StarTech.com ET90110ST System manual

10/100 Mbps RJ45 to Multimode ST Fiber Media Converter

StarTech ID: ET90110ST

StarTech.com’s high-speed ET90110ST media converters are engineered to make fiber connections simple

and reliable for even the most demanding network specialists. StarTech.com’s ET90110ST is

the perfect solution for connecting buildings to main networks.

Easy to set up and install in a matter of seconds. This reliable and compact fiber optic media converter

features a heavy-duty power supply to withstand the most challenging environments. It has 6

LED indicators to ensure its continuous operation.

ET90110ST easily converts between 10 Base-T or 100 Base-TX electrical Ethernet signals and

100 Base-FX optical Ethernet signals. While supporting a maximum multimode fiber optic cable

distance of 2km, it allows full wire speed of 148,800 packet per second throughput that prevents bottlenecks

and keeps your data flowing quickly and smoothly.

Guaranteed compatibility with 3COM, Cisco, Lucent and Nortel networks and fully complies with

the IEEE 802.3 and 802.3u standard

Applications and Solutions

> Connect remote areas of large buildings to the main network

> Connect 2 buildings that are on the same campus

Features

> Automatically detects 10 or 100 Mbps network connection speed

> Complete set of 6 LED indicators continuously shows operating status

> Compliant with IEEE 802.3u standard and guaranteed compatibility with 3Com, Cisco, Lucent,

and Nortel networks

> Easy installation and setup in seconds

> Full wire speed of 148,800 packet per second throughput prevents bottlenecks

> Heavy-Duty power supply which is engineered to withstand the most challenging conditions and

environments

> It’s compact design and weight makes it portable and unobtrusive to carry

> Standard RJ-45 connectors for connecting to UTP media, and ST connector for connecting to

fiber media

> Supports 802.3u 100Base-TX and 100Base-FX industry standards

> Supports a maximum multimode fiber optic cable distance of 2 kilometers

> Supports Half-Duplex and Full-Duplex operating modes up to 200 Mbps

Specifications

> Color Beige

> Connector Types 1 - RJ45 Female

> Connector Types 1 - Fiber Optic ST Female

> LED Indicators 1 - Power

> LED Indicators 1 - Fiber Mode

> LED Indicators 1 - Fiber Link

> LED Indicators 1 - Ethernet Link

> LED Indicators 1 - LAN Mode

> Power Adapter Included Yes

> Power Adapter - Amperage 1

> Power Adapter - DC Voltage DC 9

> Carton Quantity 12

> Shipping (Package) Weight 2.06 lb [0.93 kg]

> Weight (includes adapter) 1.95 lbs

> Dimensions(in inches) 4.8 x 3.37 x 0.78

> Operating Temperature 0 ~ 70 degrees Celsius

> Power Adapter 9V/1A

> Connectors

> UTP Port 1 x RJ-45 MDI

> Fiber Port 1 x ST Fiber

> Fiber Duplex Mode Full-Duplex or Half-Duplex

> Led Indicators

> 1 Power indicator

> 1 Fiber mode display indicator

> 1 Fiber link indicator

> 2 LAN mode indicators

> 1 Ethernet link indicator

> Wave Length 1300nm

> Emissions FCC Class A, CE Class A & CISPR Class A
