StarTech.com IREXT2 System manual

Wireless Infrared IR Remote Control Extender - 330ft (100m)

StarTech ID: IREXT2

The IREXT2 Wireless IR Extender Kit lets you extend an Infrared signal from a remote control by up to 115ft (35m).

Using a radio frequency that can operate through walls, doors, and around corners, the remote control extender lets

you control your A/V devices from greater distances or even from another room. This adds configuration versatility

for multi-room or outdoor applications, without having to move within range of your remote controlled device.

The remote control extender is comprised of two units - one local IR remote extender, which accepts the incoming IR

signal from the remote control and wirelessly transmits it to the second IR remote control Receiver unit positioned

near the controlled device.

The IREXT2 Infrared Extender is backed by StarTech.com's 2-year warranty and free lifetime technical support.

Applications

Control any IR-equipped consumer electronics (e.g. DVD players, satellite receivers, cable boxes) products

from a different room

Features

IR signal extension up to 35m

Compatible with any IR-equipped device

Kit includes both extender and receiver units

www.startech.com

1 800 265 1844

Technical Specifications

Warranty 2 Years

Ports 1

Cabling Wireless Ethernet

Frequency Range IR: 30-60kHz

Max Distance 35 m / 115 ft

Frequency 433.92 MHz +/-1 MHz

Product Length 4.1 in [103 mm]

Product Width 2.6 in [67 mm]

Product Height 1.4 in [35.3 mm]

Product Weight 9.4 oz [266.7 g]

Input Current 0.2A

Input Voltage 100~240V

Power Adapter Included Two

Output Voltage 12 DC

Output Current 0.2A

Operating Temperature 0°C to 43°C (32°F to 109°F)

Storage Temperature -20°C to 60°C (-4°F to 140°F)

Shipping (Package) Weight 0.8 lb [0.4 kg]

Included in Package 1 - IREXT transmitter

Included in Package 1 - IREXT receiver

Included in Package 1 - IR extender probe

Included in Package 2 - Power Adapter

Included in Package 1 - Instruction Manual

Certifications, Reports and Compatibility
