Stelpro Dragon ADRI User manual

INSADR0116

USER’S GUIDE

ADR SERIES

CEILING FAN HEATER

REPLACEMENT COMPONENT LIST INCLUDED

This unit

complies with

the CSA and

UL standards

For further information or to consult this guide online, please visit our website at www.stelpro.com

Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep them handy for future

reference. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems no further responsibility for this

product.

certified electrician, according to the electrical and building codes effective

in your region.

The following instructions must be adhered to in order to avoid personal injuries or property damages, serious injuries and potentially fatal electric shocks.

Protect the heating unit with the appropriate circuit breaker or fuse, in accordance with the nameplate.

Make sure the line voltage (volt) is consistent with that indicated on the unit’s nameplate.

This unit must be grounded.

Switch off the power at the circuit breaker/fuse before installing, repairing and cleaning the unit.

Make sure the unit is appropriate for the intended use (if needed, refer to the product catalog or a representative). Use this heater only as described in this



RECOMMENDED HEATING CAPACITY : 1.25 W/cubic foot (0.03 m³)

It corresponds to 10 W/square foot (0.09 m²)

   

required capacity to heat a room. If needed, refer to a specialist (industrial and commercial buildings) who will be able to calculate these heat losses and

optimize the required capacity or consult the “Online heating calculation” section of the Stelpro Design Web site (residential buildings). To heat a large room

and to increase your comfort, it is recommended to install several units instead of one. For example, 2 X 1000 W rather than 1 X 2000 W.



Respect distances and positions indicated in the installation section.

WARNING IMPORTANT INSTRUCTIONS

MATÉRIEL | MATERIAL :

1 / 1

# PIÈCE | PART # :

CRÉÉ LE | CREATED ON :

CRÉÉ PAR | CREATED BY : DR-1, DR-R & DR-2

FEUILLE | SHEET :

MIS À JOUR | UPDATED :

X:\01_PRODUITS\FAMILLES\DR\DOCUMENTATION\DR_COUVERTURE MANUEL.dft

TROISIÈME ANGLE DE

PROJECTION

THIRD ANGLE PROJECTION

FORMAT | SIZE :

DESCRIPTION :

TOLÉRANCES SI NON-SPÉCIFIÉES | TOLERANCES IF NOT SPECIFIED

ANGULAIRE | ANGULAR:

±.03"

±.015"

.XX

.XXX

[ ±.76mm ]

[ ±.38mm ]

±1°

±0.5°

XX°

XX.X°

adesmarais

2009-02-10

2013-09-11 / adesmarais

EMPLACEMENT:

LINÉAIRE | LINEAR:

L'INFORMATION CONTENUE DANS CE

DOCUMENT EST LA PROPRIÉTÉ DE

STELPRODESIGN. EN AUCUN CAS,

L'INFORMATION NEPEUT ÊTRE

UTILISÉE, SAUF SOUS AUTORISATION

ÉCRITE DE STELPRODESIGN.

THE INFORMATION IN THIS DOCUMENT

IS THEPROPERTY OF STELPRO DESIGN.

IN ANY CASE, THE INFORMATION CAN'T

BE USED,EXCEPT BY THEWRITTEN

CONSENT OF STELPRO DESIGN.

2INSADR0116

WARNING



This unit must not come into contact with a water source and must be protected from splashes. Do not use it if any part has been immersed.

When mounting the unit, make sure that the anchorage used can support the total weight of the unit with the mounting brackets.

When cutting or drilling into a ceiling, do not damage electrical wiring and other hidden utilities.



Because this unit is hot when in use, it may pose risks even in normal operation. Therefore, be careful and responsible when using it. To avoid burns, do not

let bare skin touch hot surfaces. The unit must cool down for few minutes since it will stay warm for some time after shut down. Extreme caution is necessary

when any heater is used by or near children or invalids and whenever the heater is left operating and unattended.





keep them at least 24 inches (61 cm)



Never block air vents (with objects or other items). You risk damaging the heater and the obstruction could lead to electric shock or overheating, which could









products. Store it in a dry place when not using it.

