StarTech.com PEX2EC35 User manual

3.5” Drive Bay PCI Express to Expresscard Adapter

PEX2EC35

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turn-

ing the equipment off and on, the user is encouraged to try to correct the interference by one

or more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowl-

edges that all trademarks, registered trademarks, service marks, and other protected names

and/or symbols contained in this manual and related documents are the property of their

respective holders.

Instruction Manual

Table of Contents

Introduction ................................................................................... 1

Features ......................................................................................1

Package Contents .......................................................................1

Installation...................................................................................... 2

Installing the PCI Express Card...................................................2

Installing the 3.5” Bay ..................................................................3

Speciﬁcations ................................................................................ 6

Technical Support ......................................................................... 7

Warranty Information .................................................................... 7

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com 3.5” Drive Bay PCI Express to

Expresscard Adapter. This device offers the convenience of being able to

use ExpressCards on a desktop computer, eliminating the cost of having

to buy duplicate cards to perform the same function among desktop and

notebook operating environments.

Features

Compliant with PCI Express Base Speciﬁcation 1.0a•

Internal USB Host port for support of USB based ExpressCards•

Supports both 34 and 54 form factor ExpressCards•

No driver installation required•

Package Contents

1 x DVI Expansion Cable•

1 x USB Type-B-to-10-pin-Header Adapter Cable•

1 x ExpressCard Drive 3.5” Enclosure•

1 x Instruction Manual•

1 x PCI Express Adapter Card•

1 X Power Cable•

• 1 X Low Profile Bracket

Instruction Manual

Installation

Installing the PCI Express Card

Shut down all power connected to the computer, as well as all devices1.

connected to the computer peripherally (i.e. Printers, Monitors,

Scanners etc.). As an added step to ensure safe installation, unplug

the power supply from the computer.

Remove the computer cover, allowing2.

access to the motherboard and

available slots.

Locate an empty PCI Express slot,3.

removing the metal bracket covering the

accompanying empty port/socket on the

rear panel of the computer chassis.

Position the card above the open PCI4.

Express slot, ensuring that the card is

properly aligned with the slot. Insert the

card ﬁrmly into the slot, distributing force

evenly across the length of the board.

Once inserted, secure the card into the5.

adjoining socket (previously covered by a

metal bracket, on the rear panel of the

Please note that the ExpressCard slot of this product does NOT support

hot-plugging. Installed ExpressCards will only be able to recognize the

card upon system reboot.

WARNING! PCI Express cards, like all computer equipment, can be

severely damaged by static electricity. Be sure that you are properly

grounded before opening your computer case or touching your

card. StarTech.com recommends that you wear an anti-static strap when

installing any computer component. If an anti-static strap is unavailable,

discharge yourself of any static electricity build-up by touching a large

grounded metal surface (such as the computer case) for several seconds.

Also be careful to handle the card by its edges and not the gold connec-

tors.

Instruction Manual

Installing the 3.5” Bay

Connect the Power, USB Type-B-to-10-pin-Header Adapter Cable1.

(optional) and DVI like Expansion Cable to the appropriate connectors

on the rear panel of the 3.5” ExpressCard Bay:

Remove the cover from a 3.5” drive bay, on the front panel of the host2.

computer case, then feed the remaining ends of the cables used in

step #1 through the open bay:

Instruction Manual

Continue to feed the cables into the computer case (through the open3.

drive bay), until the ExpressCard Bay is near the opening, then press

the ExpressCard Bay into the case so that it is ﬂush with the face of the

computer case:

Once the ExpressCard Bay has been inserted into the computer case,4.

fasten it to the computer chassis, as you normally would a 3.5” drive

(i.e. CD-ROM Drive, etc.), and connect the remaining ends of the

cables (see steps #1 and #2) to the appropriate ports as outlined on

the following page:

Instruction Manual

Connect the DVI like Expansion Cable (currently connected to the

ExpressCard Bay) to the PCI Express Card.

Connect the remaining ends of the power cables (currently connected

to the power port on the back of the ExpressCard Bay).

Connect the remaining end of the USB Type-B-to-10-pin-Header

Adapter Cable to an available USB (Type A) port, by threading it

through an open rear panel slot to an available (external) USB port.

Once the necessary connections have been made, close the computer5.

case, and power on the computer. If you wish to install an Express-

Card at this time, please do so prior to booting up the computer.

Instruction Manual

Specications

Bus Type PCI Express

Form Factor 34 and 54 ExpressCard

Maximum Date Transfer Rate 250 Mbps

Connectors:

1x 34/54 ExpressCard Slot

1x Internal USB Type B male Connector

1x Internal USB Header

1x SP4 male Connector

Operating System Support

Windows® 2000/XP/Vista™

Mac OSX +

Linux

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commit-

ment to provide industry-leading solutions. If you ever need help with your

product, visit www.startech.com/support and access our comprehensive

selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a one-year warranty. In addition, StarTech.

com warrants its products against defects in materials and workman-

ship for the periods noted, following the initial date of purchase. During

this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor

costs only. StarTech.com does not warrant its products from defects or

damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or

exclusions contained in this statement may not apply to you.
