StarTech.com MONSTND Quick start guide

Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: March 25, 2019 2:04 PM

Product Diagram (MONSTND)

Rear View

Part Function

1Top Plate • Used as a platform for a Monitor or Laptop

2Upper Leg

• Attaches to the Top Plate

• Congurable with three height-adjustment

settings

3Cable-Management

Slots • Used for organizing and routing Cables

4Lower Leg • Attaches to the Upper Leg

5Height-Adjustment

Screw

• Used to secure the Upper Legs and Lower

Legs together

• Can be removed to adjust height settings

Monitor Riser - Metal - Height Adjustable

Requirements

• Clean, Flat, and Stable Surface x 1

For the latest requirements please visit: www.startech.com/MONSTND.

Installation

Assembly

1. Place the Top Plate, top side down, onto a Clean, Flat, and Stable Surface.

2. Place the Upper Legs onto the Top Plate. Ensure the Holes in the Upper Legs are

aligned with the Holes in the Top Plate. The slanted portion of the Upper Legs

should be aligned with the slanted portion of the Top Plate.

3. Secure the Upper Legs to the Top Plate, using two M6x10 mm Screws for each

side. Fasten the M6x10 mm Screws using the 4 mm Hex Key.

4. Align the Lower Leg against the Upper Leg at the desired Monitor height setting.

5. Insert the Height-Adjustment Screw through the Upper Leg and into the Lower

Leg, then hand-tighten.

Note: Tighten the Height-Adjustment Screws by hand. Do not over-tighten.

6. Repeat steps 4 and 5 to attach the second Lower Leg.

7. Turn the Monitor Riser Assembly upright.

Operation

Height Adjustment

1. Place the assembled Monitor Riser, top side down, on a Clean, Flat, and Stable

Surface.

2. Remove the Height-Adjustment Screws.

3. Adjust the height of the Lower Legs to the desired height.

4. Insert the Height-Adjustment Screws through the Upper Legs and into the Lower

Legs, then hand-tighten.

5. Turn the Monitor Riser Assembly upright.