Some areas are dustier than others. Thus, it is the user’s responsibility to evaluate if the unit must be cleaned based on the amount of dirt accumulated on



in accordance with these instructions.

The thermal protection activation indicates that the unit has been subjected to abnormal operating conditions. If the thermal protection remains activated or



damaged. (Refer to the limited warranty)

Before unplugging the unit, all controls must be in the “OFF” position and the current from the main breaker panel should be cut. (The general switch may be

used also, if included.)



to the limited warranty).

SPECIFICATIONS

CEILING FAN HEATER

MODELS ADRI ADRII ADRR

VOLTS 208 V / 240 V 208, 240, 277, 347, 480 AND 600 V 208, 240, 277, 347, 480 AND 600 V

WATTS 2000 TO 5000 W 2000 TO 10000 W 2000 TO 5000 W

WEIGHT 16 LB / 7,2 KG 45 LB / 20,4 KG 16 LB / 7,2 KG

LENGTH 16” / 406 MM  23 5/8” / 600 MM

WIDTH 16” / 406 MM  23 5/8” / 600 MM

HEIGHT 5 1/8” / 130 MM 6 9/16’’ / 167 MM 

ADRI

TECHNICAL DRAWINGS

SAVE THESE INSTRUCTIONS

SPECIFICATIONS AND TECHNICAL DRAWINGS

TOP



FRONT

BOTTOM

1 1/4"

32mm

1 1/4"

32mm

1 1/2"

39mm

O7/8"

22mm

5 1/8"

130mm

16"

406mm

16"

406mm

3INSADR0116

TECHNICAL DRAWINGS

ADRII

ADRR

INSTALLATION

SPECIFICATIONS AND INSTALLATION

N.B. Cut off power supply at circuit breaker/fuse before proceeding to the installation and wiring connections. This product must be



found on the unit.



in contact with combustible material. Do not mount in close proximity to another unit.



for a suspended installation are not provided with the unit.



For best results, do not exceed the following recommended mounting heights:

UNITS MAXIMUM MOUNTING HEIGHTS

2 or 3 kW 8 ft. (2.44 m)

4 or 5 kW 10 ft. (3.04 m)

7.5 or 10 kW 12 ft. (3.66 m)

Depending on the model, keep at least 12 or 24 inches away from any vertical surfaces or walls (see drawings on next page).

BOTTOM



FRONT

TOP

6 9/16"

167mm

1 7/16"

37mm

3 3/16"

81mm

22 3/8"

568mm

22 3/8"

568mm

2 7/16"

62mm

O7/8"

22mm



TOP

BOTTOM

O7/8"

22mm

1 1/16"

26mm

1 1/2"

38mm

23 5/8"

600mm

23 5/8"

600mm

O7/8"

22mm

1 1/4"

32mm

25mm

4 3/16"

106mm 4 15/16"

125mm

22 9/16"

573mm

22 1/2"

571mm

4INSADR0116

ADRI and ADRII

1. Remove the external cover of the unit and set it aside (4 screws).

2. Remove the mounting bracket (1 or 2 screws and hinges depending on the model).

3. Screw the mounting bracket to the ceiling and make sure the ceiling structure

is strong enough to support the unit. Make sure the mounting bracket is

installed in such a way that the unit will sit straight and level.

4. Remove the wiring compartment cover and set it aside.

5. Hook the slotted side of the internal assembly to the mounting bracket. Let

the unit hang from the bracket.

             

mounted thermostat must be installed to control the heater.

7. Run the electrical supply cable up to the wiring compartment of the unit.

           

made while the unit is still hanging from the bracket.

