2-25. Star-K Active Screen (Touch Screen for 5 seconds to Exit)

This manual suits for next models

Table of contents

Other Sub-Zero LCD Drawer manuals

Sub-Zero

Sub-Zero CW24 User manual

Sub-Zero

Sub-Zero WOLF ICB User manual

Popular LCD Drawer manuals by other brands

Acnodes

Acnodes KD 8228 user manual

Ameriwood

Ameriwood 9524328PCOM manual

Kesseböhmer

Kesseböhmer TANDEM solo Mounting instructions

Crystal Image Technologies

Crystal Image Technologies RMD-151-A Series user manual

APW Wyott

APW Wyott Ease Extreme HDX-1-120 Installation and operating instructions

NTI

NTI RACKMUX-V17-N Installation and operation manual

Austin Hughes

Austin Hughes CyberView L120 user manual

Uplift Desk

Uplift Desk STR018 manual

Acnodes

Acnodes KDC 81932 user manual

Acnodes

Acnodes RK1200T user manual

StarTech.com

StarTech.com DuraView RACKCONS1501 instruction manual

Mocka

Mocka Mischa Assembly instructions

GRASS

GRASS DWD XP manual

StarTech.com

StarTech.com DuraView RACKCONS1701 instruction manual

Fisher & Paykel

Fisher & Paykel IZONA CoolDrawer RB36S installation instructions

Synergy Global Technology

Synergy Global Technology LCD1U17-44 user manual

Fujitsu

Fujitsu RC25 user manual

Acnodes

Acnodes RK 1000B installation guide
