StarTech.com FAN8025PWM User manual

Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 07/07/2011

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1 x Case Fan

• 1 x 4-pin Y-Cable

System Requirements

• 3-pin or 4-pin fan header

• Mounting location for case fan

• Mounting hardware

FAN8025PWM / FAN9225PWM / FAN12025PWM

80mm/92mm/120mm Computer Case Fan with 4-pin PWM connector

How to Use

The included 4-pin Y-Cable can be used on systems with only one available 4-pin PWM Fan Header to connect

two dierent system fans. Connect the 4-pin female connector on the cable to the Fan Header on the system

board, then connect a 4-pin PWM-enabled fan to the 4-pin male connector (black). A 3-pin or 4-pin fan can be

connected to the 3-pin connector (white). The speed of both fans will be controlled simultaneously, based on the

PWM signal from the 4-pin connector (black).

*actual product may vary from photos

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com,

or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere

in the body of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and other protected names and/or

symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During

this period, the products may be returned for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or

indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the

product exceed the actual price paid for the product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply,

the limitations or exclusions contained in this statement may not apply to you.

Specications

FAN8025PWM FAN9225PWM FAN12025PWM

Bearing Type Ever Lubricate Bearing

Air Flow Rate 9.74 ~ 25.02 CFM 12.78 ~ 39.35 CFM 33.20 ~ 78.41 CFM

Noise Level < 10dBA ~ 28 dBA < 10 dBA ~ 25 dBA < 17.2 dBA ~ 39 dBA

RPM 800 ~ 2500 RPM 700 ~ 2200 RPM 800 ~ 2200 RPM

Material Plastic

MTBF 40, 000 hours

Operating Temperature -10°C to 70°C (14°F to 158°F)

Storage Temperature -20°C to 70°C (-4°F to 158°F)

Humidity 0 ~ 65% RH

Dimensions 80.0mm x 80.0mm x

25.0mm

92.0mm x 92.0mm x

25.0mm

120.0mm x 120.0mm x

25.0mm

Weight 86g 96g 118g