8. Make the electrical connections using the supplied wire connectors

(marrettes). Connect the ground wire to the grounding screw. Make sure all



and L2 wires to one of the power supply leads and connect the L1 wire to the

other power supply lead. Note that the Fan mode option will not be available

with this type of installation.)

9. Replace the wiring compartment cover. Swing the other half of the interior

assembly into position and screw the assembly to the bracket with the

screw(s) previously removed in step 2.

10. Replace the external cover and screw it into place with the four screws

removed in step 1.

11. Test the unit to make sure it is running properly.

ADRR

N.B. This product has been designed to be installed into a suspended ceiling,

not into a closed ceiling. Keep in mind that if you intend on recessing it

into a closed ceiling, you will not have access to it for maintenance and/or

repair purposes in the future.

1. Remove the wiring compartment cover and set it aside.

2. Run the electrical supply cable up to the wiring compartment of the unit.

3. Make the electrical connections using the supplied wire connectors

(marrettes). Connect the ground wire to the grounding screw. Make sure all

and L2 wires to one of the power supply leads and connect the L1 wire to the

other power supply lead. Note that the Fan mode option will not be available

with this type of installation.)

4. Replace the wiring compartment cover.

             

mounted thermostat must be installed to control the heater.

6. This product has been designed to be installed into a suspended ceiling,

therefore there are no mounting brackets supplied with the unit; it must be

supported by the metal framing of the suspended ceiling.

7. Test the unit to make sure it is running properly.

All other repairs and maintenance other than those described in

        

            

regularly. Cut off power supply at circuit breaker/fuse and wait for

the unit to cool down before cleaning.

              

abrasive dish soap. Do not use abrasive or chemical cleaners because they

               

vacuum brush to remove dust and other foreign objects from the grilles. Note

that cigarette smoke could yellow the discharge grille and that the best way to

prevent it is to clean the unit on a regular basis.



          

if the thermostat is set off. This means that there is a risk of

electric shock as long as the unit is energized.

MAINTENANCE

MINIMUM

12"

[305mm]

MINIMUM

12"

[305mm]

MINIMUM

24"

[610mm]

MINIMUM

24"

[610mm]

MINIMUM

12"

[305mm]

MINIMUM

12"

[305mm]

INSTALLATION, OPERATION AND MAINTENANCE

OPERATION

WARNING: the heater must be properly installed before it is used.

