StarTech.com ST4200MINI User manual

Manual Revision: 02/23/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

ST4200MINI

Mini 4 Port USB 2.0 Hub

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use ofTrademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Specications..........................................................................................3

Technical Support ..................................................................................4

Warranty Information............................................................................4

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com 4-port USB 2.0 mini hub. ST4200MINI allows

you to plug in your most demanding next-generation peripherals and enjoy data

transfer speeds of up to 480 Mbps. And, since ST4200MINI is backward compatible

with USB 1.1 specications, your less demanding peripherals will still function perfectly

with no adjustments. The hub’s compact, “pocket”-sized design means you can take it

with you anywhere, and since it’s USB powered, you don’t have to worry about nding

an available power outlet.

Packaging Contents

• 1 x USB 2.0 4-port mini-hub

System Requirements

• A USB 2.0 cable computer (for maximum data transfer speed)

• Operating system requirement: Windows 2000, Windows XP, Windows Vista™,

Windows 7 ; Mac OS X and up

Instruction Manual

Installation

1. With your computer turned on, plug the mini hub into an open USB 2.0 port.

2. Your computer will automatically detect the device and install the drivers.

3. If you are using several high-powered devices, you may need to use the power

adapter. Plug the adapter into the DC power port on the side of the device and

connect the other end into an available power source.

Checking Proper Installation

On Windows systems, you can check Device Manager to ensure that your hub has been

installed successfully. Under the Universal Serial Bus heading, you should see“Generic

USB Hub” (or similar). If installed correctly, there should be no question or exclamation

marks beside the device name.

Over Current Status

If you are powering the hub through the USB bus and are using several high-current

devices, you may exceed the current limit. If the current limit is exceeded, the hub will

disconnect power from the related port (the port’s LED will also go out). If you have

exceeded the current limitation, plug in the hub’s optional power adapter.

If you are using Windows, you may see a pop-up window telling you that the maximum

current has been exceeded. If you see this window, you can click the Reset button to

resume working. If no window appears, reset the hub by unplugging the USB cable then

plugging it back in.

Instruction Manual

Specications

Ports 4 x downstream, 1 x upstream

Power Bus power: 5V 500mA

LEDs 1 x hub power (red) 4 x port status (green)

Working Temperature 32~104ºF (0~40ºC)

Storage Temperature 14~185ºF (-10~85ºC)

Compliance FCC Class B

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
