StarTech.com SAT2510U2E User manual

eSATA/USB SATA Drive Enclosure

SAT2510U2E Instruction Manual

Actual product may vary from photo

2.5" eSATA/USB 2.0 SATA Drive Enclosure

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aannddootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other protected names

and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur

these references are for illustrative purposes only and do not represent an endorsement of a

product or service by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks,

registered trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Instruction Manual

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Hardware Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting to a Host Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Verifying Installation and Drive Partitions . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Instruction Manual

Thank you for purchasing a StarTech.com 2.5” eSATA/USB 2.0 SATA Drive Enclosure.

This versatile enclosure can be connected to a host computer using either eSATA or USB

2.0, and is natively supported by modern operating systems eliminating the need to

install drivers or third party software. Plus, with a sleek, yet sturdy design, SAT2510U2E

can be a perfect notebook accessory, providing added storage for a flawless user

experience.

IInnttrroodduuccttiioonn

•Portable, lightweight design

Features

System Requirements:

•Compatible with Windows ME, 2000, XP and Vista, as well as Mac OS 10 and up

Package Contents:

•2.5” SATA Enclosure

This package should contain:

•Sturdy yet attractive construction

•Includes protective carrying pouch

•A 2.5” SATA I/II hard drive (use SATA II for improved data transfer speeds)

•USB Cable

•USB to DC Cable

•User Manual

•Travel Pouch

•Screws

•Screw Driver

Instruction Manual

HHaarrddwwaarreeGGuuiiddee

Front

Panel

Rear Panel

(Enclosure)

Power

Port

eSATA

Port

USB

Port

LED Power

and Status

Indicator

IInnssttaallllaattiioonn

WARNING: Hard drives require careful handling, especially when being

transported. If you are not careful with your hard disk, lost data may result.

Always handle your hard drive and storage device with caution.

WARNING: Hard drives, like all computer equipment can also be severely

damaged by static electricity. Be sure that you are properly grounded before

opening your computer case or touching any components. StarTech.com

recommends that you wear an anti-static strap when installing any computer

equipment. If an antistatic strap is unavailable, discharge yourself of any static

electricity build-up by touching a large grounded metal surface (such as the

computer case) for several seconds.

Instruction Manual

1. Remove the screws from the enclosure, and remove the rear panel cover. Pull the front

panel out of the enclosure:

2. Attach the 2.5” SATA hard drive to the connector provided:

2.5” SATA

Hard Drive

3. Insert the front panel (with drive attached) into the rear panel (enclosure).

Instruction Manual

4. Fasten the front panel (with drive attached) to the rear panel (enclosure), using the

screws removed in step #1.

CCoonnnneeccttiinnggttooaaHHoossttCCoommppuutteerr

To connect SAT2510U2E to a host computer using USB, simply insert the included USB

cable into the USB type Mini B slot provided by the enclosure, and the remaining end into

an available USB type A slot on the host computer.

To connect SAT2510U2E to a host computer using eSATA, connect the enclosure to the

host computer, using a standard eSATA cable. To provide power to the enclosure, connect

the USB to DC cable (provided) to an available USB port on the host computer, and insert

the remaining end into the power port located on the front panel of SAT2510U2E.

Once the enclosure has been connected to the host computer, the operating system will

automatically update the necessary driver files. Once this has been completed, the newly

connected drive should appear as an added hard drive, in My Computer.

VVeerriiffyyiinnggIInnssttaallllaattiioonnaannddDDrriivveePPaarrttiittiioonnss

To ensure that the drive is properly detected by the operating system (for Windows users):

1. Right-click on My Computer, and select Manage:

Fasten here

Instruction Manual

2. Select Disk Management, in the left pane. In the right pane, you should notice the new

hard drive:

New

Drive

3. Right-click on the Unallocated block, and select New Partition.

4. This will launch the New Partition Wizard. Please follow the instruction provided by the

Wizard, to partition the drive for use.

5. Once the partition has been created, the drive installed within SAT2510U2E will be

recognized as a New Volume in Disk Management, as well as in My Computer:

SAT2510U2E

Installed

Drive

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

LLiimmiittaattiioonnooffLLiiaabbiilliittyy

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

SSppeecciiffiiccaattiioonnss

Operation Temperature 0°C ~ 70°C

Storage Temperature -20°C ~ 70°C

Operation Humidity 10% ~ 90% RH

Storage Humidity 5% ~ 95% RH

Operating System

Compatibility Windows ME, 2000, XP, Vista, Mac OS X and up

Regulatory

Certifications CE / FCC certified, RoHS compliant

October 18 2007 (Rev. A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer Parts”.

Since 1985, we have been providing IT professionals with the quality products

they need to complete their solutions. We offer an unmatched selection of

computer parts, cables, server management solutions and A/V products and

serve a worldwide market through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products and to

access exclusive interactive tools such as the Parts Finder and the KVM

Reference Guide. StarTech.com makes it easy to complete almost any IT

solution. Find out for yourself why our products lead the industry in performance,

support, and value.