ADRI ADRII ADRR

5INSADR0116

REF. # PART # DESCRIPTION

1 CONTACTOR 30A 2 POLES 240/208 V

1 CONTACTOR 30A 2 POLES 24 V

1 CONTACTOR 35A 2 POLES 120 V

1 CONTACTOR 35A 3 POLES 24 V

1 CONTACTOR 40A 3 POLES 208/240 V

1 CONTACTOR 40A 3 POLES 120 V

1 CONTACTOR 50A 3 POLES 120 V

2 BLADE 9” 26” 5B (2 TO 5 KW)

2 BLADE 10” 26” (7.5 TO 10 KW)

3 SWITCH (SPDT)

3 SWITCH (DPDT) HI/LOW

4 PILOT LIGHT 240 V

4 PILOT LIGHT 120 V

4 PILOT LIGHT 24 V

5 ENCLOSED MOTOR 240 V (2 TO 5 KW)

5 MOTOR 240 V (7.5 TO 10 KW)

5 MOTOR 600 V/3PH (15 TO 40 KW)

6 PROTECTION L150

7 RELAY 240 V

7 R841C1011 RELAY 208/24 V

7 R841C1029 RELAY 240/24 V

7 RE153T ELECTRONIC RELAY (15 A MAX AND 347 V MAX)

8 THERMOSTAT SP

8 THERMOSTAT SP

9 TRF200025 TRANSFORMER 240/24/25VA

9 TRF200040D 

9 TRF300025 TRANSFORMER 347/24/25VA

9 TRF320100 TRANSFORMER 347/240/100VA

9 TRF410200D TRANSFORMER 347/240/200VA

9 TRF320150 TRANSFORMER 347/240/150VA

9 TRF600025 TRANSFORMER 600/24/25VA

9 TRF620100 TRANSFORMER 600/240/100VA

9 TRF620200 TRANSFORMER 600/240/200VA

9 TRF620025 TRANSFORMER 600/240/25VA

9 TRF620150 TRANSFORMER 600/240/150VA

9 TRF210025D 

9 TRF310025D 

9 TRF500025D 

9 TRF510100D 

9 TRF520150 TRANSFORMER 480/240/150VA



TROUBLESHOOTING

N.B. If you do not solve the problem after checking these points, cut off the power supply at the main electrical panel and contact our customer service (see the

“Limited warranty” section to obtain the phone numbers).

PROBLEM DEFECTIVE PART OR PART TO CHECK

The unit does not work

 Defective thermostat or wrong thermostat setting

 Open circuit breaker or fuse

 The thermal protection has been activated

 Faulty connections

The unit runs continuously  Defective thermostat or wrong thermostat setting

 Heat losses higher than the unit capacity

The enclosure is extremely hot

 Defective thermal protection

 Blocked air vents

 Defective motor

The unit cycles under control of the thermal protection

(overheat indicator)

 Blocked air vents

 Defective motor

Overheating  Defective motor

 Defective thermostat or wrong thermostat setting

The breaker trips when the heater is turned on  Faulty connections

 Voltage higher than that written on the nameplate

Elements are on, but the motor does not work  Defective motor

The desired room temperature cannot be reached

 One or more elements are defective

 Defective thermostat or wrong thermostat setting

 Voltage lower than that written on the nameplate

 Heat losses higher than the unit capacity

REPLACEMENT COMPONENT LIST

REF. # PART # DESCRIPTION

9 TRF520200D 

9 TRF610025D 

9 TRF610050D 

9 TRF700025 TRANSFORMER 277/24/25VA

9 TRF810025D 

10  GRILLE (DRI)

10  GRILLE (DRII)

10  GRILLE (DRR)

11  FUSE HOLDER 2 POLES 600V

11  FUSE HOLDER 2 POLES 600V

12  FUSE 15A CLASS CC 600V T.D.

12  FUSE 25A CLASS CC 600V T.D.

12  FUSE 45A CLASS J 600V T.D.

- FUSE LINK KIT

LIST OF REPLACEMENT COMPONENTS

6INSADR0116

STELPRO DESIGN INC. | Saint-Bruno-de-Montarville | Québec | J3V 6L7

This limited warranty is offered by Stelpro Design Inc. (“Stelpro”) and applies to the following products made by Stelpro: models ADRI, ADRII and

ADRR. Please read this limited warranty carefully. Subject to the terms of this warranty, Stelpro warrants its products and their

components against defects in workmanship and/or materials for the following periods from the date of purchase: 3 years. This warranty applies only



CLAIM PROCEDURE

If at any time during the warranty period the unit becomes defective, you must cut off the power supply at the main electrical panel and contact 1)

your installer or distributor, 2) your service center or 3) Stelpro’s customer service department. In all cases, you must have a 

and provide the information written on the product nameplate. Stelpro reserves the right to examine or to ask one of its representatives to

examine the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase

price or repair a defective part. Please note that repairs made within the warranty period must be authorized in advance in writing by Stelpro and

carried out by persons authorized by Stelpro.

Before returning a product to Stelpro, you must have a Stelpro authorization number (RMA). To obtain it, call the customer service department at:

1-800-363-34141-800-343-10221-866-766-6020 (consumers).

The authorization number must be clearly written on the parcel or it will be refused.



This warranty is exclusive and in lieu of all other representations and warranties (except of title), expressed or implied, and Stelpro expressly disclaims



Stelpro’s liability with respect to products is limited as provided above. Stelpro shall not be subject to any other obligations or liabilities whatsoever,

whether based on contract, tort or other theories of law, with respect to goods or services furnished by it, or any undertakings, acts or omissions

relating thereto. Without limiting the generality of the foregoing, Stelpro expressly disclaims any liability for property or personal injury damages,

          

services, shutdowns, slowdowns, or for other types of economic loss or for claims of a dealer’s customers or any third party for such damages. Stelpro



This warranty does not cover any damages or failures resulting from: 1) a faulty installation or improper storage; 2) an abusive or abnormal use, lack

of maintenance, improper maintenance (other than that prescribed by Stelpro) or a use other than that for which the unit was designed; 3) a natural

disaster or an event out of Stelpro’s control, including, but not limited to, hurricanes, tornadoes, earthquakes, terrorist attacks, wars, overvoltage,



negligence of the user or owner of the product. Moreover, it does not cover the cost of disconnection, transport, and installation.

The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, at the discretion of Stelpro. Any parts

replaced or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original warranty

period. This warranty will be considered null and void and Stelpro will have the right to refuse any claims if  without



corrosion or discoloration caused by excessive heat, chemical cleaning products and abrasive agents. It does not cover any damage that occurred

during the shipping.

Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages and some of them do not allow limitations



may have other rights which vary from state to state or from province to province.

LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY

LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY

LIMITED WARRANTY

This manual suits for next models

Table of contents

Other Stelpro Heater manuals

Stelpro

Stelpro ACWS1000 Series User manual

Stelpro

Stelpro SIL2030 series User manual

Stelpro

Stelpro AALU1 Series User manual

Stelpro

Stelpro DR series User manual

Stelpro

Stelpro LCH48T User manual

Stelpro

Stelpro ACWS750 Series User manual

Stelpro

Stelpro Spider SGH series User manual

Stelpro

Stelpro ZENITH SIRH1501W Series User manual

Stelpro

Stelpro ASIL Series User manual

Stelpro

Stelpro SCAS Series User manual

Stelpro

Stelpro PRIMA SPR Series User manual

Stelpro

Stelpro PDH0758W User manual

Stelpro

Stelpro pulsair RWF Series User manual

Stelpro

Stelpro FI Series User manual

Stelpro

Stelpro ASHC series User manual

Stelpro

Stelpro CW750-CW1000 User manual

Stelpro

Stelpro ACF4002 User manual

Stelpro

Stelpro ALUX406101 User manual

Stelpro

Stelpro FI6032W User manual

Stelpro

Stelpro SILBH2060 Series Service manual

Stelpro

Stelpro APCH series User manual

Stelpro

Stelpro FUHGX Series User manual

Stelpro

Stelpro OXFORD RUH Series User manual

Stelpro

Stelpro ACW1000930 Series User manual

Popular Heater manuals by other brands

oventrop

oventrop Regucor Series quick start guide

Blaze King

Blaze King CLARITY CL2118.IPI.1 Operation & installation manual

ELMEKO

ELMEKO ML 150 Installation and operating manual

BN Thermic

BN Thermic 830T instructions

KING

KING K Series Installation, operation & maintenance instructions

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Installation instructions and owner's manual

Well Straler

Well Straler RC-16B user guide

EUROM

EUROM 333299 instruction manual

Heylo

Heylo K 170 operating instructions

Eterna

Eterna TR70W installation instructions

Clarke

Clarke GRH15 Operation & maintenance instructions

IRSAP

IRSAP The Radiator Company Ovali Fitting instructions

Empire Heating Systems

Empire Heating Systems WCC65 Installation and owner's instructions

Wetekom

Wetekom 92 86 43 Original instructions

Desa

Desa SPC170-F owner's manual

Watlow

Watlow Watrod Electric Tubular Heaters Specifications

Haverland

Haverland ECO-DRY GPS Series Instruction & installation manual

iLO

iLO IHP2424 User and installation manual
